如何使用 Conky 監控 mythtv 後端？

我想使用Conky 來監控mythtv 後端，我該如何設定？

答案1

只是對 mytv-status 選項進行快速評論，您可以設定主機選項，在/etc/default/mythtv-status這種情況下，如果 mytv-status 升級或重新安裝，它將被記住。

您也可以設定其他選項，例如開啟顏色輸出並向輸出添加其他資訊。

答案2

來自論壇貼文（內容與語法編輯）：

我最近發現了這一點，因為我需要其他東西，但我認為檢查遠端和本地前端的狀態可能會很好。

我編寫了一個在 conky 中顯示本地和遠端前端狀態的腳本，我想與您分享。我剛剛學習腳本編寫，這是我第一次嘗試變量，我主要只是將一些東西放入其中，我可以從 shell 中輸入類型，沒有變量或糾錯，所以我學會了一些準備工作。

有關如何使用的說明位於文件的註釋中這個連結應該讓您了解 mytv telnet 以及如何啟用它。

在此輸入影像描述

在此輸入影像描述

在此輸入影像描述

第二個螢幕截圖顯示了我如何將它與 DemonBobs idea 和 conky mythtv 錄製狀態 howto 結合使用（在此處找到）

#!/bin/bash
#Made By Kemble Wagner
#To use this Script you need to Enable Network Remote Control Interface on Mythfrontend
#Thanks to wagnerrp from mythtv-users on freenode for his contributions and tips
#the output files are meant to be used with conky
#e.g .conkyrc
#${color #8844ee}Local Frontend Status:
#${color #8844ee} ${execi 30 mythnc.sh > /dev/null && cat /var/tmp/local.myth}
#${color #8844ee}Remote Frontend Status:
#${color #8844ee} ${execi 30 mythnc.sh > /dev/null && cat /var/tmp/remote.myth}
#Version 0.2 14/04/09
#Version 0.3 "       " fixed sed to make it parse long file names and unusual characters with spaces and no spaces when outputting Video Playback
#Version 0.4 "       " added more events to output in human friendly terms changes it so only one instance of nc is used to prevent hammering of ports
#Version 0.5 17/04/09 add some fixes to playback status and added a check status in the even the frontend not running but the host is up



#change the host names to suit add more if needed
LOCALHOST=box
#path to text file leave as default is ok
OUTPUTFILE1=/var/tmp/local.myth
OUTPUTFILETMP1=/var/tmp/local.myth.tmp
FETEST1=/var/tmp/local.fetest
FILENAME1=`cat $OUTPUTFILETMP1 | grep 'Playback Video' |sed  -e 's/[[ \t]]*/_/g' | sed 's/\(.*\)\..*/\1/' |  sed  's/  *//g' | sed -e 's/^.*\///;s/ .*$//'`
RECFILE1=`cat $OUTPUTFILETMP1 | grep 'Playback Recorded' |sed  -e 's/[[ \t]]*/_/g' | sed 's/\(.*\)\..*/\1/' |  sed  's/  *//g' | sed -e 's/^.*\///;s/ .*$//'`
#remote host variables


#the stuff below is an attempt to convert telnet status info into human friendly readable info

#below are localhost checks

nc -c exit  $LOCALHOST 6546 && echo opened >  $FETEST1|| echo closed > $FETEST1


#Checking if MythFrontend is running


if (cat $FETEST1 | grep closed ); then
  echo "$LOCALHOST is up but MythFrontend doesn't seem to be running" > $OUTPUTFILE1

else
echo -e "query location\nexit" | nc $LOCALHOST 6546 > $OUTPUTFILETMP1
fi

#Checking for TV recording Menu
if (cat $OUTPUTFILETMP1 | grep PlaybackBox ); then
  echo "$LOCALHOST is Idle in TV Recordings Menu" > $OUTPUTFILE1

else

#Checking for Program Guide
if (cat $OUTPUTFILETMP1 | grep GuideGrid ); then
  echo " $LOCALHOST is in TV Guide" > $OUTPUTFILE1
else

#Checking for MythVideo Gallery
if (cat $OUTPUTFILETMP1 | grep videogallery ); then
  echo "MythVideo Menu On $LOCALHOST is Idle" > $OUTPUTFILE1
else

#Checking for MythVideo Listings
if (cat $OUTPUTFILETMP1 | grep videolistings); then
  echo "MythVideo Menu On $LOCALHOST is Idle" > $OUTPUTFILE1
else

#Checking for MythVideo Browser
if (cat $OUTPUTFILETMP1 | grep videobrowser); then
  echo "MythVideo Menu On $LOCALHOST is Idle" > $OUTPUTFILE1
else
#Checking for MythMusics
if (cat $OUTPUTFILETMP1 | grep playmusic ); then
  echo "Playing Music Cant you Hear?" > $OUTPUTFILE1
else

#Checking for MainMenu
if (cat $OUTPUTFILETMP1 | grep MainMenu ); then
  echo "$LOCALHOST is in The Main Menu" > $OUTPUTFILE1

else

#Checking for Live TV
if (cat $OUTPUTFILETMP1 | grep "Playback LiveTV" ); then
  echo "$LOCALHOST is Watching Live TV" > $OUTPUTFILE1
else

#Checking for MythVideo Playback
if (cat $OUTPUTFILETMP1 | grep "Playback Video" ); then
  echo "MythVideo is playing $FILENAME1" > $OUTPUTFILE1
else

if (cat $OUTPUTFILETMP1 | grep  "Playback Recorded" ); then
    echo "MythTV is playing recording $RECFILE1" > $OUTPUTFILE1
else





#if none of the above simply display then query status output
if (cat $OUTPUTFILETMP1 | grep "#"); then
cat   $OUTPUTFILETMP1 | grep "#" > $OUTPUTFILE1


fi
  fi
     fi
        fi
           fi
              fi
                fi
                  fi
                     fi
                        fi
                          fi




#setting remote host variables you can reproduce this for as many hosts as you want
REMOTE=frontend
OUTPUTFILE2=/var/tmp/remote.myth
OUTPUTFILETMP2=/var/tmp/remote.myth.tmp
# script gets slow if the host is not up when continueing to set remote host variables so check its up first
#checking remote frontend is up first
if ! `/bin/ping -W1 -c1 $REMOTE >/dev/null 2>&1` ; then
echo "$REMOTE Seems Offline" > $OUTPUTFILE2 && exit 0
else

#contine setting remote host variables

FILENAME2=`cat $OUTPUTFILETMP2 | grep 'Playback Video' |sed  -e 's/[[ \t]]*/_/g' | sed 's/\(.*\)\..*/\1/' |  sed  's/  *//g' | sed -e 's/^.*\///;s/ .*$//'`
RECFILE2=`cat $OUTPUTFILETMP2 | grep 'Playback Recorded' | sed -e 's/^.*\///;s/ .*$//' | sed 's/\(.*\)\..*/\1/'`
FETEST2=/var/tmp/remote.fetest


#below are remote host checks

nc -c exit $REMOTE 6546 && echo opened >  $FETEST2|| echo closed > $FETEST2

#Checking if MythFrontend is running

if (cat $FETEST2 | grep closed ); then
  echo "$REMOTE is up but MythFrontend doesn't seem to be running" > $OUTPUTFILE2

else

echo -e "query location\nexit" | nc $REMOTE 6546 > $OUTPUTFILETMP2
fi


#Checking for TV recording Menu
if (cat $OUTPUTFILETMP2 | grep PlaybackBox ); then
  echo "$REMOTE is Idle in TV Recordings Menu" > $OUTPUTFILE2
else

#Checking for Program Guide
if (cat $OUTPUTFILETMP2 | grep GuideGrid ); then
  echo "$REMOTE is in TV Guide" > $OUTPUTFILE2
else

#Checking for MythVideo Gallery
if (cat $OUTPUTFILETMP2 | grep videogallery ); then
  echo "MythVideo Menu On $REMOTE is Idle" > $OUTPUTFILE2
else

#Checking for MythVideo Listings
if (cat $OUTPUTFILETMP2 | grep videolistings); then
  echo "MythVideo Menu On $REMOTE is Idle" > $OUTPUTFILE2
else

#Checking for MythVideo Browser
if (cat $OUTPUTFILETMP2 | grep videobrowser); then
  echo "MythVideo Menu On $REMOTE is Idle" > $OUTPUTFILE2
else

#Checking for MythMusics
if (cat $OUTPUTFILETMP2 | grep playmusic ); then
  echo "Playing Music Cant you Hear?" > $OUTPUTFILE2
else

#Checking for MainMenu
if (cat $OUTPUTFILETMP2 | grep MainMenu ); then
  echo "$REMOTE is in The Main Menu" > $OUTPUTFILE2
else

#Checking for Live TV
if (cat $OUTPUTFILETMP2 | grep "Playback LiveTV" ); then
  echo "$REMOTE is Watching Live TV" > $OUTPUTFILE2
else

#Checking for MythVideo Playback
if (cat $OUTPUTFILETMP2 | grep "Playback Video" ); then
  echo "MythVideo On $REMOTE is playing $FILENAME2" > $OUTPUTFILE2
else

if (cat $OUTPUTFILETMP2 | grep  "Playback Recorded" ); then
    echo "MythTV On $REMOTE is playing recording $RECFILE2" > $OUTPUTFILE2
else



#if none of the above simply display then query status output
if (cat $OUTPUTFILETMP2 | grep "#"); then
cat   $OUTPUTFILETMP2 | grep "#" > $OUTPUTFILE2



fi
  fi
     fi
        fi
           fi
              fi
                fi
                   fi
                      fi
                        fi
                          fi
                            fi
                               fi

考慮到我必須寫多少才能在 conky 中啟用幾行，我認為這是相當微妙的。不管怎樣，這對我來說很有趣，我希望人們嘗試一下，如果您需要任何幫助，請告訴我它是如何回复的，如果您在設置時遇到任何問題，我很樂意為您提供幫助。

參考

答案3

這是關於在任何 ubuntu 機器上使用 conky 查看後端錄製資訊的操作方法。這是透過在使用 conky 的 ubuntu 機器上安裝 mythtv-status 來實現的。我稍微修改了mythtv-status。

  1. /home/username/.mythtv/config.xml將您的 mythbuntu 盒子複製到本機 ubuntu 桌面/home/username/.mythtv/config.xml

  2. 編輯 config.xml 檔案以反映後端的 IP 位址

    gedit ~/.mythtv/config.xml

    編輯這一行。將 localhost 變更為您後端的 IP 位址。就我而言

    <DBHostName>localhost</DBHostName>

    變成：

    <DBHostName>192.168.15.3</DBHostName>

  3. 將 config.xml 連結到/root/.mythtv/config.xml

    sudo mkdir /root/.mythtv
sudo ln -s ~/.mythtv/config.xml /root/.mythtv/config.xml

    這是為了修復 mytv 狀態下的 perl api 警告。

  4. 安裝 mythv-status

    sudo apt-get 更新 sudo apt-get 安裝 mytv-status

  5. 編輯 mytv-status 以反映我的更改。

    sudo gedit /usr/bin/mythtv-status

    在第 21 行左右，將 localhost 變更為後端的 ip 位址

    my $host = "localhost";

    在我的例子中它變成了。

    my $host = "192.168.15.3";

  6. 編輯 .conkyrc 檔案以新增輸出。

    gedit ~.conkyrc

    在頂部附近新增：

    text_buffer_size 1024

    在底部添加

    ${color #0077ff} ${execi 300 perl /usr/bin/mythtv-status KISP}

變更顏色以對應您目前的 .conkyrc 配置。

執行conky進行測試。

參考
