嘗試應用 Calico 節點配置時如何修復「無法套用「節點」資源：[更新衝突：節點（...）]」？

tag-icon • tag-icon networking kubernetes calico
嘗試應用 Calico 節點配置時如何修復「無法套用「節點」資源：[更新衝突：節點（...）]」？

我正在使用 Kubernetes，並獲得了兩台 VirtualBox 機器——主機器和工作機器。每個都有兩個網路介面 - 一個用於互聯網，另一個用於虛擬機器和主機之間的通訊。我在設定 Calico 時遇到了麻煩，因為它會自動偵測到錯誤的網路介面。我做了一些設定來修復它，但仍然存在一個問題 - 工作人員獲取了錯誤的 IP。我找到了修復它的方法 - 但它不起作用。詳細資訊如下。

目前的工作配置是（10.0.3.15那些「錯誤」的IP）：

[12:35]user@ubuntu-vbox-k8s-master[~]$ ./calicoctl get node ubuntu-vbox-k8s-worker -o yaml
apiVersion: projectcalico.org/v3
kind: Node
metadata:
  annotations:
    projectcalico.org/kube-labels: '{"beta.kubernetes.io/arch":"amd64","beta.kubernetes.io/os":"linux","kubernetes.io/arch":"amd64","kubernetes.io/hostname":"ubuntu-vbox-k8s-worker","kubernetes.io/os":"linux"}'
  creationTimestamp: "2021-09-26T10:59:00Z"
  labels:
    beta.kubernetes.io/arch: amd64
    beta.kubernetes.io/os: linux
    kubernetes.io/arch: amd64
    kubernetes.io/hostname: ubuntu-vbox-k8s-worker
    kubernetes.io/os: linux
  name: ubuntu-vbox-k8s-worker
  resourceVersion: "9219"
  uid: 6f5efd41-e06c-4f9d-9b3a-248af88a385e
spec:
  addresses:
  - address: 10.0.3.15/24
    type: CalicoNodeIP
  - address: 10.0.3.15
    type: InternalIP
  bgp:
    ipv4Address: 10.0.3.15/24
    ipv4IPIPTunnelAddr: 192.168.77.64
  orchRefs:
  - nodeName: ubuntu-vbox-k8s-worker
    orchestrator: k8s
status: {}

我嘗試應用固定的一個：

[12:37]user@ubuntu-vbox-k8s-master[~]$ cat calico-worker.yaml
apiVersion: projectcalico.org/v3
kind: Node
metadata:
  annotations:
    projectcalico.org/kube-labels: '{"beta.kubernetes.io/arch":"amd64","beta.kubernetes.io/os":"linux","kubernetes.io/arch":"amd64","kubernetes.io/hostname":"ubuntu-vbox-k8s-worker","kubernetes.io/os":"linux"}'
  creationTimestamp: "2021-09-26T10:59:00Z"
  labels:
    beta.kubernetes.io/arch: amd64
    beta.kubernetes.io/os: linux
    kubernetes.io/arch: amd64
    kubernetes.io/hostname: ubuntu-vbox-k8s-worker
    kubernetes.io/os: linux
  name: ubuntu-vbox-k8s-worker
  resourceVersion: "5303"
  uid: 6f5efd41-e06c-4f9d-9b3a-248af88a385e
spec:
  addresses:
  - address: 192.168.56.109
    type: InternalIP
  orchRefs:
  - nodeName: ubuntu-vbox-k8s-worker
    orchestrator: k8s
status: {}

並得到錯誤：

[12:38]user@ubuntu-vbox-k8s-master[~]$ ./calicoctl apply -f calico-worker.yaml
Failed to apply 'Node' resource: [update conflict: Node(ubuntu-vbox-k8s-worker)]

這很奇怪，因為我成功地以相同的方式修復了 Calico 主節點，並且沒有與配置衝突：

apiVersion: projectcalico.org/v3
kind: Node
metadata:
  annotations:
    projectcalico.org/kube-labels: '{"beta.kubernetes.io/arch":"amd64","beta.kubernetes.io/os":"linux","kubernetes.io/arch":"amd64","kubernetes.io/hostname":"ubuntu-vbox-k8s-master","kubernetes.io/os":"linux","node-role.kubernetes.io/control-plane":"","node-role.kubernetes.io/master":"","node.kubernetes.io/exclude-from-external-load-balancers":""}'
  creationTimestamp: "2021-09-26T10:56:24Z"
  labels:
    beta.kubernetes.io/arch: amd64
    beta.kubernetes.io/os: linux
    kubernetes.io/arch: amd64
    kubernetes.io/hostname: ubuntu-vbox-k8s-master
    kubernetes.io/os: linux
    node-role.kubernetes.io/control-plane: ""
    node-role.kubernetes.io/master: ""
    node.kubernetes.io/exclude-from-external-load-balancers: ""
  name: ubuntu-vbox-k8s-master
  resourceVersion: "9052"
  uid: 9e6d55c6-f449-4ded-ab47-ea9d889d6b43
spec:
  addresses:
  - address: 192.168.56.108
    type: InternalIP
  bgp:
    ipv4IPIPTunnelAddr: 192.168.77.0
  orchRefs:
  - nodeName: ubuntu-vbox-k8s-master
    orchestrator: k8s
status:
  podCIDRs:
  - 192.168.77.0/24

答案1

在 Calico Slack 頻道的幫助下透過指令kubectl set env daemonset/calico-node -n kube-system IP_AUTODETECTION_METHOD=interface=enp0s3解決https://docs.projectcalico.org/networking/ip-autodetection
