如何解決 MacbookPro(Ubuntu) WIFI 上的雙啟動問題？

tag-icon • tag-icon dual-boot wireless sound keyboard macbook-pro
如何解決 MacbookPro(Ubuntu) WIFI 上的雙啟動問題？

我已在 MacbookPro 2016 雙啟動 MacO 和 Ubuntu 上安裝？我沒有連接 wifi，只能連接 LAN（有時）。

02:00.0 Network controller [0280]: Broadcom Inc. and subsidiaries
BCM43602 802.11ac Wireless LAN SoC [14e4:43ba] (rev 02)
Subsystem: Apple Inc. BCM43602 802.11ac Wireless LAN SoC [106b:0157]
Kernel driver in use: brcmfmac  Kernel modules: brcmfmac

。

[    5.007976] usbcore: registered new interface driver brcmfmac
[    5.136826] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43602-pcie for chip BCM43602/2
[    5.138755] brcmfmac 0000:02:00.0: Direct firmware load for brcm/brcmfmac43602-pcie.Apple Inc.-MacBookPro13,2.txt failed with error -2
[    5.138769] brcmfmac 0000:02:00.0: Direct firmware load for brcm/brcmfmac43602-pcie.txt failed with error -2
[    5.472861] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43602-pcie for chip BCM43602/2
[    5.472891] brcmfmac: brcmf_c_process_clm_blob: no clm_blob available (err=-2), device may have limited channels available
[    5.473317] brcmfmac: brcmf_c_preinit_dcmds: Firmware: BCM43602/2 wl0: Nov 10 2015 06:38:10 version 7.35.177.61 (r598657) FWID 01-ea662a8c
[    5.512360] brcmfmac 0000:02:00.0 wlp2s0: renamed from wlan0
[    5.754337] bluetooth hci0: Direct firmware load for brcm/BCM.hcd failed with error -2
[    5.754339] Bluetooth: hci0: BCM: Patch brcm/BCM.hcd not found

。

iwconfig

lo        no wireless extensions.

wlp2s0    IEEE 802.11  ESSID:off/any
          Mode:Managed  Access Point: Not-Associated   Tx-Power=31 dBm
          Retry short limit:7   RTS thr:off   Fragment thr:off
          Power Management:on

。

sudo iwlist scan

[sudo] password for vita:
lo        Interface doesn't support scanning.

wlp2s0    Scan completed :
          Cell 01 - Address: 24:58:6E:BC:E3:C7
                    Channel:6
                    Frequency:2.437 GHz (Channel 6)
                    Quality=17/70  Signal level=-93 dBm
                    Encryption key:on
                    ESSID:"WIND_6xUapP"
                    Bit Rates:1 Mb/s; 2 Mb/s; 5.5 Mb/s; 11 Mb/s; 6 Mb/s
                              9 Mb/s; 12 Mb/s; 18 Mb/s
                    Bit Rates:24 Mb/s; 36 Mb/s; 48 Mb/s; 54 Mb/s
                    Mode:Master
                    Extra:tsf=0000000000000000
                    Extra: Last beacon: 84ms ago
                    IE: Unknown: 000B57494E445F367855617050
                    IE: Unknown: 010882848B960C121824
                    IE: Unknown: 030106
                    IE: Unknown: 050400010000
                    IE: Unknown: 2A0104
                    IE: Unknown: 32043048606C
                    IE: Unknown: 2D1A0C181FFFFF000000000000000000000000000000000000000000
                    IE: Unknown: 3D1606000000000000000000000000000000000000000000
                    IE: IEEE 802.11i/WPA2 Version 1
                        Group Cipher : CCMP
                        Pairwise Ciphers (1) : CCMP
                        Authentication Suites (1) : PSK
                    IE: Unknown: DD180050F2020101000003A4000027A4000042435E0062322F00
                    IE: Unknown: DD1E00904C330C181FFFFF000000000000000000000000000000000000000000
                    IE: Unknown: DD1A00904C3406000000000000000000000000000000000000000000
                    IE: Unknown: DD0600E04C020160
                    IE: Unknown: DD0E0050F204104A0001101044000102
          Cell 02 - Address: 30:99:35:B4:AF:C2
                    Channel:6
                    Frequency:2.437 GHz (Channel 6)
                    Quality=33/70  Signal level=-77 dBm
                    Encryption key:on
                    ESSID:"olympiakos7"
                    Bit Rates:1 Mb/s; 2 Mb/s; 5.5 Mb/s; 11 Mb/s; 18 Mb/s
                              24 Mb/s; 36 Mb/s; 54 Mb/s
                    Bit Rates:6 Mb/s; 9 Mb/s; 12 Mb/s; 48 Mb/s
                    Mode:Master
                    Extra:tsf=0000000000000000
                    Extra: Last beacon: 84ms ago
                    IE: Unknown: 000B6F6C796D7069616B6F7337
                    IE: Unknown: 010882848B962430486C
                    IE: Unknown: 030106
                    IE: Unknown: 050400010000
                    IE: Unknown: 0706475220010D14
                    IE: Unknown: 2A0104
                    IE: Unknown: 32040C121860
                    IE: IEEE 802.11i/WPA2 Version 1
                        Group Cipher : TKIP
                        Pairwise Ciphers (2) : CCMP TKIP
                        Authentication Suites (1) : PSK
                    IE: Unknown: 46053208010000
                    IE: Unknown: 2D1A1E181BFFFF000001000000000000000000000000000000000000
                    IE: Unknown: 3D16060D1600000000000000000000000000000000000000
                    IE: Unknown: 7F080400080000000040
                    IE: Unknown: DD180050F204104A00011010440001021049000600372A000120
                    IE: Unknown: DD090010180204000C0000
                    IE: WPA Version 1
                        Group Cipher : TKIP
                        Pairwise Ciphers (2) : CCMP TKIP
                        Authentication Suites (1) : PSK
                    IE: Unknown: DD180050F2020101800003A4000027A4000042435E0062322F00

。

rfkill list all

0: phy0: Wireless LAN
    Soft blocked: no
    Hard blocked: no
1: hci0: Bluetooth
    Soft blocked: no
    Hard blocked: no

答案1

我在 MacBookPro13,2 上的 wifi 上也遇到同樣的問題：

sudo dmidecode -s system-product-name
MacBookPro13,2

我安裝了 Ubuntu 18.04 雙重啟動，行為是雖然我可以看到 2GHz wifi 網路（沒有 5GHz），但當我連接到它時，它不斷要求輸入密碼，即使密碼輸入正確。

我有相同的 wifi 硬體：

lspci -nn | grep Network
02:00.0 Network controller [0280]: Broadcom Inc. and subsidiaries BCM43602 802.11ac Wireless LAN SoC [14e4:43ba] (rev 02)

lspci -nnk | grep 0280 -A3
02:00.0 Network controller [0280]: Broadcom Inc. and subsidiaries BCM43602 802.11ac Wireless LAN SoC [14e4:43ba] (rev 02)
    Subsystem: Apple Inc. BCM43602 802.11ac Wireless LAN SoC [106b:0157]
    Kernel driver in use: brcmfmac
    Kernel modules: brcmfmac

期待司機的brcmfmac支持BCM43602 [14e4:43ba] (rev 02)

驅動程式載入時我遇到同樣的錯誤brcmfmac：

sudo rmmod brcmfmac
sudo dmesg -C
sudo modprobe brcmfmac
dmesg
[  758.560640] usbcore: registered new interface driver brcmfmac
[  758.666665] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43602-pcie for chip BCM43602/2
[  758.667797] brcmfmac 0000:02:00.0: Direct firmware load for brcm/brcmfmac43602-pcie.Apple Inc.-MacBookPro13,2.txt failed with error -2
[  758.667873] brcmfmac 0000:02:00.0: Direct firmware load for brcm/brcmfmac43602-pcie.txt failed with error -2
[  759.006375] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43602-pcie for chip BCM43602/2
[  759.006446] brcmfmac: brcmf_c_process_clm_blob: no clm_blob available (err=-2), device may have limited channels available
[  759.007055] brcmfmac: brcmf_c_preinit_dcmds: Firmware: BCM43602/2 wl0: Nov 10 2015 06:38:10 version 7.35.177.61 (r598657) FWID 01-ea662a8c
[  759.047217] brcmfmac 0000:02:00.0 wlp2s0: renamed from wlan0
mrabule1@mrabule1-MacBookPro:~$

我的e中沒有這樣的文件/lib/firmvar：

brcm/brcmfmac43602-pcie.Apple Inc.-MacBookPro13,2.txt
brcm/brcmfmac43602-pcie.txt

這是我所擁有的：

sudo ls /lib/firmware/brcm/brcmfmac43602*
/lib/firmware/brcm/brcmfmac43602-pcie.ap.bin
/lib/firmware/brcm/brcmfmac43602-pcie.bin

我發現了各種討論論壇，人們都說他們讓這個硬體正常運作了。

我在 Ubuntu 16.04 上嘗試了各種解決方案，但沒有成功，然後我放棄了，切換到 Ubuntu 18.04，希望它更新並且能夠更好地應對硬體。還是不行。我想我會再次嘗試描述的一些解決方案這裡：

在這工作之前，我使用 USB 轉 eth 加密狗進行有線連接，但如果 wifi 能工作，我真的很高興。
