結合されたセル、複数のインデックス、テキストの折り返しを含む表

Question

こんな感じのテーブルが欲しいです。こちらは画像を別のタブで開くためのリンク。

私にとって重要なのは構造です。フォーマットは、他のものと何かしらの違いを際立たせたいことを示すためだけのものです。

どうすればいいですか:

1. データが特定の長さを超える場合は、テキストが折り返されることを確認します。
2. 画像のように、右下のセルに複数列を使用しますか?

私が持っているものは次のとおりです:

\documentclass[11pt]{article}
\usepackage{multirow}
\begin{document}
 % Text data placeholder. May be long enough that it needs to be wrapped.
\begin{table}[ht]
    \begin{center}
        \begin{tabular}{cccc}
            \hline
            \multirow{2}{*}{Outer index 1} & Inner index 1.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & Inner index 1.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
            \multirow{2}{*}{Outer index 2} & Inner index 2.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & Inner index 2.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
            \multirow{6}{*}{Outer index 3} &  Inner index 3.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.3 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.4 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.5 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.5 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.6 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
        \end{tabular}
    \end{center}
\end{table}

\end{document}

より良いフォーマットは大歓迎です。自由に独自のタッチを加えてください。

Answer 1

以下が含まれます:

• tabularxテキスト幅にX合うタイプの列とテーブル
• \multicolumn 2列にまたがるセルの場合
• \multirow最初の列のテキストを垂直中央に配置するために調整された値
• 前者はテーブルの周りに余分な空白を追加するので、center環境を に置き換えた。\centering

• 間隔を改善するためにパッケージの水平線を使用しましたbooktabs。

  \documentclass[11pt]{article}

  \usepackage{multirow}
  \usepackage{geometry}
  \usepackage{tabularx}
  \usepackage{booktabs}
  \usepackage{ragged2e}
  \begin{document}

  \begin{table}[ht]
      \centering
          \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
              \toprule
              \multirow{6}{*}{Outer index 1} & Inner index 1.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              & Inner index 1.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              \midrule
              \multirow{6}{*}{Outer index 2} & Inner index 2.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              & Inner index 2.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              \midrule
              \multirow{9}{*}{Outer index 3} &  Inner index 3.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              &Inner index 3.2 & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
              &Inner index 3.3 & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
              \bottomrule
          \end{tabularx}
  \end{table}

  \end{document}


---

multirowここでは、 2 番目の列の内容にも以下を使用しました。

\documentclass[11pt]{article}

\usepackage{multirow}
\usepackage{geometry}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{ragged2e}
\begin{document}

\begin{table}[ht]
    \centering
        \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
            \toprule
            \multirow{6}{*}{Outer index 1} & \multirow{3}{*}{Inner index 1.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 1.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{6}{*}{Outer index 2} & \multirow{3}{*}{Inner index 2.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 2.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{9}{*}{Outer index 3} &  \multirow{3}{*}{Inner index 3.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 3.2} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            & \multirow{3}{*}{Inner index 3.3} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            \bottomrule
        \end{tabularx}
\end{table}

\end{document}

---

2 番目の列のテキストを垂直方向に中央揃えにするには、次の MWE に示すように、makecell垂直方向に中央揃えされたタイプの列と組み合わせてパッケージを使用することもできます。X

\documentclass[11pt]{article}

\usepackage{multirow}
\usepackage{geometry}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{ragged2e}
\usepackage{makecell}
\renewcommand{\tabularxcolumn}[1]{m{#1}}
\begin{document}

\begin{table}[ht]
    \centering
        \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
            \toprule
            \multirow{6}{*}{Outer index 1} & \makecell[cc]{Inner index 1.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 1.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{6}{*}{Outer index 2} & \makecell[cc]{Inner index 2.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 2.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{9}{*}{Outer index 3} &  \makecell[cc]{Inner index 3.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 3.2} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            & \makecell[cc]{Inner index 3.3} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            \bottomrule
        \end{tabularx}
\end{table}

\end{document}
