我為我的郵件伺服器購買了憑證並在 Postfix 中進行了配置,如下所示:
smtpd_tls_security_level=may
smtpd_tls_CAfile = /etc/ssl/certs/ca-certificates.crt
smtpd_tls_cert_file = /somepath/chain.crt
smtpd_tls_key_file = /somepath/myserver.key
我創建chain.crt
每後綴說明透過連接我的憑證和兩個中間 CA 憑證。 (準確地說,首先是我自己的證書,然後COMODORSADomainValidationSecureServerCA.crt
是COMODORSAAddTrustCA.crt
)根據日誌,與我的郵件伺服器的大多數連接現在都已加密,因此一切似乎都正常。
但是,當我使用連接到伺服器時,openssl s_client -connect mail.example.com:25 -starttls smtp
得到以下輸出,這似乎表明出現了問題:
CONNECTED(00000003)
depth=2 C = GB, ST = Greater Manchester, L = Salford, O = COMODO CA Limited, CN = COMODO RSA Certification Authority
verify error:num=20:unable to get local issuer certificate
verify return:0
---
Certificate chain
0 s:/OU=Domain Control Validated/OU=PositiveSSL/CN=mail.example.com
i:/C=GB/ST=Greater Manchester/L=Salford/O=COMODO CA Limited/CN=COMODO RSA Domain Validation Secure Server CA
1 s:/C=GB/ST=Greater Manchester/L=Salford/O=COMODO CA Limited/CN=COMODO RSA Domain Validation Secure Server CA
i:/C=GB/ST=Greater Manchester/L=Salford/O=COMODO CA Limited/CN=COMODO RSA Certification Authority
2 s:/C=GB/ST=Greater Manchester/L=Salford/O=COMODO CA Limited/CN=COMODO RSA Certification Authority
i:/C=SE/O=AddTrust AB/OU=AddTrust External TTP Network/CN=AddTrust External CA Root
---
Server certificate
-----BEGIN CERTIFICATE-----
8<
-----END CERTIFICATE-----
subject=/OU=Domain Control Validated/OU=PositiveSSL/CN=mail.example.com
issuer=/C=GB/ST=Greater Manchester/L=Salford/O=COMODO CA Limited/CN=COMODO RSA Domain Validation Secure Server CA
---
No client certificate CA names sent
---
SSL handshake has read 5217 bytes and written 489 bytes
---
New, TLSv1/SSLv3, Cipher is ECDHE-RSA-AES256-GCM-SHA384
Server public key is 2048 bit
Secure Renegotiation IS supported
Compression: zlib compression
Expansion: zlib compression
SSL-Session:
Protocol : TLSv1.2
Cipher : ECDHE-RSA-AES256-GCM-SHA384
Session-ID: B2736D2B1639153CB8379480ACDBC1F0B1DCC51DE7CC27DA59061740F0186EA1
Session-ID-ctx:
Master-Key: 9EE658D6B1835F94D140E7BBF05A5A8960566584A8BC6FF40DD5D038C70127A63BAB580A41BC55DEEA3C031FCC7FA550
Key-Arg : None
PSK identity: None
PSK identity hint: None
SRP username: None
TLS session ticket lifetime hint: 3600 (seconds)
TLS session ticket:
0000 - 09 8a 6d 68 70 0c 64 c0-23 2e fc f2 d4 21 ca bd ..mhp.d.#....!..
0010 - 0a 15 4f 36 06 a8 ea f9-e2 84 de 18 cf 31 af 77 ..O6.........1.w
0020 - 2a a1 98 d5 f8 df 54 48-82 68 cb c3 91 9b 38 60 *.....TH.h....8`
0030 - dc 2e 18 f4 b9 bd 43 3e-26 cf 80 49 48 bb a4 98 ......C>&..IH...
0040 - bc 94 7d 1e 5f 51 7e 52-d6 ad 7f 8b e5 36 ee 55 ..}._Q~R.....6.U
0050 - 7a bb 15 d3 c2 7f b2 f4-5a 85 a5 80 1b 9e 67 98 z.......Z.....g.
0060 - 3a 2f 5c d1 34 d5 bb 11-c7 8f fc 10 cb c3 b4 cb :/\.4...........
0070 - 49 61 41 ac aa b1 cb eb-6f 7a 22 e5 79 a2 c6 1f IaA.....oz".y...
0080 - 98 25 39 f0 f0 79 b4 ee-95 72 93 04 0f a2 f3 69 .%9..y...r.....i
0090 - 8f 8a 86 c6 8f a5 38 ed-25 ba fc c8 db 6b 9a 8e ......8.%....k..
00a0 - 13 1e e5 c6 28 98 e4 17-ce 69 d5 c2 aa 1a de 4b ....(....i.....K
Compression: 1 (zlib compression)
Start Time: 1400131328
Timeout : 300 (sec)
Verify return code: 20 (unable to get local issuer certificate)
---
另外,運行時openssl verify chain.crt
我收到相同的錯誤訊息:
chain.crt: OU = Domain Control Validated, OU = PositiveSSL, CN = mail.example.com
error 20 at 0 depth lookup:unable to get local issuer certificate
我嘗試AddTrustExternalCARoot.crt
在其末尾添加chain.crt
,使錯誤訊息更改為verify error:num=19:self signed certificate in certificate chain
。此外,我連接的機器已經安裝了這個證書,所以應該不需要它。
所以我的問題是:我的郵件伺服器有問題還是我只是openssl
錯誤地使用了命令?我是否應該將根憑證包含在鏈中?
答案1
聽起來您已經正確安裝了它,但您的驗證步驟不正確。除非您明確告知,否則 OpenSSL 不知道在哪裡尋找根憑證。
嘗試openssl s_client -connect mail.example.com:25 -starttls smtp -CApath /etc/ssl/certs
一下。那應該有效。
