Ngnix 反向代理程式為 Docker 中的本機設定 SSL

使用下面的 docker compose.yml 我正在建立 2 個容器和一個反向代理容器。

version: '3'

services:
  # SSGTM Tag Server Container
  tagging_server_container:
    image: gcr.io/cloud-tagging-10302018/gtm-cloud-image:stable
    ports:
      - '8080:8080'
    restart: always
    environment:
      PREVIEW_SERVER_URL: https://preview.ssgtm.dev
      CONTAINER_CONFIG: aWQ9...
    networks:
      - ssgtm
  # SSGTM Preview Server Container
  preview_server_container:
    image: gcr.io/cloud-tagging-10302018/gtm-cloud-image:stable
    ports:
      - '8081:8080'
    restart: always
    environment:
      RUN_AS_PREVIEW_SERVER: true
      CONTAINER_CONFIG: aWQ9...
    networks:
      - ssgtm
  proxy:
    image: nginx:1.19.10-alpine
    ports:
      - 80:80
      - 443:443
    volumes:
      - ./conf/nginx.conf:/etc/nginx/nginx.conf
      - ./certs:/etc/nginx/certs
    depends_on:
      - preview_server_container
      - tagging_server_container
    networks:
      - ssgtm
networks:
  ssgtm:
    driver: bridge

也在內部conf/nginx.conf用於mkcert -cert-file ssgtm.dev.crt -key-file ssgtm.dev.key ssgtm.dev "*.ssgtm.dev" localhost 127.0.0.1 ::1建立 SSL 憑證和金鑰。

events {
  worker_connections 1024;
}

http {

  upstream docker-tagging-server {
    server tagging_server_container:8080;
  }

  upstream docker-preview-server {
    server preview_server_container:8080;
  }

  server {
    listen 443 ssl;
    server_name 127.0.0.1;

    ssl_certificate /etc/nginx/certs/cert.crt;
    ssl_certificate_key /etc/nginx/certs/cert.key;
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
    ssl_ciphers HIGH:!aNULL:!MD5;

    location / {
      proxy_buffering off;
      proxy_redirect  off;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Forwarded-Host $host;
      proxy_set_header X-Forwarded-Port $server_port;

      proxy_pass http://docker-preview-server;
    }
  }

  server {
    listen 443 ssl;
    server_name ssgtm.dev;

    ssl_certificate /etc/nginx/certs/cert.crt;
    ssl_certificate_key /etc/nginx/certs/cert.key;
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
    ssl_ciphers HIGH:!aNULL:!MD5;

    location / {
      proxy_buffering off;
      proxy_redirect  off;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Forwarded-Host $host;
      proxy_set_header X-Forwarded-Port $server_port;

      proxy_pass http://docker-tagging-server;
    }
  }

  server {
    listen 443 ssl;
    server_name preview.ssgtm.dev;

    ssl_certificate /etc/nginx/certs/cert.crt;
    ssl_certificate_key /etc/nginx/certs/cert.key;
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
    ssl_ciphers HIGH:!aNULL:!MD5;

    location / {
      proxy_buffering off;
      proxy_redirect  off;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Forwarded-Host $host;
      proxy_set_header X-Forwarded-Port $server_port;

      proxy_pass http://docker-preview-server;
    }
  }
}

我將 VirtualHost 請求代理程式到目標容器。

另外，hosts我在文件中添加了以下內容以在本地解決。效果很好...它解析為 127.0.0.1 並轉到 Nginx 並轉到其目標容器。

127.0.0.1 preview.ssgtm.dev
::1 preview.ssgtm.dev

127.0.0.1 ssgtm.dev
::1 ssgtm.dev

我面臨的問題是...在兩個容器應用程式內部確實請求使用443 連接埠的TCP 到網域IP...所以當它確實請求ssgtm.dev:443 時，它會變成127.0.0.1:443 並返回錯誤Message: connect ECONNREFUSED 127.0.0.1:443我無法理解這個錯誤。據我了解，它無法透過連接埠 443 連接到 127.0.0.1，但我已經添加了！我做錯了什麼？

答案1

容器無法存取 Nginx，因為它們正在嘗試連接到自己網路命名空間的本機，我們可以嘗試使用特殊的 DNSname host.docker.internal來解析主機使用的內部 IP 位址。

修改您的nginx.conf文件，以便它不向ssgtm.dev:443或127.0.0.1:443發出請求，而是向host.docker.internal:443.

server {
    listen 443 ssl;
    server_name host.docker.internal;

    ssl_certificate /etc/nginx/certs/cert.crt;
    ssl_certificate_key /etc/nginx/certs/cert.key;
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
    ssl_ciphers HIGH:!aNULL:!MD5;

    location / {
      proxy_buffering off;
      proxy_redirect  off;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Forwarded-Host $host;
      proxy_set_header X-Forwarded-Port $server_port;

      proxy_pass http://docker-preview-server;
    }
  }
