我正在嘗試採用有狀態的 k8s PostgreSQL 集群基於這篇文章適應我公司的當地環境。
編輯
這是一個 vmware tanzu 集群，我自己沒有設定過，所以我沒有關於集群本身本質的更多細節。我新增了一個我引用的 StorageClass
> kubectl version
Client Version: version.Info{Major:"1", Minor:"20", GitVersion:"v1.20.8", GitCommit:"5575935422cc1cf5169dfc8847cb587aa47bac5a", GitTreeState:"clean", BuildDate:"2021-06-16T13:00:45Z", GoVersion:"go1.15.13", Compiler:"gc", Platform:"linux/amd64"}
Server Version: version.Info{Major:"1", Minor:"20", GitVersion:"v1.20.8+vmware.1", GitCommit:"3e397df2f5dadadfa35958ec45c14b0e81abc25f", GitTreeState:"clean", BuildDate:"2021-06-21T16:59:40Z", GoVersion:"go1.15.13", Compiler:"gc", Platform:"linux/amd64"}
PostgreSQL 以 postgres 使用者身分運行，而不是 root。這可能是我的問題的一部分。
結束編輯
有一個自訂 PostgreSQL 映像，它安裝了 3 個磁碟區作為
/opt/db/data/postgres/data/opt/db/backup/postgres/backups/opt/db/backup/postgres/archives
當在叢集上套用這些檔案（按照下面列出的順序）時，postgres pod 不會啟動，且日誌會報告存取權限問題。
> kcl logs pod/postgres-stateful-0
starting up postgres docker image:
postgres -D /opt/db/data/postgres/data
+ echo 'starting up postgres docker image:'
+ echo postgres -D /opt/db/data/postgres/data
+ '[' '!' -d /opt/db/data/postgres/data ']'
+ '[' '!' -O /opt/db/data/postgres/data ']'
+ mkdir -p /opt/db/data/postgres/data
+ chmod 700 /opt/db/data/postgres/data
chmod: changing permissions of '/opt/db/data/postgres/data': Operation not permitted
這源於docker-entrypoint.sh在容器創建時運行。
這個腳本檢查 $PGDATA 目錄 (/opt/db/data/postgres/data) 是否存在以及它是否屬於 postgres 使用者。實際上Dockerfile從自訂映像正確建立此內容，因此應跳過mkdir和chmod操作並應啟動容器。
當您僅基於該映像運行單一 Pod 時，這會起作用。
所以我猜測在容器內安裝磁碟區會以某種方式混淆所有權，我想知道如何解決這個問題，或者換句話說，owner為要建立的容器內的安裝路徑定義和存取權限。
有人能指出我如何解決這個問題的正確方向嗎？我甚至不能說是statefulset.yml還是storage.yaml需要調整
形象創作
ARG REGISTRY=docker-dev-local.intern.net
ARG BASE_IMAGE_REPO=scm
ARG BASE_IMAGE_NAME=debian-bullseye
ARG BASE_IMAGE_TAG=latest
# Second stage - create runtime image
# -----------------------------------
#FROM debian:11 as base
#FROM docker-dev-local.intern.net/scm/debian-bullseye:build-74 as base
FROM $REGISTRY/$BASE_IMAGE_REPO/$BASE_IMAGE_NAME:$BASE_IMAGE_TAG
# Maintainer
# ----------
LABEL org.opencontainers.image.authors="<[email protected]>"
# Build Environment variables, change as needed
# -------------------------------------------------------------
ARG PG_MAJOR=14
ARG PG_VERSION=14.1
ARG DIST_VERSION=deb11
ARG DVZ_BUILD=dvz1
ENV DVZ_REPO_URL=http://dvzsn-rd1115.dbmon.rz-dvz.cn-mv.de/scb-repo
# Environment variables required for this build (do NOT change)
# -------------------------------------------------------------
ENV PG_MAJOR=${PG_MAJOR}
ENV PG_VERSION=${PG_VERSION}
ENV PGUSER=postgres
ENV PGDATABASE=postgres
ENV PGPORT=5432
ENV DBBASE=/opt/db
ENV PGBASE=$DBBASE/postgres
ENV PGBIN=$PGBASE/bin
ENV PGHOME=$PGBASE/postgresql
ENV PGDATA=$DBBASE/data/postgres/data
ENV PGLOG=$PGDATA/log
ENV PGBACK=$DBBASE/backup/postgres/backups
ENV PGARCH=$DBBASE/backup/postgres/archives
ENV PATH=$PGHOME/bin:$PATH
ENV LANG=de_DE.UTF-8
ENV LC_MESSAGES=en_US.UTF-8
ENV TZ=Europe/Berlin
RUN env | sort
# Install additional packages and dependencies
# --------------------------------------------
RUN set -ex; \
apt-get update && \
apt-get upgrade && \
apt-get install -y --no-install-recommends \
ca-certificates \
curl \
dirmngr \
gnupg \
iproute2 \
less \
libnss-wrapper \
libpam0g \
libreadline8 \
libselinux1 \
libsystemd0 \
libxml2 \
locales \
openssl \
procps \
vim-tiny \
wget \
xz-utils \
zlib1g \
&& \
apt-get clean
# create locales for en_US and de_DE
RUN localedef -i en_US -f UTF-8 en_US.UTF-8 && \
localedef -i de_DE -f UTF-8 de_DE.UTF-8 && \
locale -a
# Set up user and directories
# ---------------------------
RUN mkdir -p $PGBASE $PGBIN $PGDATA $PGBACK $PGARCH && \
useradd -d /home/postgres -m -s /bin/bash --no-log-init postgres && \
chown -R postgres:postgres $PGBASE $PGDATA $PGBACK $PGARCH $DBBASE/data && \
chmod a+xr $PGBASE
# set up user env
# ---------------
USER postgres
COPY --chown=postgres:postgres ["files/.alias", "files/.bashrc", "files/postgresql.conf.${PG_MAJOR}", "files/conf.d/00-ina-default.conf", "/hom
COPY ["files/docker-entrypoint.sh", "/"]
ADD ["files/pg-docker-env.tar.gz", "$PGBASE/"]
# install postgres
# --------------------
# copy postgres package from builder stage
#RUN mkdir -p $PGBASE/postgresql-$PG_VERSION-$DIST_VERSION-$DVZ_BUILD
#COPY --from=build --chown=postgres:postgres ["$PGBASE/postgresql-$PG_VERSION-$DIST_VERSION-$DVZ_BUILD", "$PGBASE/postgresql-$PG_VERSION-$DIST_
# download build of postgres
WORKDIR $PGBASE
RUN curl -sSL $DVZ_REPO_URL/postgres/Linux/$DIST_VERSION/postgresql-$PG_VERSION-$DIST_VERSION-dvz1.tar.gz | tar xzf - -C $PGBASE
RUN ln -s $PGBASE/postgresql-$PG_VERSION-$DIST_VERSION-$DVZ_BUILD postgresql
# bindings
# --------
VOLUME ["$PGDATA", "$PGBACK", "$PGARCH"]
STOPSIGNAL SIGINT
EXPOSE 5432
HEALTHCHECK --interval=1m --start-period=5m \
CMD pg_ctl status >/dev/null || exit 1
# Define default command to start Database.
ENTRYPOINT ["/docker-entrypoint.sh"]
CMD ["postgres", "-D", "/opt/db/data/postgres/data"]
#!/bin/bash
set -xeEuo pipefail
echo "starting up postgres docker image:"
echo "$@"
# check PGDATA directory and create if necessary
if [ \! -d $PGDATA ] || [ \! -O $PGDATA ]
then
mkdir -p $PGDATA
chmod 700 $PGDATA
fi
# check database cluster in PGDATA directory and create new db cluster if necessary
if [ \! -s $PGDATA/PG_VERSION ] || ! pg_controldata
then
POSTGRES_PASSWORD=${POSTGRES_PASSWORD:-"Start1234"}
initdb -D $PGDATA --locale=de_DE.UTF-8 --lc-messages=en_US.UTF-8 --auth-local=trust --auth-host=md5 --pwfile=<(echo "$POSTGRES_PASSWORD")
mv $PGDATA/postgresql.conf $PGDATA/postgresql.conf.orig
cp ~/postgresql.conf.${PG_MAJOR} $PGDATA/postgresql.conf
mkdir -p $PGDATA/conf.d
cp ~/00-ina-default.conf $PGDATA/conf.d/
{
echo "# allow connections via docker gateway or bridge"
echo "host all all 172.16.0.0/14 md5"
} >> "$PGDATA/pg_hba.conf"
fi
# show PGDATA version and controldata
echo "PGDATA/PGVERSION=`cat $PGDATA/PG_VERSION`"
# start postgres rdbms now
exec "$@"
Kubernetes 聲明
kind: PersistentVolume
apiVersion: v1
metadata:
name: postgres-pgdata33
labels:
app: postgres
type: local
spec:
storageClassName: ina01
capacity:
storage: 1Gi
accessModes:
- ReadWriteOnce
hostPath:
path: "/var/data"
---
kind: PersistentVolume
apiVersion: v1
metadata:
name: postgres-pgbackup33
labels:
app: postgres
type: local
spec:
storageClassName: ina01
capacity:
storage: 1Gi
accessModes:
- ReadWriteOnce
hostPath: path: "/var/data"
---
kind: PersistentVolume
apiVersion: v1
metadata:
name: postgres-pgarch33
labels:
app: postgres
type: local
spec:
storageClassName: ina01
capacity:
storage: 1Gi
accessModes:
- ReadWriteOnce
hostPath:
path: "/var/data"
# #####################################################################################
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: pgdata33-pvc
labels:
app: postgres
spec:
storageClassName: ina01
capacity:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 1Gi
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: pgbackup33-pvc
labels:
app: postgres
spec:
storageClassName: ina01
capacity:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 1Gi
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: pgarch33-pvc
labels:
app: postgres
spec:
storageClassName: ina01
capacity:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 1Gi
apiVersion: v1
kind: ConfigMap
metadata:
name: postgres-configuration
labels:
app: postgres
data:
POSTGRES_DB: awesomedb
POSTGRES_USER: amazinguser
POSTGRES_PASSWORD: perfectpassword
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: postgres-stateful
labels:
app: postgres
spec:
serviceName: "postgres"
replicas: 1
selector:
matchLabels:
app: postgres
template:
metadata:
labels:
app: postgres
spec:
containers:
- name: postgres
image: docker-dev-local.intern.net/ina/postgresql:14.1-scm-debian-bullseye-build-74-4
envFrom:
- configMapRef:
name: postgres-configuration
ports:
- containerPort: 5432
name: postgresdb
volumeMounts:
- name: pv-data
mountPath: /opt/db/data/postgres/data # /var/lib/postgresql/data
- name: pv-backup
mountPath: /opt/db/backup/postgres
- name: pv-arch
mountPath: /opt/db/backup/postgres/arch
securityContext:
runAsUser: 1000
runAsGroup: 1000
fsGroup: 1000
volumes:
- name: pv-data
persistentVolumeClaim:
claimName: pgdata33-pvc
- name: pv-backup
persistentVolumeClaim:
claimName: pgbackup33-pvc
- name: pv-arch
persistentVolumeClaim:
claimName: pgarch33-pvc
apiVersion: v1
kind: Service
metadata:
name: postgres-service
labels:
app: postgres
spec:
ports:
- port: 5432
name: postgres
type: NodePort
selector:
app: postgres
