論文のために、より高品質の画像が必要ですが、Tikz のスキルが思うようにありません。
円、点、矢印の作成は途中までできましたが、想像どおり、ノードの 1 つで円の一部が消去されるなどの詳細を作成できません。または、矢印付きの奇妙な曲線 T_T。
私が使用しているドキュメントのクラスは、article クラスのバリエーションです。
これまで私がやったことは以下の通りです:
\documentclass{article}
%Packages for the TIKZ%
\usepackage{xcolor}
\definecolor{azul}{RGB}{187,233,255}
\usepackage{tikz}
\usetikzlibrary{arrows,positioning}
\tikzset{
%Define standard arrow tip
>=stealth',
% Define arrow style
pil/.style={
->,
thick,
shorten <=2pt,
shorten >=2pt,}
}
\begin{document}
\begin{tikzpicture}
\draw[thick,->] (0,0) -- (5,0) node[anchor=north west] {x};
\draw[thick,->] (0,0) -- (0,5) node[anchor=south east] {y};
\filldraw[azul, draw=black, thick] (2.5,2.5) circle (2cm);
\filldraw[white, draw=black, thick] (2.5,2.5) circle (0.75cm);
\filldraw[black] (2.5,2.5) circle (3pt) node [anchor= south] {$\delta$};
\filldraw[black] (2.11,2.05) circle (3pt);
\draw[thick,->] (2.5,2.5) -- (3.03,3.03);
\draw[thick] (2.5,2.5) -- (1.8,3.07) node [anchor= south east] {$\epsilon$};
\draw[thick,->] (1.3,3.50) -- (0.93,3.78);
\end{tikzpicture}
\end{document}
私が再現しようとしているイメージは次のとおりです。
答え1
出発点と使用方法この素敵な答えからアンリ・メンケ左側の画像のみです。希望する曲線の形状に応じて座標を手動で設定する必要があります。
\documentclass[margin=3mm]{standalone}
%Packages for the TIKZ%
\usepackage{xcolor}
\definecolor{azul}{RGB}{187,233,255}
\usepackage{tikz}
\usetikzlibrary{arrows,positioning}
\usetikzlibrary{decorations.markings}
\tikzset{
%Define standard arrow tip
>=stealth',
% Define arrow style
pil/.style={
->,
thick,
shorten <=2pt,
shorten >=2pt,}
}
\tikzset{
set arrow inside/.code={\pgfqkeys{/tikz/arrow inside}{#1}},
set arrow inside={end/.initial=>, opt/.initial=},
/pgf/decoration/Mark/.style={
mark/.expanded=at position #1 with
{
\noexpand\arrow[\pgfkeysvalueof{/tikz/arrow inside/opt}]{\pgfkeysvalueof{/tikz/arrow inside/end}}
}
},
arrow inside/.style 2 args={
set arrow inside={#1},
postaction={
decorate,decoration={
markings,Mark/.list={#2}
}
}
},
}
\begin{document}
\begin{tikzpicture}
\coordinate (A) at (2.11,2.05);
\coordinate (B) at (2.5,2.5);
\draw[thick,->] (0,0) -- (5,0) node[anchor=north west] {x};
\draw[thick,->] (0,0) -- (0,5) node[anchor=south east] {y};
\filldraw[azul, draw=black, thick] (2.5,2.5) circle (2cm);
\filldraw[white, draw=black, thick] (2.5,2.5) circle (0.75cm);
\draw[thick,->] (2.5,2.5) -- (3.03,3.03);
\draw[thick] (2.5,2.5) -- (1.8,3.07) node [anchor= south east] {$\epsilon$};
\draw[thick,->] (1.3,3.50) -- (0.93,3.78);
\draw[blue, thick] plot [smooth,tension=1]
coordinates {(A) (2.3,2.1) (2.65,1.6) (3.5,1.8) (4,2.5) (B)}
[arrow inside={end=stealth,opt={blue,scale=2}}{0.3,0.5,0.75,0.97}];
\filldraw[black] (B) circle (3pt) node [anchor= south] {$\delta$};
\filldraw[black] (A) circle (3pt);
\end{tikzpicture}
\end{document}
答え2
2つの曲線はTikZで異なるようです。最初の曲線は趣味曲線と2番目は楕円マーキングも異なるため、プリアンブルで 2 種類の装飾 (異なる種類の引数を使用) を定義しました。
2 番目の曲線の箇条書きは試行錯誤で作成されます。後で図面が必要になり、少し修正する必要がある場合は、楕円に沿ったパラメータを使用して箇条書きを定義する方がよいでしょう。
\documentclass[11pt, margin=1cm]{standalone}
\usepackage{tikz}
\definecolor{azul}{RGB}{187, 233, 255}
\usetikzlibrary{arrows}
\usetikzlibrary{calc, math, hobby, decorations.markings}
\tikzset{
>=stealth', % define standard arrow tip
pil/.style={ % define arrow style
->,
thick,
shorten <=2pt,
shorten >=2pt
},
show two/.style={% define markings along path
decorate, decoration={markings,
mark=between positions .1 and .99 step .5 with {
{\arrow[blue, line width=.8pt]{#1}};
}
}
},
show three/.style={% define markings along path
decorate, decoration={markings,
mark=between positions .3 and .99 step #1 with {
{\arrow[blue, line width=.8pt]{>}};
}
}
}
}
\begin{document}
\tikzmath{
real \R, \r;
\R = 2;
\r = .75;
}
\begin{tikzpicture}[every node/.style={color=black, scale=.7}]
\draw[very thin, ->] (0,0) -- (5,0) node[anchor=north west] {$x$};
\draw[very thin, ->] (0,0) -- (0,5) node[anchor=south east] {$y$};
\path (2.5, 2.5) coordinate (B);
\path
($(B)+(240:.7*\r)$) coordinate (A1)
($(B)+(270:.65*\r)$) coordinate (A2)
($(B)+(269:1.3*\r)$) coordinate (A3)
($(B)+(-70:1.8*\r)$) coordinate (A4)
($(B)+(-25:2.2*\r)$) coordinate (A5)
($(B)+(15:2.*\r)$) coordinate (A6)
($(B)+(-10:.9*\r)$) coordinate (A7)
($(B)+(-30:.8*\r)$) coordinate (A8);
\draw[fill=azul, even odd rule] (B) circle (\R) (B) circle (\r);
\draw[->, gray] (B) -- node[pos=.6, fill=azul] {$\epsilon$} +(135: \R);
\draw[->, gray] (B) -- node[anchor=west, inner sep=1pt] {$\delta$} +(85: \r);
\draw[blue, thick, postaction={show three={.28}}]
(A1) to[curve through={(A2) (A3) (A4) (A5) (A6) (A7) (A8)}] (B);
\filldraw (B) circle (1.5pt) (A1) circle (1.5pt)
node[anchor=north east, inner sep=1pt] {$(\phi(0),\psi(0))$};
\end{tikzpicture}
\begin{tikzpicture}[every node/.style={color=black, scale=.7}]
\draw[very thin, ->] (0,0) -- (5,0) node[anchor=north west] {$x$};
\draw[very thin, ->] (0,0) -- (0,5) node[anchor=south east] {$y$};
\path (2.5, 2.5) coordinate (B);
\path ($(B)+(155:.76*\r)$) coordinate (A1);
\draw[fill=azul, even odd rule] (B) circle (\R) (B) circle (\r);
\draw[->, gray] (B) -- node[pos=.6, fill=azul] {$\epsilon$} +(130: \R);
\draw[->, gray] (B)
-- node[pos=.4, anchor=south east, inner sep=1pt] {$\delta$} +(55: \r);
\draw[blue, thick, postaction={show two={<}}, rotate=35]
(B) ellipse[x radius={\R-.01}, y radius=.5];
\filldraw (B) circle (1.5pt) (A1) circle (1.5pt)
node[anchor=south east, inner sep=1pt] {$(\phi(0),\psi(0))$};
\end{tikzpicture}
\end{document}
