無法透過 SSH 存取 Terraform 建立的 EC2 執行個體

tag-icon • tag-icon amazon-web-services terraform
無法透過 SSH 存取 Terraform 建立的 EC2 執行個體

在 Ubuntu 18.04 上使用 Terraform v1.0.11

在terraform apply執行以下操作後main.tf，並等待實例通過檢查（然後再過一分鐘），嘗試 SSH 就會遇到困難。

$ ssh -v -i ~/.ssh/toydeploy.pem [email protected]
OpenSSH_7.6p1 Ubuntu-4ubuntu0.5, OpenSSL 1.0.2n  7 Dec 2017
debug1: Reading configuration data /etc/ssh/ssh_config
debug1: /etc/ssh/ssh_config line 19: Applying options for *
debug1: Connecting to 18.144.125.224 [18.144.125.224] port 22.
debug1: connect to address 18.144.125.224 port 22: Connection timed out
ssh: connect to host 18.144.125.224 port 22: Connection timed out

我已經使用相同的 AMI 和金鑰對手動啟動了一個實例，並且可以透過 SSH 登入。 DNS 名稱”對於手動部署的執行個體顯示“IPv4 (A)”，對於Terraformed 實例顯示“-”。兩者看起來都是良性的，但我可能是錯的。

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 3.27"
    }
  }
}

provider "aws" {
  profile = "default"
  region  = "us-west-1"
}

variable "cidr_vpc" {
  description = "CIDR block for VPC"
  default     = "10.1.0.0/16"
}

variable "cidr_subnet" {
  description = "CIDR block for subnet"
  default     = "10.1.0.0/20"
}

resource "aws_vpc" "toydeploy-vpc" {
  cidr_block           = var.cidr_vpc
  enable_dns_hostnames = true
  enable_dns_support   = true
}

resource "aws_subnet" "toydeploy-subnet" {
  vpc_id     = aws_vpc.toydeploy-vpc.id
  cidr_block = var.cidr_subnet
}

resource "aws_security_group" "toydeploy-sg" {
  name   = "toydeploy-sg"
  vpc_id = aws_vpc.toydeploy-vpc.id

  ingress {
    from_port = 22
    to_port   = 22
    protocol  = "tcp"
    cidr_blocks = [
      "0.0.0.0/0"
    ]
  }

  # Terraform removes the default rule, so we re-add it.
  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

resource "aws_instance" "toydeploy" {
  ami                         = "ami-083f68207d3376798" # Ubuntu 18.04
  instance_type               = "t2.micro"
  security_groups             = ["${aws_security_group.toydeploy-sg.id}"]
  subnet_id                   = aws_subnet.toydeploy-subnet.id
  associate_public_ip_address = true
  key_name                    = "toydeploy"
}

如果下面沒有任何問題，並且您可以向我指出一個有效的範例，那麼我也將不勝感激。

解決

仔細檢查發現路由表只是子網路的路由，而不是 0.0.0.0/0。添加以下內容解決了該問題。

resource "aws_internet_gateway" "toydeploy-ig" {
  vpc_id = aws_vpc.toydeploy-vpc.id
}

resource "aws_route_table" "toydeploy-rt" {
  vpc_id = aws_vpc.toydeploy-vpc.id
  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.toydeploy-ig.id
  }
}

resource "aws_route_table_association" "toydeploy-rta" {
  subnet_id      = aws_subnet.toydeploy-subnet.id
  route_table_id = aws_route_table.toydeploy-rt.id
}

答案1

連線逾時通常表示網路問題。查看：

  • 安全群組/NACL 在連接埠 22 上向您的 IP 開放
  • VPC有網路網關
  • 子網路有一條到網際網路閘道的路由
  • 實例有公網IP
  • 路由設定正確

這是您連接嘗試中的關鍵行，它告訴您發生了什麼

ssh: connect to host 18.144.125.224 port 22: Connection timed out
