我有一台運行 L2TP/IPSec VPN 伺服器的 Mac OS X Server (10.9) 電腦。設定似乎很好，伺服器和 VPN 的主機名稱都設定為 DynDNS 主機名稱。伺服器配置在具有連接埠轉送功能的 AirPort Extreme 路由器後面，連接到已停用路由器（橋接）的 Arris 數據機/路由器。伺服器配置有靜態內部 IP，路由器也透過 DHCP 綁定其 MAC 位址，以確保內部位址一致。
如果我輸入伺服器的內部 IP 位址 (10.0.1.x) 並嘗試從網路內部連接到 VPN 伺服器，則一切正常。但是，如果我輸入外部主機名稱（DynDNS 名稱）並嘗試再次從網路內部連接，則連接失敗。同樣，在網路外部（例如透過 LTE）時也無法連線。
其他服務（SSH、遠端桌面等）在網路內部和外部都可以正常連線。僅 VPN 受到影響。我可以確認可以透過 SSH 和遠端桌面（連接埠 22/5900）存取該伺服器。
我進一步確認，除了其他服務使用的其他連接埠之外，路由器還會轉送連接埠 500(UDP)、1701(UDP) 和 4500(UDP)。
當我嘗試連線時，客戶端控制台上會顯示以下內容：
12/16/13 11:13:33.213 PM configd[28]: SCNC: start, triggered by (15822) com.apple.prefe, type L2TP, status 0, trafficClass 0
12/16/13 11:13:33.229 PM pppd[15967]: publish_entry SCDSet() failed: Success!
12/16/13 11:13:33.230 PM pppd[15967]: publish_entry SCDSet() failed: Success!
12/16/13 11:13:33.230 PM pppd[15967]: pppd 2.4.2 (Apple version 727.1.15) started by user, uid 501
12/16/13 11:13:33.231 PM pppd[15967]: L2TP connecting to server 'x.x.x.x' (x.x.x.x)...
12/16/13 11:13:33.232 PM pppd[15967]: IPSec connection started
12/16/13 11:13:33.244 PM racoon[15968]: accepted connection on vpn control socket.
12/16/13 11:13:33.244 PM racoon[15968]: Connecting.
12/16/13 11:13:33.244 PM racoon[15968]: IPSec Phase 1 started (Initiated by me).
12/16/13 11:13:33.245 PM racoon[15968]: IKE Packet: transmit success. (Initiator, Main-Mode message 1).
12/16/13 11:13:33.245 PM racoon[15968]: >>>>> phase change status = Phase 1 started by us
12/16/13 11:13:33.416 PM racoon[15968]: >>>>> phase change status = Phase 1 started by peer
12/16/13 11:13:33.416 PM racoon[15968]: IKE Packet: receive success. (Initiator, Main-Mode message 2).
12/16/13 11:13:33.420 PM racoon[15968]: IKE Packet: transmit success. (Initiator, Main-Mode message 3).
12/16/13 11:13:33.429 PM racoon[15968]: IKE Packet: receive success. (Initiator, Main-Mode message 4).
12/16/13 11:13:33.447 PM racoon[15968]: IKE Packet: transmit success. (Initiator, Main-Mode message 5).
12/16/13 11:13:36.715 PM racoon[15968]: !!! skipped retransmitting frags: frag_flags 1, r->sendbuf->l 112, max 1280
12/16/13 11:13:36.715 PM racoon[15968]: Received retransmitted packet from x.x.x.x[500].
12/16/13 11:13:36.715 PM racoon[15968]: the packet is retransmitted by x.x.x.x[500].
12/16/13 11:13:36.745 PM racoon[15968]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:39.872 PM racoon[15968]: !!! skipped retransmitting frags: frag_flags 1, r->sendbuf->l 112, max 1280
12/16/13 11:13:39.872 PM racoon[15968]: Received retransmitted packet from x.x.x.x[500].
12/16/13 11:13:39.873 PM racoon[15968]: the packet is retransmitted by x.x.x.x[500].
12/16/13 11:13:40.043 PM racoon[15968]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:43.170 PM racoon[15968]: !!! skipped retransmitting frags: frag_flags 1, r->sendbuf->l 112, max 1280
12/16/13 11:13:43.170 PM racoon[15968]: Received retransmitted packet from x.x.x.x[500].
12/16/13 11:13:43.170 PM racoon[15968]: the packet is retransmitted by x.x.x.x[500].
12/16/13 11:13:43.335 PM racoon[15968]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:55.912 PM racoon[15968]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:56.367 PM racoon[15968]: !!! skipped retransmitting frags: frag_flags 1, r->sendbuf->l 112, max 1280
12/16/13 11:13:56.367 PM racoon[15968]: Received retransmitted packet from x.x.x.x[500].
12/16/13 11:13:56.367 PM racoon[15968]: the packet is retransmitted by x.x.x.x[500].
12/16/13 11:14:03.416 PM pppd[15967]: IPSec connection failed
12/16/13 11:14:03.416 PM racoon[15968]: IPSec disconnecting from server x.x.x.x
12/16/13 11:14:03.416 PM racoon[15968]: glob found no matches for path "/var/run/racoon/*.conf"
在伺服器的控制台上：
12/16/13 11:13:33.404 PM racoon[216]: IPSec Phase 1 started (Initiated by peer).
12/16/13 11:13:33.404 PM racoon[216]: IKE Packet: receive success. (Responder, Main-Mode message 1).
12/16/13 11:13:33.404 PM racoon[216]: >>>>> phase change status = Phase 1 started by us
12/16/13 11:13:33.404 PM racoon[216]: IKE Packet: transmit success. (Responder, Main-Mode message 2).
12/16/13 11:13:33.541 PM racoon[216]: IKE Packet: receive success. (Responder, Main-Mode message 3).
12/16/13 11:13:33.559 PM racoon[216]: IKE Packet: transmit success. (Responder, Main-Mode message 4).
12/16/13 11:13:33.566 PM racoon[216]: Connecting.
12/16/13 11:13:36.697 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:36.697 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:39.989 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:43.286 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:13:56.484 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:14:06.392 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:14:12.978 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:14:32.767 PM racoon[216]: IKE Packet: transmit success. (Phase 1 Retransmit).
12/16/13 11:14:39.390 PM racoon[216]: IKEv1 Phase 1: maximum retransmits. (Phase 1 Maximum Retransmits).
12/16/13 11:14:39.390 PM racoon[216]: Phase 1 negotiation failed due to time up. 45b24df5cc9713e7:9b427f72231ccb59
我注意到的一件事是，客戶端在 11:14:03 失敗，而伺服器又持續重傳封包 30 秒，一直到逾時。本例中的客戶端是 Mac OS X，但 iOS 用戶端的行為類似。
我應該在此處查找哪些故障排除步驟？
答案1
好吧，事實證明這是最新版本的 Mac OS X Server 中的「錯誤」。據我所知，racoon如果來源端口不是 UDP 4500，IKE 守護程序將不會接受連接。舊版的守護程式沒有此限制。如果直接連接到伺服器的 IP，來自網路內部的連接不會隨機化端口，但環回和外部連接顯然會隨機化端口，從而導致失敗。
那麼，快速的解決方案就是將二進位檔案替換racoon為 OS 10.8 的舊版本，當然是透過命名來備份舊的racoon.old（或者會racoon.new更正確？：D）。
蘋果似乎確實意識到了這個問題，希望他們能發布修復程式；同時，恢復二進位。
