從 Apache2 遷移到 NGINX 配置

tag-icon • tag-icon nginx ssl amazon-ec2 apache2 ubuntu-20.04
從 Apache2 遷移到 NGINX 配置

在我的 AWS Ubuntu 20.04 伺服器上從 apache2 遷移到 nginx 後，我一直在嘗試啟動我的網站。我已將相關文件從 apache2 翻譯到我的 nginx 配置，但是我似乎無法透過頁面獲得安全的 https 存取權。我的配置可以進行健全性檢查嗎？

A我已在 AWS 端指派了一個彈性 IP，並使用我們的 Web 主機平台上的名稱重新路由該 IP 。我已經能夠透過運行來產生 SSL 憑證：sudo certbot certonly --webroot --agree-tos -w /etc/letsencrypt/ --expand -d mywebsite.com,mywebsite.blah.com。

我還可以透過直接在搜尋欄中輸入彈性 IP 位址來直接載入網站，然後載入網頁，但使用https 劃掉並顯示無效的證書訊息。

/etc/nginx/nginx.conf

user  nginx;
worker_processes  auto;

error_log  /var/log/nginx/error.log debug;
pid        /var/run/nginx.pid;


events {
    worker_connections  1024;
}


http {
    server_names_hash_bucket_size       128;
    include /etc/nginx/sites-enabled/*;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    include       /etc/nginx/mime.types;

    default_type  application/octet-stream;

    log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
                      '$status $body_bytes_sent "$http_referer" '
                      '"$http_user_agent" "$http_x_forwarded_for"';

    access_log  /var/log/nginx/access.log  main;

    sendfile        on;
    #tcp_nopush     on;

    keepalive_timeout  65;

    #gzip  on;

    #include /etc/nginx/conf.d/*.conf;
    include /etc/nginx/sites-enabled/*.conf;


    disable_symlinks off;
}

/etc/apache2/sites-available/website.conf

<IfModule mod_ssl.c>
<VirtualHost *:443>
        ServerAdmin webmaster@localhost
        DocumentRoot /var/www/html
        ServerName mywebsite.com
        ServerAlias mywebsite.com mywebsite.blah.com
        SSLEngine on
        SSLProxyEngine on
        SSLCertificateFile /etc/letsencrypt/live/mywebsite.com/fullchain.pem
        SSLCertificateKeyFile /etc/letsencrypt/live/mywebsite.com/privkey.pem
        Include /etc/letsencrypt/options-ssl-apache.conf

    RewriteEngine On

    RewriteCond %{HTTP:Upgrade} =websocket               [NC]
    RewriteRule /(.*)           ws://amazon-ec2-instance.com:8080/$1  [P,L]

        ProxyPreserveHost On
        ProxyRequests Off
        ProxyPass / http://amazon-ec2-instance.com:8080/
        ProxyPassReverse / http://amazon-ec2-instance.com:8080/
        ProxyPassReverseCookieDomain / http://amazon-ec2-instance.com:8080/
        ProxyPassReverseCookiePath / http://amazon-ec2-instance.com:8080/

        ProxyPass /api/ws wss://amazon-ec2-instance.com:8080/
        ProxyPassReverse /api/ws wss://amazon-ec2-instance.com:8080/
        ErrorLog ${APACHE_LOG_DIR}/error.log
        CustomLog ${APACHE_LOG_DIR}/access.log combined

        <Directory />
          Options FollowSymLinks
          AllowOverride All
        </Directory>

</VirtualHost>
</IfModule>

/etc/nginx/sites-available/website.conf

server {
    if ($host = mywebsite.com) {
        return 301 https://$host$request_uri;
    } # managed by Certbot

server {
       listen 80;
        listen [::]:80;

       server_name mywebsite.com mywebsite.blah.com;

       root /var/www/html;
       index index.html;

       #passenger_enabled on;

       location / {
                rewrite ^(.*)$ https://$http_host:8080$request_uri redirect;
                try_files $uri $uri/ =404;
        }

        location !/\.ht {
                deny all;
        }

        location ~ \.php$ {
                # include snippets/fastcgi-php.conf;
                fastcgi_pass unix:/run/php/php7.4-fpm.sock;
        }
}

/etc/apache2/sites-available/website-ssl.conf

<IfModule mod_ssl.c>
<VirtualHost *:443>
        ServerAdmin webmaster@localhost
        DocumentRoot /var/www/html
        ServerName mywebsite
        ServerAlias mywebsite.com mywebsite.blah.com
        SSLEngine on
        SSLProxyEngine on
        Include /etc/letsencrypt/options-ssl-apache.conf
        RewriteEngine On


        RewriteCond %{HTTP:Upgrade} =websocket [NC]
    RewriteRule /(.*) ws://amazon-ec2-instance.com:8080/$1 [P,L]

    ProxyPreserveHost On
    ProxyRequests Off
        ProxyPass / http://amazon-ec2-instance.com:8080/
        ProxyPassReverse / http://amazon-ec2-instance.com:8080/
        ProxyPassReverseCookieDomain / http://amazon-ec2-instance.com:8080/
        ProxyPassReverseCookiePath / http://amazon-ec2-instance.com:8080/

        ProxyPass /api/ws wss://amazon-ec2-instance.com:8080/
        ProxyPassReverse /api/ws wss://amazon-ec2-instance.com:8080/

        ErrorLog ${APACHE_LOG_DIR}/error.log
        CustomLog ${APACHE_LOG_DIR}/access.log combined

        <Directory />
          Options FollowSymLinks
          AllowOverride All
        </Directory>

        SSLCertificateFile /etc/letsencrypt/live/mywebsite/fullchain.pem
        SSLCertificateKeyFile /etc/letsencrypt/live/mywebsite/privkey.pem
</VirtualHost>
</IfModule>

/etc/nginx/sites-available/website-ssl.conf

server {
    include                     /etc/letsencrypt/options-ssl-nginx.conf;
    listen                      443 ssl;
    server_name                 mywebsite.com;
    ssl_certificate             /etc/letsencrypt/live/mywebsite.com/fullchain.pem;
    ssl_certificate_key         /etc/letsencrypt/live/mywebsite.com/privkey.pem;

    root                        /var/www/html ;

    location / {
        proxy_pass                      http://mywebsite.com:8080/ ;
        proxy_set_header Host           $host;
        proxy_set_header X-Real-IP      $remote_addr;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_cookie_domain http://mywebsite.com:8080/ $host;
        proxy_cookie_path / /;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
    }

    location /api/ws {
        proxy_pass http://mywebsite.com:8080/ ;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }

    access_log /var/log/nginx/access.log;
    error_log /var/log/nginx/error.log;
}

/etc/apache2/sites-available/website-ssl2.conf

<IfModule mod_ssl.c>
<VirtualHost *:443>
        ServerAdmin webmaster@localhost
        DocumentRoot /var/www/html
        ServerName mywebsite.com
        ServerAlias mywebsite.com mywebsite.blah.com
        SSLEngine on
        SSLProxyEngine on
        SSLCertificateFile /etc/letsencrypt/live/mywebsite.com/fullchain.pem
        SSLCertificateKeyFile /etc/letsencrypt/live/mywebsite.com/privkey.pem
        Include /etc/letsencrypt/options-ssl-apache.conf

    RewriteEngine On

    RewriteCond %{HTTP:Upgrade} =websocket               [NC]
    RewriteRule /(.*)           ws://localhost:8080/$1  [P,L]

        ProxyPreserveHost On
        ProxyRequests Off
        ProxyPass / http://localhost:8080/
        ProxyPassReverse / http://localhost:8080/
        ProxyPassReverseCookieDomain / http://localhost:8080/
        ProxyPassReverseCookiePath / http://localhost:8080/

        ProxyPass /api/ws wss://localhost:8080/
        ProxyPassReverse /api/ws wss://localhost:8080/

        # Available loglevels: trace8, ..., trace1, debug, info, notice, warn,
        # error, crit, alert, emerg.
        # It is also possible to configure the loglevel for particular
        # modules, e.g.
        #LogLevel info ssl:warn

        ErrorLog ${APACHE_LOG_DIR}/error.log
        CustomLog ${APACHE_LOG_DIR}/access.log combined

        <Directory />
          Options FollowSymLinks
          AllowOverride All
        </Directory>

</VirtualHost>
</IfModule>

/etc/nginx/sites-available/website-ssl2.conf

server {
    include                     /etc/letsencrypt/options-ssl-nginx.conf;
    listen                      443 ssl;
    server_name                 mywebsite.com;

    ssl_certificate             /etc/letsencrypt/live/mywebsite.com/fullchain.pem;
    ssl_certificate_key         /etc/letsencrypt/live/mywebsite.com/privkey.pem;

    location / {
        proxy_pass                      http://localhost:8080/;
        proxy_set_header Host           $host;
        proxy_set_header X-Real-IP      $remote_addr;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_cookie_domain http://localhost:8080/ $host;
        proxy_cookie_path / /;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
    }


    access_log /var/log/nginx/access.log;
    error_log /var/log/nginx/error.log;

    # Other directives specific to your configuration
    # ...
}

答案1

user nginx;將檔案“/etc/nginx/nginx.conf”的第一行更改為user www-data;

然後重啟nginx伺服器

systemctl restart nginx
