中括弧内のノードの定義

中括弧内のノードの定義

中括弧 {} 内にノードを定義しようとしています:

\documentclass{article}

\usepackage{tikz}
\usepackage{tikz-qtree}

\begin{document}

\begin{tikzpicture}
\Tree [.CP \node(y){here}; [.C$'$ C [.TP \edge[roof]; {Some text \node(x){here};} ]]]
\end{tikzpicture}

\end{document}

tikz-qtree が文字列「Some text here」を単一の単位として扱うようにしたいので、{} 環境内でノード x を定義する必要があります。ただし、最初または 2 番目の閉じ括弧の後にセミコロンを置くと、機能しません。

答え1

屋根付きノード内のテキストは内部的にはノード自体であり、ノード内にノードを埋め込むことはできないため、この問題には少し異なる方法で対処する必要があります。基本的な考え方は、屋根付きノードの親ノードを名前付きノードにすることです。次に、たとえば各ノードからの矢印を表示したい場合は、矢印の開始点を親ノードに対してオフセットする必要があります。次に例を示します。

\documentclass{article}

\usepackage{tikz}
\usepackage{tikz-qtree}

\begin{document}

\begin{tikzpicture}
\Tree [.CP \node(y){here}; [.C$'$ C [.\node(x){TP}; \edge[roof];  {Some text here} ]]]
\draw [->] (x.south)++(.9,-1) to[out=-90,in=-90,looseness=2] (y.south);
\end{tikzpicture}

\end{document}

別の方法 (おそらく少し簡単です) は、屋根のテキスト自体をノードとして定義し、パラメータを使用して[xshift]矢印の開始点を目的の場所に移動するだけです。

\documentclass{article}

\usepackage{tikz}
\usepackage{tikz-qtree}

\begin{document}

\begin{tikzpicture}
\Tree [.CP \node(y){here}; [.C$'$ C [.TP \edge[roof];  \node(x){Some text here}; ]]]
\draw [->] ([xshift=2.5em]x.south) to[out=-90,in=-90,looseness=2] (y.south);
\end{tikzpicture}

\end{document}

コードの出力

答え2

万が一、誰にも気づかれなかった場合に備えて言っておくと、私はforest木を描くときに好む傾向があります。

この解決策では、「ここ」という単語を手動で繰り返したり、矢印の開始位置を手動で調整したりする必要はありません。マニュアルの 20 ページの例に基づいていますが、少し間違っている可能性があります。

  • triangle屋根に使用される
  • スタイルはmove={}{}2 つの引数を取るように定義されています。最初の引数はコンテンツのコピー先のノードを指定し、2 番目の引数は現在のノードに追加する追加のテキストを指定します。

これを正確に実行したくないと思うかもしれないので、これはすぐに使用できるソリューションというよりは、説明のためのものです。あなたが示した例では、 と入力し、move={<specification of target node>}{Some text}ソース ノードのコンテンツを として指定しますhere

すると、ソース ノードには が含まれSome text here、ターゲット ノードには が含まれ、ソース ノードのすぐ下の点とターゲット ノードのすぐ下のhere点の間に矢印が描画されます。herehere

ターゲット ノードを指定するために、「相対ノード ウォーク」を使用しました。ただし、, name=targetターゲット ノードに を追加してから と入力するだけでも同じように実行できますmove={target}{Some text}。ほとんどの場合、この方法の方が簡単でしょう。このアイデアを示すために、ツリーにコメント付きコードとしてこの代替案を追加しました。

\documentclass[tikz,border=5pt]{standalone}
\usepackage{forest}
\begin{document}
  \newlength{\sourcetextaddwidth}
  \begin{forest}
    for tree={
      parent anchor=south,
      child anchor=north,
      fit=rectangle
    },
    move/.style n args=2{% page 20 of forest manual
      before typesetting nodes={
        TeX={
          \settowidth{\sourcetextaddwidth}{#2}
        },
        #1.content={##1},
        content={#2 ##1},
        tikz={
          \draw[->] (.south) +(.5\sourcetextaddwidth,0) to [out=south west, in=south] (#1);
        },
      },
    },
    [CP
      [this is the target node to which text will be moved%, name=target
      ]
      [C$'$
        [C
        ]
        [TP
          [here, triangle, move={!r1}{Some text}% move={target}{Some text}
          ]
        ]
      ]
    ]
  \end{forest}
\end{document}
