我最近添加了一個StarTech 4 連接埠 PCIe SATA 卡到 Linux 伺服器。該卡透過 SFF-8087 連接到 Norco 4224 背板和 4 個新硬碟，我想將其配置為新的軟體 RAID。
主機板（Gigabyte GA-990FXA-UD5）已經有 8 個板載 SATA 端口，使用類似的晶片組（2 個 Marvell 88SE9172 晶片），工作正常，目前配置為 2 個獨立的軟體 RAID（使用mdadm）。
但是，系統沒有偵測到新的硬碟，我也無法按照ctrl+M手冊的建議進入控制卡的BIOS。有沒有人遇到類似的問題，或是有如何解決問題的建議？先致謝！
輸出來自lspci（似乎偵測到 SATA 卡，倒數第 5 個條目）：
00:00.0 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD/ATI] RD890 PCI to PCI bridge (external gfx0 port B) [1002:5a14] (rev 02)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5000]
00:02.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] RD890 PCI to PCI bridge (PCI express gpp port B) [1002:5a16]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:09.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] RD890 PCI to PCI bridge (PCI express gpp port H) [1002:5a1c]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:0a.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] RD890 PCI to PCI bridge (external gfx1 port A) [1002:5a1d]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:0b.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] RD890 PCI to PCI bridge (NB-SB link) [1002:5a1f]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:0c.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] RD890S PCI Express bridge for GPP2 port 1 [1002:5a20]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:11.0 SATA controller [0106]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 SATA Controller [AHCI mode] [1002:4391] (rev 40)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:b002]
Kernel driver in use: ahci
00:12.0 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB OHCI0 Controller [1002:4397]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ohci-pci
Kernel modules: ohci_pci
00:12.2 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB EHCI Controller [1002:4396]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ehci-pci
00:13.0 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB OHCI0 Controller [1002:4397]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ohci-pci
Kernel modules: ohci_pci
00:13.2 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB EHCI Controller [1002:4396]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ehci-pci
00:14.0 SMBus [0c05]: Advanced Micro Devices, Inc. [AMD/ATI] SBx00 SMBus Controller [1002:4385] (rev 42)
Kernel modules: i2c_piix4, sp5100_tco
00:14.2 Audio device [0403]: Advanced Micro Devices, Inc. [AMD/ATI] SBx00 Azalia (Intel HDA) [1002:4383] (rev 40)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:a132]
Kernel driver in use: snd_hda_intel
Kernel modules: snd_hda_intel
00:14.3 ISA bridge [0601]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 LPC host controller [1002:439d] (rev 40)
Subsystem: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 LPC host controller [1002:439d]
00:14.4 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] SBx00 PCI to PCI Bridge [1002:4384] (rev 40)
00:14.5 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB OHCI2 Controller [1002:4399]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ohci-pci
Kernel modules: ohci_pci
00:15.0 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] SB700/SB800/SB900 PCI to PCI bridge (PCIE port 0) [1002:43a0]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:15.1 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] SB700/SB800/SB900 PCI to PCI bridge (PCIE port 1) [1002:43a1]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:15.2 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] SB900 PCI to PCI bridge (PCIE port 2) [1002:43a2]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:15.3 PCI bridge [0604]: Advanced Micro Devices, Inc. [AMD/ATI] SB900 PCI to PCI bridge (PCIE port 3) [1002:43a3]
Kernel driver in use: pcieport
Kernel modules: shpchp
00:16.0 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB OHCI0 Controller [1002:4397]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ohci-pci
Kernel modules: ohci_pci
00:16.2 USB controller [0c03]: Advanced Micro Devices, Inc. [AMD/ATI] SB7x0/SB8x0/SB9x0 USB EHCI Controller [1002:4396]
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5004]
Kernel driver in use: ehci-pci
00:18.0 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 0 [1022:1600]
00:18.1 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 1 [1022:1601]
00:18.2 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 2 [1022:1602]
Kernel modules: amd64_edac_mod
00:18.3 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 3 [1022:1603]
Kernel driver in use: k10temp
Kernel modules: k10temp
00:18.4 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 4 [1022:1604]
Kernel driver in use: fam15h_power
Kernel modules: fam15h_power
00:18.5 Host bridge [0600]: Advanced Micro Devices, Inc. [AMD] Family 15h Processor Function 5 [1022:1605]
01:00.0 VGA compatible controller [0300]: NVIDIA Corporation G98 [GeForce 9300 GE] [10de:06e0] (rev a1)
Subsystem: Pegatron Device [1b0a:9004]
Kernel driver in use: nouveau
Kernel modules: nvidiafb, nouveau
02:00.0 USB controller [0c03]: Etron Technology, Inc. EJ168 USB 3.0 Host Controller [1b6f:7023] (rev 01)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5007]
Kernel driver in use: xhci_hcd
Kernel modules: xhci_hcd
03:00.0 SATA controller [0106]: Marvell Technology Group Ltd. 88SE9172 SATA 6Gb/s Controller [1b4b:9172] (rev 11)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:b000]
Kernel driver in use: ahci
04:00.0 Ethernet controller [0200]: Emulex Corporation OneConnect 10Gb NIC (be3) [19a2:0710] (rev 01)
Subsystem: Emulex Corporation Device [10df:e722]
Kernel driver in use: be2net
Kernel modules: be2net
04:00.1 Ethernet controller [0200]: Emulex Corporation OneConnect 10Gb NIC (be3) [19a2:0710] (rev 01)
Subsystem: Emulex Corporation Device [10df:e722]
Kernel driver in use: be2net
Kernel modules: be2net
05:00.0 SATA controller [0106]: Marvell Technology Group Ltd. 88SE9230 PCIe SATA 6Gb/s Controller [1b4b:9230] (rev 11)
Subsystem: Marvell Technology Group Ltd. 88SE9230 PCIe SATA 6Gb/s Controller [1b4b:9230]
Kernel driver in use: ahci
06:0e.0 FireWire (IEEE 1394) [0c00]: VIA Technologies, Inc. VT6306/7/8 [Fire II(M)] IEEE 1394 OHCI Controller [1106:3044] (rev c0)
Subsystem: Gigabyte Technology Co., Ltd GA-7VT600-1394 Motherboard [1458:1000]
Kernel driver in use: firewire_ohci
Kernel modules: firewire_ohci
07:00.0 Ethernet controller [0200]: Realtek Semiconductor Co., Ltd. RTL8111/8168/8411 PCI Express Gigabit Ethernet Controller [10ec:8168] (rev 06)
Subsystem: Gigabyte Technology Co., Ltd Motherboard [1458:e000]
Kernel driver in use: r8169
Kernel modules: r8169
08:00.0 USB controller [0c03]: Etron Technology, Inc. EJ168 USB 3.0 Host Controller [1b6f:7023] (rev 01)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:5007]
Kernel driver in use: xhci_hcd
Kernel modules: xhci_hcd
09:00.0 SATA controller [0106]: Marvell Technology Group Ltd. 88SE9172 SATA 6Gb/s Controller [1b4b:9172] (rev 11)
Subsystem: Gigabyte Technology Co., Ltd Device [1458:b000]
Kernel driver in use: ahci
lsblk 的輸出（僅偵測到現有磁碟機）：
NAME MAJ:MIN RM SIZE RO TYPE MOUNTPOINT
sda 8:0 0 111.8G 0 disk
├─sda1 8:1 0 11G 0 part [SWAP]
└─sda2 8:2 0 100.8G 0 part
└─md0 9:0 0 100.8G 0 raid1 /
sdb 8:16 0 111.8G 0 disk
└─sdb1 8:17 0 111.8G 0 part
└─md0 9:0 0 100.8G 0 raid1 /
sdc 8:32 0 1.8T 0 disk
└─sdc1 8:33 0 1.8T 0 part
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
sdd 8:48 0 1.8T 0 disk
└─sdd1 8:49 0 1.8T 0 part
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
sde 8:64 0 1.8T 0 disk
└─sde1 8:65 0 1.8T 0 part
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
sdf 8:80 0 1.8T 0 disk
└─sdf1 8:81 0 1.8T 0 part
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
sdg 8:96 0 1.8T 0 disk
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
sdh 8:112 0 1.8T 0 disk
└─sdh1 8:113 0 1.8T 0 part
└─md1 9:1 0 7.3T 0 raid6 /Lab_Share
答案1
我們最終解決了問題，這是電纜類型錯誤。
我們使用的是前向分支電纜。
這個特殊的設定需要一個離散至 SFF-8087（反向分支）電纜。
Unraid.net 有正向和反向分支 SFF-8087 電纜之間差異的說明，儘管從外面看它們看起來是一樣的。
答案2
倒數第五台 PCI 裝置不是 StarTech SATA 卡，而是 Marvell 6Gbps 晶片組。
我沒有看到列出的 PCI SATA 卡。它可能有缺陷，我不會懷疑。那時我在一家電腦商店工作，到處都在使用這些設備，它們的開箱故障率約為 10%。這可能是抽樣偏差，但在數百個中我傾向於相信趨勢。
確保 BIOS 中沒有設定停用 PCI 卡或 PCIe 至 PCI 橋接器。某些安裝程式將此稱為「舊版免費」模式。
