雖然指示燈閃爍,但 Mellanox connectx-3 (cx312a) 連結已斷開

雖然指示燈閃爍,但 Mellanox connectx-3 (cx312a) 連結已斷開

我有一個運行 TrueNas Scale 的系統。由於某些奇怪的原因,即使 dmesg 報告連結已建立且連接埠上的指示燈閃爍,系統也看不到連結已建立。我不確定這是否是光纖的兼容性,因為我使用的是 Ericson 的光纖(在瞻博網路中得到認可)。同樣奇怪的是,廣告中的自動協商已關閉。這是我用來排除故障的一些命令。我還嘗試了網卡上的兩個連接埠。

這是 dmesg

admin@truenas[~]$ sudo dmesg | grep mlx
[    1.865599] mlx4_core: Mellanox ConnectX core driver v4.0-0
[    1.866114] mlx4_core: Initializing 0000:01:00.0
[    1.866639] mlx4_core 0000:01:00.0: enabling device (0000 -> 0002)
[    8.864380] mlx4_core 0000:01:00.0: DMFS high rate steer mode is: disabled performance optimized steering
[    8.865246] mlx4_core 0000:01:00.0: 63.008 Gb/s available PCIe bandwidth (8.0 GT/s PCIe x8 link)
[    8.943401] mlx4_en: Mellanox ConnectX HCA Ethernet driver v4.0-0
[    8.943890] mlx4_en 0000:01:00.0: Activating port:1
[    8.947954] mlx4_en: 0000:01:00.0: Port 1: Using 8 TX rings
[    8.948294] mlx4_en: 0000:01:00.0: Port 1: Using 8 RX rings
[    8.948836] mlx4_en: 0000:01:00.0: Port 1: Initializing port
[    8.949441] mlx4_en 0000:01:00.0: registered PHC clock
[    8.950038] mlx4_en 0000:01:00.0: Activating port:2
[    8.951205] mlx4_core 0000:01:00.0 enp1s0: renamed from eth0
[    8.953510] mlx4_en: 0000:01:00.0: Port 2: Using 8 TX rings
[    8.954069] mlx4_en: 0000:01:00.0: Port 2: Using 8 RX rings
[    8.954840] mlx4_en: 0000:01:00.0: Port 2: Initializing port
[    8.980259] <mlx4_ib> mlx4_ib_add: mlx4_ib: Mellanox ConnectX InfiniBand driver v4.0-0
[    8.982100] <mlx4_ib> mlx4_ib_add: counter index 2 for port 1 allocated 1
[    8.982215] mlx4_core 0000:01:00.0 enp1s0d1: renamed from eth0
[    8.982567] <mlx4_ib> mlx4_ib_add: counter index 3 for port 2 allocated 1
[   11.659376] mlx4_en: enp1s0: Link Up
[  185.391704] mlx4_en: enp1s0: Link Down
[  257.903512] mlx4_en: enp1s0: Link Up
[ 1486.106437] mlx4_en: enp1s0: Link Down
[ 1524.842156] mlx4_core 0000:01:00.0: MLX4_CMD_MAD_IFC Get Module ID attr(ff60) port(1) i2c_addr(50) offset(0) size(1): Response Mad Status(31c) - cable is not connected
[ 1591.308231] mlx4_en: enp1s0: Link Up
[ 2026.000939] mlx4_en: enp1s0: Link Down
[ 2047.724983] mlx4_en: enp1s0: Link Up
[ 3657.633665] mlx4_en: enp1s0: Link Down
[ 3684.070133] mlx4_en: enp1s0d1: Link Up
[ 4577.747372] mlx4_en: enp1s0d1: Link Down
[ 4631.805428] mlx4_en: enp1s0: Link Up

這是ethtool

admin@truenas[~]$ sudo ethtool enp1s0
Settings for enp1s0:
    Supported ports: [ FIBRE ]
    Supported link modes:   1000baseX/Full
                            10000baseCR/Full
                            10000baseSR/Full
    Supported pause frame use: Symmetric Receive-only
    Supports auto-negotiation: No
    Supported FEC modes: Not reported
    Advertised link modes:  1000baseX/Full
                            10000baseCR/Full
                            10000baseSR/Full
    Advertised pause frame use: Symmetric
    Advertised auto-negotiation: No
    Advertised FEC modes: Not reported
    Speed: 10000Mb/s
    Duplex: Full
    Auto-negotiation: off
    Port: FIBRE
    PHYAD: 0
    Transceiver: internal
    Supports Wake-on: d
    Wake-on: d
        Current message level: 0x00000014 (20)
                               link ifdown
    Link detected: no

這是用於光學的 ethtool:

admin@truenas[~]$ sudo ethtool -m enp1s0
    Identifier                                : 0x03 (SFP)
    Extended identifier                       : 0x04 (GBIC/SFP defined by 2-wire interface ID)
    Connector                                 : 0x07 (LC)
    Transceiver codes                         : 0x10 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
    Transceiver type                          : 10G Ethernet: 10G Base-SR
    Encoding                                  : 0x06 (64B/66B)
    BR, Nominal                               : 10300MBd
    Rate identifier                           : 0x00 (unspecified)
    Length (SMF,km)                           : 0km
    Length (SMF)                              : 0m
    Length (50um)                             : 80m
    Length (62.5um)                           : 30m
    Length (Copper)                           : 0m
    Length (OM3)                              : 300m
    Laser wavelength                          : 850nm
    Vendor name                               : FINISAR CORP.
    Vendor OUI                                : 00:90:65
    Vendor PN                                 : FTLX8571D3BCL-ER
    Vendor rev                                : A
    Option values                             : 0x00 0x1a
    Option                                    : RX_LOS implemented
    Option                                    : TX_FAULT implemented
    Option                                    : TX_DISABLE implemented
    BR margin, max                            : 0%
    BR margin, min                            : 0%
    Vendor SN                                 : AP3193K
    Date code                                 : 130127
    Optical diagnostics support               : Yes
    Laser bias current                        : 8.036 mA
    Laser output power                        : 0.6284 mW / -2.02 dBm
    Receiver signal average optical power     : 0.7003 mW / -1.55 dBm
    Module temperature                        : 41.64 degrees C / 106.95 degrees F
    Module voltage                            : 3.2852 V
    Alarm/warning flags implemented           : Yes
    Laser bias current high alarm             : Off
    Laser bias current low alarm              : Off
    Laser bias current high warning           : Off
    Laser bias current low warning            : Off
    Laser output power high alarm             : Off
    Laser output power low alarm              : Off
    Laser output power high warning           : Off
    Laser output power low warning            : Off
    Module temperature high alarm             : Off
    Module temperature low alarm              : Off
    Module temperature high warning           : Off
    Module temperature low warning            : Off
    Module voltage high alarm                 : Off
    Module voltage low alarm                  : Off
    Module voltage high warning               : Off
    Module voltage low warning                : Off
    Laser rx power high alarm                 : Off
    Laser rx power low alarm                  : Off
    Laser rx power high warning               : Off
    Laser rx power low warning                : Off
    Laser bias current high alarm threshold   : 13.200 mA
    Laser bias current low alarm threshold    : 4.000 mA
    Laser bias current high warning threshold : 12.600 mA
    Laser bias current low warning threshold  : 5.000 mA
    Laser output power high alarm threshold   : 1.0000 mW / 0.00 dBm
    Laser output power low alarm threshold    : 0.2512 mW / -6.00 dBm
    Laser output power high warning threshold : 0.7943 mW / -1.00 dBm
    Laser output power low warning threshold  : 0.3162 mW / -5.00 dBm
    Module temperature high alarm threshold   : 78.00 degrees C / 172.40 degrees F
    Module temperature low alarm threshold    : -13.00 degrees C / 8.60 degrees F
    Module temperature high warning threshold : 73.00 degrees C / 163.40 degrees F
    Module temperature low warning threshold  : -8.00 degrees C / 17.60 degrees F
    Module voltage high alarm threshold       : 3.7000 V
    Module voltage low alarm threshold        : 2.9000 V
    Module voltage high warning threshold     : 3.6000 V
    Module voltage low warning threshold      : 3.0000 V
    Laser rx power high alarm threshold       : 1.0000 mW / 0.00 dBm
    Laser rx power low alarm threshold        : 0.0100 mW / -20.00 dBm
    Laser rx power high warning threshold     : 0.7943 mW / -1.00 dBm
    Laser rx power low warning threshold      : 0.0158 mW / -18.01 dBm

答案1

我很笨。我只需將 IP 分配給介面即可使用。
