我正在嘗試使用綁定（特別是 802.3ad 模式）將具有兩個 1Gbps NIC 的 Linux 伺服器與交換器 Netgear ProSafe GSM7248V2 連接。結果非常令人困惑，我將感謝任何有關下一步嘗試的提示。
在伺服器端，這是我的 /etc/network/interfaces：
auto bond0
iface bond0 inet static
address 192.168.1.15/24
gateway 192.168.1.254
dns-nameservers 8.8.8.8
dns-search my-domain.org
bond-slaves eno1 eno2
bond-mode 4
bond-miimon 100
bond-lacp-rate 1
bond-xmit_hash_policy layer3+4
hwaddress aa:bb:cc:dd:ee:ff
交換器的配置如下：
(GSM7248V2) #show port-channel 3/2
Local Interface................................ 3/2
Channel Name................................... fubarlg
Link State..................................... Up
Admin Mode..................................... Enabled
Type........................................... Dynamic
Load Balance Option............................ 6
(Src/Dest IP and TCP/UDP Port fields)
Mbr Device/ Port Port
Ports Timeout Speed Active
------ ------------- --------- -------
0/7 actor/long Auto True
partner/long
0/8 actor/long Auto True
partner/long
(GSM7248V2) #show lacp actor 0/7
Sys Admin Port Admin
Intf Priority Key Priority State
------ -------- ----- -------- -----------
0/7 1 55 128 ACT|AGG|LTO
(GSM7248V2) #show lacp actor 0/8
Sys Admin Port Admin
Intf Priority Key Priority State
------ -------- ----- -------- -----------
0/8 1 55 128 ACT|AGG|LTO
(GSM7248V2) #show lacp partner 0/7
Sys System Admin Prt Prt Admin
Intf Pri ID Key Pri Id State
------ --- ----------------- ----- --- ----- -----------
0/7 0 00:00:00:00:00:00 0 0 0 ACT|AGG|LTO
(GSM7248V2) #show lacp partner 0/8
Sys System Admin Prt Prt Admin
Intf Pri ID Key Pri Id State
------ --- ----------------- ----- --- ----- -----------
0/8 0 00:00:00:00:00:00 0 0 0 ACT|AGG|LTO
我相信xmit“layer3+4”與交換器的負載平衡類型6最相容。第一件令人驚訝的事情是交換器看不到 LACP 夥伴的 MAC 位址。
在伺服器端，這是 /proc/net/bonding/bond0 的內容：
Ethernet Channel Bonding Driver: v3.7.1 (April 27, 2011)
Bonding Mode: IEEE 802.3ad Dynamic link aggregation
Transmit Hash Policy: layer3+4 (1)
MII Status: up
MII Polling Interval (ms): 100
Up Delay (ms): 0
Down Delay (ms): 0
802.3ad info
LACP rate: fast
Min links: 0
Aggregator selection policy (ad_select): stable
System priority: 65535
System MAC address: ac:1f:6b:dc:2e:88
Active Aggregator Info:
Aggregator ID: 15
Number of ports: 2
Actor Key: 9
Partner Key: 55
Partner Mac Address: a0:21:b7:9d:83:6a
Slave Interface: eno1
MII Status: up
Speed: 1000 Mbps
Duplex: full
Link Failure Count: 0
Permanent HW addr: ac:1f:6b:dc:2e:88
Slave queue ID: 0
Aggregator ID: 15
Actor Churn State: none
Partner Churn State: none
Actor Churned Count: 0
Partner Churned Count: 0
details actor lacp pdu:
system priority: 65535
system mac address: ac:1f:6b:dc:2e:88
port key: 9
port priority: 255
port number: 1
port state: 63
details partner lacp pdu:
system priority: 1
system mac address: a0:21:b7:9d:83:6a
oper key: 55
port priority: 128
port number: 8
port state: 61
Slave Interface: eno2
MII Status: up
Speed: 1000 Mbps
Duplex: full
Link Failure Count: 0
Permanent HW addr: ac:1f:6b:dc:2e:89
Slave queue ID: 0
Aggregator ID: 15
Actor Churn State: none
Partner Churn State: none
Actor Churned Count: 0
Partner Churned Count: 0
details actor lacp pdu:
system priority: 65535
system mac address: ac:1f:6b:dc:2e:88
port key: 9
port priority: 255
port number: 2
port state: 63
details partner lacp pdu:
system priority: 1
system mac address: a0:21:b7:9d:83:6a
oper key: 55
port priority: 128
port number: 7
port state: 61
如果我理解正確的話，這意味著 Linux 綁定驅動程式正確地確定了所有聚合器詳細資訊（金鑰、連接埠號碼、系統優先權、連接埠優先權等）。儘管如此，在重新啟動網路服務後，我在 dmesg 中收到了此訊息：
[Dec14 20:40] bond0: Releasing backup interface eno1
[ +0.000004] bond0: first active interface up!
[ +0.090621] bond0: Removing an active aggregator
[ +0.000004] bond0: Releasing backup interface eno2
[ +0.118446] bond0: Enslaving eno1 as a backup interface with a down link
[ +0.027888] bond0: Enslaving eno2 as a backup interface with a down link
[ +0.008805] IPv6: ADDRCONF(NETDEV_UP): bond0: link is not ready
[ +3.546823] igb 0000:04:00.0 eno1: igb: eno1 NIC Link is Up 1000 Mbps Full Duplex, Flow Control: RX
[ +0.160003] igb 0000:05:00.0 eno2: igb: eno2 NIC Link is Up 1000 Mbps Full Duplex, Flow Control: RX
[ +0.035608] bond0: link status definitely up for interface eno1, 1000 Mbps full duplex
[ +0.000004] bond0: Warning: No 802.3ad response from the link partner for any adapters in the bond
[ +0.000008] bond0: first active interface up!
[ +0.000166] IPv6: ADDRCONF(NETDEV_CHANGE): bond0: link becomes ready
[ +0.103821] bond0: link status definitely up for interface eno2, 1000 Mbps full duplex
兩個介面都處於活動狀態，網路連線似乎很正常，我只是收到一個奇怪的警告，提示沒有 802.3ad 相容夥伴。
此外，當我嘗試從連接到同一交換器的兩台不同機器（每台連接速度為1Gbps）同時複製兩個大型二進位（每個10GB）時，伺服器上bond0 介面的總體吞吐量遠低於1Gbps，儘管我期望接近 2 Gbps（讀取速度等不是這裡的限制因素，所有 SSD，快取良好等）。當我從同一台機器上依次複製相同的檔案時，我可以輕鬆達到接近 1Gbps 的吞吐量。
請問您知道這裡可能出了什麼問題嗎？關於診斷，令人困惑的警告出現在 dmesg（無 802.3ad 相容夥伴）和交換器的 sh lacp 輸出中（無夥伴的 MAC，儘管常規連接埠記錄顯示所連接 NIC 的正確 MAC 位址）。關於網路效能，我確實看不到使用兩個不同連接的任何聚合。我將非常感謝任何提示。
答案1
交換器配置為longLACP 逾時 - 每 30 秒一個 LACPDU。
Linux 系統配置為bond-lacp-rate 1.
我找不到這在 Debian 中實際做了什麼，但如果它將lacp_rate=1模組選項傳遞給bonding（參考），那麼這就是快速超時 - 每 1 秒一個 LACPDU。
慢/快 LACP 速率之間的這種不匹配是一種錯誤配置。
我能找到的所有範例文件都表明 Debian 接受，bond-lacp-rate slow這有望為您糾正它。
您也可以bond-lacp-rate從設定檔中刪除該行，因為預設速率較慢，然後卸載綁定模組或重新啟動以套用。
不要僅使用兩個流來測試吞吐量。此layer3+4策略不保證任何兩個流都有一個單獨的 NIC，只是在給定足夠的流的情況下，流量應該稍微均衡。
使用 16 或 32 個同時 iperf3 TCP 流進行測試。所有串流的總吞吐量應接近 2Gbps。
