我正在嘗試使用 ipv6 將發起方連接到回應方
兩者都已打開Ubuntu 20.04，並且strongswan 5.9.0
啟動器位於連接到我的 ISP 網路的盒子後面的個人電腦上的虛擬機器（使用 VMware）上。虛擬機器與主機使用NAT網路回應者是在線VPS
發起者獲得了 ipv6（他的主機的）並且可以 ping 回應者 ipv6。它的 ipv6 是<initiator_ipv6>
響應者 ipv6 似乎配置正確，我可以使用它 ping 和 ssh。它的ipv6是<responder_ipv6>
IPv6 已使用以下設定啟動（由我的 VPS 提供者提供）
/etc/netplan/51-ipv6.yaml
network:
version: 2
ethernets:
<responder_interface>:
dhcp4: true
dhcp6: false
match:
name: <responder_interface>
addresses:
- <responder_ipv6>/128
gateway6: <responder_ipv6_gateway>
routes:
- to: <responder_ipv6_gateway>
scope: link
兩個 Strongswan 都是使用以下指令在啟動器上建構的：
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run
make
make install
它們具有相同的strongswan.conf，這主要是預設的，帶有文件日誌選項，以便於調試
charon {
load_modular = yes
plugins {
include strongswan.d/charon/*.conf
}
filelog {
logger {
path = <custom_dir>/swanctl.log
time_format = %b %e %T
ike_name = yes
default = 1
flush_line = yes
}
}
}
include strongswan.d/*.conf
響應者有以下 swanctl.conf
connections {
# Seems to change nothing
local_addrs = <responder_ipv6>
pubkey-vm {
pools = primary-pool-ipv4, primary-pool-ipv6
local {
auth = pubkey
certs = <responder_cert>
id = <responder_id>
}
remote {
auth = pubkey
id = <initiator_id>
}
children {
client {
}
}
}
}
pools {
primary-pool-ipv4 {
# Totally arbitrary value
addrs = 10.0.0.0/24
}
primary-pool-ipv6 {
# Totally arbitrary value
addrs = 2620:0:2d0:200::7/97
}
}
發起者有以下配置
connections {
initiator-to-host {
remote_addrs = <responder_ip>
# Any value works, at long as vips got a value (but assigned ip will be in the respodner pool)
vips = 1.2.3.4
local {
auth = pubkey
certs = <initator_cert>
id = <initiator_id>
}
remote {
auth = pubkey
id = <responder_id>
}
children {
to-host {
start_action = none
}
}
}
}
當我嘗試使用響應者 ipv4 進行連線時，它可以正常工作並且啟動成功完成。當我將 ip 切換到 ipv6 時，它不起作用，並且我在響應器上收到以下日誌
<pubkey-vm|4> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (80 bytes)
<pubkey-vm|4> parsed INFORMATIONAL request 2 [ D ]
<pubkey-vm|4> received DELETE for IKE_SA pubkey-vm[4]
<pubkey-vm|4> deleting IKE_SA pubkey-vm[4] between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|4> IKE_SA deleted
<pubkey-vm|4> generating INFORMATIONAL response 2 [ ]
<pubkey-vm|4> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (80 bytes)
<pubkey-vm|4> lease 10.0.0.1 by '<initiator_id>' went offline
<5> received packet: from <initiator_ipv6>[1016] to <responder_ipv6>[500] (392 bytes)
<5> parsed IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<5> <initiator_ipv6> is initiating an IKE_SA
<5> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<5> remote host is behind NAT
<5> sending cert request for "C=FR, O=Test, CN=Test CA"
<5> generating IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<5> sending packet: from <responder_ipv6>[500] to <initiator_ipv6>[1016] (273 bytes)
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (356 bytes)
<5> parsed IKE_AUTH request 1 [ EF(2/2) ]
<5> received fragment #2 of 2, waiting for complete IKE message
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (1220 bytes)
<5> parsed IKE_AUTH request 1 [ EF(1/2) ]
<5> received fragment #1 of 2, reassembled fragmented IKE message (1504 bytes)
<5> parsed IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<5> received cert request for "C=FR, O=Test, CN=Test CA"
<5> received end entity cert "C=FR, O=Test, CN=<initiator_id>"
<5> looking for peer configs matching <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> selected peer config 'pubkey-vm'
<pubkey-vm|5> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<pubkey-vm|5> checking certificate status of "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> certificate status is not available
<pubkey-vm|5> reached self-signed root ca with a path length of 0
<pubkey-vm|5> using trusted certificate "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> authentication of '<initiator_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> peer supports MOBIKE
<pubkey-vm|5> authentication of '<responder_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> IKE_SA pubkey-vm[5] established between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> scheduling rekeying in 14286s
<pubkey-vm|5> maximum IKE_SA lifetime 15726s
<pubkey-vm|5> sending end entity cert "C=FR, O=Test, CN=<responder_id>"
<pubkey-vm|5> peer requested virtual IP 1.2.3.4
<pubkey-vm|5> reassigning offline lease to '<initiator_id>'
<pubkey-vm|5> assigning virtual IP 10.0.0.1 to peer '<initiator_id>'
<pubkey-vm|5> selected proposal: ESP:AES_GCM_16_128
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI cffdef3f (FAILED)
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI c028512b (FAILED)
<pubkey-vm|5> unable to install inbound and outbound IPsec SA (SAD) in kernel
<pubkey-vm|5> failed to establish CHILD_SA, keeping IKE_SA
<pubkey-vm|5> generating IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<pubkey-vm|5> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (1216 bytes)
客戶端日誌在這裡
Starting IKE charon daemon (strongSwan 5.9.0, Linux 5.4.0-56-generic, x86_64)
loading ca certificates from '<custom_path>/etc/ipsec.d/cacerts'
loading aa certificates from '<custom_path>/etc/ipsec.d/aacerts'
loading ocsp signer certificates from '<custom_path>/etc/ipsec.d/ocspcerts'
loading attribute certificates from '<custom_path>/etc/ipsec.d/acerts'
loading crls from '<custom_path>/etc/ipsec.d/crls'
loading secrets from '<custom_path>/etc/ipsec.secrets'
loaded plugins: charon aes eap-aka eap-dynamic eap-identity eap-sim eap-tls des rc2 sha2 sha1 md5 mgf1 random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem fips-prf gmp curve25519 xcbc cmac hmac drbg attr kernel-netlink resolve socket-default stroke vici updown xauth-generic counters
spawning 16 worker threads
loaded certificate 'C=FR, O=Test, CN=<responder_id>'
loaded certificate 'C=FR, O=Test, CN=<initiator_id>'
loaded certificate 'C=FR, O=Test, CN=Test CA'
loaded RSA private key
loaded RSA private key
added vici connection: host-host
vici initiate CHILD_SA 'to-host'
<host-host|1> initiating IKE_SA host-host[1] to <responder_ipv6>
<host-host|1> generating IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<host-host|1> sending packet: from <initiator_ipv6>[500] to <responder_ipv6>[500] (392 bytes)
<host-host|1> received packet: from <responder_ipv6>[500] to <initiator_ipv6>[500] (273 bytes)
<host-host|1> parsed IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<host-host|1> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<host-host|1> local host is behind NAT, sending keep alives
<host-host|1> received cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> sending cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> authentication of '<initiator_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> sending end entity cert "C=FR, O=Test, CN=<initiator_id>"
<host-host|1> establishing CHILD_SA to-host{1}
<host-host|1> generating IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<host-host|1> splitting IKE message (1504 bytes) into 2 fragments
<host-host|1> generating IKE_AUTH request 1 [ EF(1/2) ]
<host-host|1> generating IKE_AUTH request 1 [ EF(2/2) ]
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (1220 bytes)
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (356 bytes)
<host-host|1> received packet: from <responder_ipv6>[4500] to <initiator_ipv6>[4500] (1216 bytes)
<host-host|1> parsed IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<host-host|1> received end entity cert "C=FR, O=Test, CN=<responder_id>"
<host-host|1> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<host-host|1> checking certificate status of "C=FR, O=Test, CN=<responder_id>"
<host-host|1> certificate status is not available
<host-host|1> reached self-signed root ca with a path length of 0
<host-host|1> using trusted certificate "C=FR, O=Test, CN=<responder_id>"
<host-host|1> authentication of '<responder_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> IKE_SA host-host[1] established between <initiator_ipv6>[<initiator_id>]...<responder_ipv6>[<responder_id>]
<host-host|1> scheduling rekeying in 13877s
<host-host|1> maximum IKE_SA lifetime 15317s
<host-host|1> installing new virtual IP 10.0.0.1
<host-host|1> received NO_PROPOSAL_CHOSEN notify, no CHILD_SA built
<host-host|1> failed to establish CHILD_SA, keeping IKE_SA
<host-host|1> peer supports MOBIKE
關於如何解決這個問題有什麼想法嗎？
--enable-kernel-libipsec我嘗試了使用配置選項的解決方案。所以現在我得到了
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run --enable-kernel-libipsec
發起者端日誌保持不變，但我在下面得到了新的響應者端日誌
[CFG] <pubkey-vm|1> selected proposal: ESP:AES_GCM_16_128
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[IKE] <pubkey-vm|1> unable to install inbound and outbound IPsec SA (SAD) in kernel
[IKE] <pubkey-vm|1> failed to establish CHILD_SA, keeping IKE_SA
答案1
如果您的主機之間存在 NAT，如對等方在此處偵測到的：
<5> remote host is behind NAT
和
<host-host|1> local host is behind NAT, sending keep alives
將為 IPsec SA（NAT 遍歷）啟用 ESP 的 UDP 封裝。然而，這需要 IPsec 堆疊的支持，Linux 從 5.8 版本起才為 IPv6 提供支援。因此對於較舊的內核，這是行不通的。
您必須使用更新的核心、刪除 NAT、返回使用 IPv4，或使用替代的 IPsec 堆疊（例如 StrongSwan 自己的libipsec）。
