是否可以在雙顯示器設定（桌面）中快速啟用/停用顯示器？

tag-icon • tag-icon 18.04 nvidia multiple-monitors display settings
是否可以在雙顯示器設定（桌面）中快速啟用/停用顯示器？

我的設定非常簡單，只有兩個螢幕和 3 個非常標準的用例：

我的設定

+------------------------+----------------+----------+
|         Set-up         | Screen (144Hz) |    TV    |
+------------------------+----------------+----------+
| A – joined or mirrored | Enabled        | Enabled  |
| B – Computer           | Enabled        | Disabled |
| C – Home Theater       | Disabled       | Enabled  |
+------------------------+----------------+----------+

這意味著在設定之間切換時我有以下 4 種情況：

+------- --------------------+-------------+-----------+
|       Scenarios            | From set-up | To set-up |
+----------------------------+-------------+-----------+
| 1 – Turn on TV             | B           | C         |
| 2 – Turn off TV            | C           | B         |
| 3 – Extend displays        | B/C         | A         |
| 4 – Back to single display | A           | B/C       |
+----------------------------+-------------+-----------+

我知道在 Ubuntu 中我可以使用預設鍵盤快捷鍵super+p來切換顯示，但它在任何這些情況下都不起作用。

在所有這些中，我都需要手動進入settings> devices>display並選擇我想要的內容，並且每次都將電腦螢幕更新率從 60Hz 重新提高到 144Hz。

有沒有辦法自動化這個？在 W10 上，您設定一次，它就會記住該設定。然後，您可以循環設定（雙、單、投影機、鏡像）。

這裡，場景 3 意味著每次都重新定位顯示器的相對位置，而場景 4 無法透過快捷方式實現，因為我的桌面沒有「內建顯示器」。

或者是否可以將外接顯示器設定為內建顯示器？

問題是：

  1. 如果重新啟用螢幕，其設定將完全重置（解析度、刷新率和相對位置）
  2. 如果沒有內建顯示器，則無法透過捷徑啟用或停用螢幕super+p

答案1

感謝 MestreLion 讓這個解決方案成為可能。

稍後深入研究我用這個很棒的腳本找到了一個相關的問題：

#!/bin/bash
#
# monitor-switch - switch outputs using xrand
#
#    Copyright (C) 2012 Rodrigo Silva (MestreLion) <[email protected]>
#
#    This program is free software: you can redistribute it and/or modify
#    it under the terms of the GNU General Public License as published by
#    the Free Software Foundation, either version 3 of the License, or
#    (at your option) any later version.
#
#    This program is distributed in the hope that it will be useful,
#    but WITHOUT ANY WARRANTY; without even the implied warranty of
#    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
#    GNU General Public License for more details.
#
#    You should have received a copy of the GNU General Public License
#    along with this program. See <http://www.gnu.org/licenses/gpl.html>

declare -A monitor_opts
declare -a monitors

myname="${0##*/}"
verbose=0

# Read settings from config file
config=${XDG_CONFIG_HOME:-"$HOME"/.config}/"$myname".conf
if [[ -f "$config" ]]; then
    source "$config"
fi

print_monitors() {
    while read -r output conn hex; do
        echo "# $output $conn   $(xxd -r -p <<<"$hex")"
    done < <(xrandr --prop | awk '
    !/^[ \t]/ {
        if (output && hex) print output, conn, hex
        output=$1
        hex=""
    }
    /ConnectorType:/ {conn=$2}
    /[:.]/ && h {
        sub(/.*000000fc00/, "", hex)
        hex = substr(hex, 0, 26) "0a"
        sub(/0a.*/, "", hex)
        h=0
    }
    h {sub(/[ \t]+/, ""); hex = hex $0}
    /EDID.*:/ {h=1}')
}

# if there's no pre-defined monitors list, read from xrandr
# and save them to config file
if [[ -z "$monitors" ]]; then
    while read -r output ; do
        monitors+=("$output")
    done < <(xrandr | awk '$2 ~/^c/{print $1}' | sort)
    cat > "$config" <<-EOF
        # $myname config file
        # List of monitors, from left to right. Edit to your actual layout
        monitors=(${monitors[@]})
        # Extra xrandr options for each monitor.
        # Useful when EDID data does not reflect actual preferred mode
        # Options for non-existing outputs (such as the examples below) are ignored
        # Examples:
        monitor_opts[DFPx]="--mode 1920x1080 --rate 60"
        monitor_opts[DFPy]="--mode 1280x720"
        # As a reference, these were the connected monitors when this config file was created
        # use it as a guide when editing the above monitors list and extra options
        $(print_monitors)
        # For an updated list, run $myname --list
    EOF
fi

message() { printf "%s\n" "$1" >&2 ; }
fatal()   { [[ "$1" ]] && message "$myname: error: $1" ; exit ${2:-1} ; }
argerr()  { printf "%s: %s\n" "$myname" "${1:-error}" >&2 ; usage 1 ; }
invalid() { argerr "invalid argument: $1" ; }
missing() { argerr "missing ${2:+$2 }operand${1:+ from $1}." ; }

usage() {
    cat <<-USAGE
    Usage: $myname [options]
    USAGE
    if [[ "$1" ]] ; then
        cat >&2 <<- USAGE
        Try '$myname --help' for more information.
        USAGE
        exit 1
    fi
    cat <<-USAGE
    Switch monitors using xrandr.
    Options:
      -h|--help          - show this page.
      -v|--verbose       - print in terminal the full xrandr command executed.
      -l|--list          - list connector and monitor names of connected outputs
      -a|--all           - enable all monitors.
      -s|--select OUTPUT - enable monitor OUTPUT, disable all others.
      -l|--left          - enable leftmost monitor.  Alias for --select ${monitors[0]}
      -r|--right         - enable rightmost monitor. Alias for --select ${monitors[${#monitors[@]}-1]}
    Copyright (C) 2012 Rodrigo Silva (MestreLion) <[email protected]>
    License: GPLv3 or later. See <http://www.gnu.org/licenses/gpl.html>
    USAGE
    exit 0
}

# Option handling
for arg in "$@"; do [[ "$arg" == "-h" || "$arg" == "--help" ]] && usage ; done
while (( $# )); do
    case "$1" in
    -v|--verbose) verbose=1 ;;
    -q|--no-notify) notify=0 ;;
    -l|--list) list=1 ;;
    -a|--all) all=1 ;;
    -s|--select) shift ; monitor="$1" ;;
    -l|--left ) monitor="${monitors[0]}" ;;
    -r|--right) monitor="${monitors[${#monitors[@]}-1]}" ;;
    *) invalid "$1" ;;
    esac
    shift
done

if ((list)); then
    echo "Connected monitors:"
    print_monitors
    exit
fi

if [[ -z "$monitor" && -z "$all" ]]; then
    usage
fi

# Loop outputs (monitors)
for output in "${monitors[@]}"; do
    if ((all)) || [[ "$output" = "$monitor" ]]; then
        xrandropts+=(--output "$output" --auto ${monitor_opts["$output"]})
        if ((all)); then
            if [[ "$output" = "${monitors[0]}" ]]; then
                xrandropts+=(--pos 0x0 --primary)
            else
                xrandropts+=(--right-of "$previous")
            fi
            previous="$output"
        else
            xrandropts+=(--primary)
        fi
    else
        xrandropts+=(--output "$output" --off)
    fi
done

((verbose)) && message "$myname: executing xrandr ${xrandropts[*]}"
xrandr "${xrandropts[@]}"

該程式碼也共享於吉圖布。

透過將此腳本映射到鍵盤快捷鍵，我可以輕鬆切換顯示器：

monitor-switch --left
monitor-switch --right

該腳本也會建立一個設定檔/home/.config/monitor-switch.conf。這 3 行設定檔允許註冊兩件事：

  1. 螢幕的實體佈局：哪個螢幕位於另一個螢幕的左側/右側。當您的主顯示器位於輔助顯示器的右側（我的情況）時，這非常有用。
  2. 開啟顯示器時所使用的模式（預設為xrandr --auto）。以我為例，我可以保存monitor_opts[DP-2]="--mode 1920x1080 --rate 144"

答案2

有時我的顯示器會失去對齊（左變為右，頂部變為底部等），有時我的第二個顯示器會褪色。為此，我只需輸入即可xreset，一切都會恢復正常。我~/.bashrc為此目的創建了一個函數：

$ type -a xreset

xreset is a function

xreset ()
{
    # Reset xrandr to normal, first use: xrandr | grep " connected "
    # HDMI-0 connected 1920x1080+0+0 (normal left inverted right x axis y axis) 1107mm x 623mm
    # eDP-1-1 connected primary 1920x1080+3840+2160 (normal left inverted right x axis y axis) 382mm x 215mm
    # DP-1-1 connected 3840x2160+1920+0 (normal left inverted right x axis y axis) 1600mm x 900mm
    xrandr --output HDMI-0  --mode 1920x1080 --pos 0x0       --rotate normal \
           --output eDP-1-1 --mode 1920x1080 --pos 3840x2160 --rotate normal \
           --output DP-1-1  --mode 3840x2160 --pos 1920x0    --rotate normal

}

您可以使用 、 等執行類似的操作xconfig1，xconfig2然後將它們綁定到快捷鍵。
