使用 Nginx 反向代理 React App 不顯示 /swagger ； /redoc

tag-icon • tag-icon nginx proxy
使用 Nginx 反向代理 React App 不顯示 /swagger ； /redoc

所以我一直在嘗試設定 Swagger 在 /swagger/ 上工作，它工作正常，直到我們切換到網域。我對 nginx 不太有經驗，它是反向代理。如果有人可以提供幫助，我將分享我的設定。它實際上打開了頁面，但它是白色的，與 /redoc/ (Redis) 相同。

Nginx.conf

events {
worker_connections 768;
multi_accept       on;
}

http {

large_client_header_buffers 16 5120k;
fastcgi_read_timeout 900;
proxy_read_timeout 900;
proxy_connect_timeout 900;
proxy_send_timeout 900;

sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
server_tokens off;

proxy_buffer_size   128k;
proxy_buffers   4 256k;
proxy_busy_buffers_size   256k;

include /etc/nginx/mime.types;
default_type application/octet-stream;

ssl_protocols TLSv1 TLSv1.1 TLSv1.2 TLSv1.3;
ssl_prefer_server_ciphers on;

access_log /var/log/nginx/access.log;
error_log /var/log/nginx/error.log;

gzip on;

proxy_http_version      1.1;
proxy_set_header        Upgrade $http_upgrade;
proxy_set_header        Connection "upgrade";
proxy_set_header        X-Real-IP $remote_addr;
proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header        X-Forwarded-Proto $scheme;
proxy_set_header        Host $http_host;
proxy_intercept_errors  on;

server {

    client_max_body_size 250M;
    listen 80;
    server_name mysite.com;

    location /.well-known/acme-challenge/ {
        root /var/www/certbot;
    }

        location / {
            return 301 https://$host$request_uri;
    }
}

server {

    client_max_body_size 250M;
    listen 443 ssl;
    server_name mysite.com;

    ssl_certificate /etc/letsencrypt/live/mysite.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/mysite.com/privkey.pem;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        proxy_pass http://mysite:3000/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

    location /ht/ {
        proxy_pass http://mysite:8000/ht/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

    location /swagger/ {
        proxy_pass http://mysite:8000/swagger/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

例如，/ht/（健康檢查）運作良好

後端的 urls.py:

urlpatterns = [
url(r'^swagger/$', schema_view.with_ui('swagger', cache_timeout=0), name='schema-
swagger-ui')]

如果您需要任何其他文件，請告訴我，我願意分享它們，我只是用 mysite.com 等虛擬數據替換敏感數據

先致謝！

編輯：我剛剛注意到，在“網絡”選項卡中，它為所有CSS、JS 文件顯示“需要啟用Javascript 才能運行此應用程式”，/redoc 也是如此，控制台日誌也會拋出此錯誤：“未捕獲的語法錯誤：意外的錯誤” JS 檔案的標記“<”。

我忘記指出它是一個 React 應用程序，但應用程式本身運作良好。後端是 Python/Django 所以我一直在嘗試設定 Swagger 在 /swagger/ 上工作，它工作正常，直到我們切換到網域。我對 nginx 不太有經驗，它是反向代理。如果有人可以提供幫助，我將分享我的設定。它實際上打開了頁面，但它是白色的，與 /redoc/ (Redis) 相同。

Nginx.conf

events {
worker_connections 768;
multi_accept       on;
}

http {

large_client_header_buffers 16 5120k;
fastcgi_read_timeout 900;
proxy_read_timeout 900;
proxy_connect_timeout 900;
proxy_send_timeout 900;

sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
server_tokens off;

proxy_buffer_size   128k;
proxy_buffers   4 256k;
proxy_busy_buffers_size   256k;

include /etc/nginx/mime.types;
default_type application/octet-stream;

ssl_protocols TLSv1 TLSv1.1 TLSv1.2 TLSv1.3;
ssl_prefer_server_ciphers on;

access_log /var/log/nginx/access.log;
error_log /var/log/nginx/error.log;

gzip on;

proxy_http_version      1.1;
proxy_set_header        Upgrade $http_upgrade;
proxy_set_header        Connection "upgrade";
proxy_set_header        X-Real-IP $remote_addr;
proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header        X-Forwarded-Proto $scheme;
proxy_set_header        Host $http_host;
proxy_intercept_errors  on;

server {

    client_max_body_size 250M;
    listen 80;
    server_name mysite.com;

    location /.well-known/acme-challenge/ {
        root /var/www/certbot;
    }

        location / {
            return 301 https://$host$request_uri;
    }
}

server {

    client_max_body_size 250M;
    listen 443 ssl;
    server_name mysite.com;

    ssl_certificate /etc/letsencrypt/live/mysite.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/mysite.com/privkey.pem;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        proxy_pass http://mysite:3000/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

    location /ht/ {
        proxy_pass http://mysite:8000/ht/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

    location /swagger/ {
        proxy_pass http://mysite:8000/swagger/;
        proxy_redirect off;
        proxy_set_header        X-Real-IP $remote_addr;
        proxy_set_header        X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header        X-Forwarded-Proto $scheme;
        proxy_set_header        Host $http_host;
        proxy_intercept_errors  on;
    }

例如，/ht/（健康檢查）運作良好

後端的 urls.py:

urlpatterns = [
url(r'^swagger/$', schema_view.with_ui('swagger', cache_timeout=0), name='schema-
swagger-ui')]

如果您需要任何其他文件，請告訴我，我願意分享它們，我只是用 mysite.com 等虛擬數據替換敏感數據

先致謝！

編輯：我剛剛注意到，在“網絡”選項卡中，它為所有CSS、JS 文件顯示“需要啟用Javascript 才能運行此應用程式”，/redoc 也是如此，控制台日誌也會拋出此錯誤：“未捕獲的語法錯誤：意外的錯誤” JS 檔案的標記“<”。

我忘記指出它是一個 React 應用程序，但應用程式本身運作良好。後端是Python/Django
