Ich schreibe eine Figur mit mehreren Segmenten und es sieht so aus, als ob Tikz das nicht mag. Also habe ich hinzugefügt:
\usepgfplotslibrary{external}
\usetikzlibrary{matrix,chains,positioning,decorations.pathreplacing,arrows}
\tikzexternalize
Es hat gut funktioniert, und plötzlich wird die Kompilierung blockiert, wenn ich nur noch einen Bogen hätte.
\write18 enabled.
entering extended mode
Wenn ich in myFigure.log nachschaue, kann ich nichts Falsches erkennen. Es endet mit
Package: ifpdf 2011/01/30 v2.3 Provides the ifpdf switch (HO)
Package ifpdf Info: pdfTeX in PDF mode is detected.
)
Package pdftexcmds Info: LuaTeX not detected.
Package pdftexcmds Info: \pdf@primitive is availabl
Da ich keine Fehlermeldung bekomme, weiß ich wirklich nicht, wo ich suchen soll.
Hier ist ein Beispiel für zwei Abbildungen, die auf meinem System nicht kompiliert werden:
\documentclass[11pt,a4]{article}
\usepackage{graphics}
\usepackage{url}
\usepackage{amsmath}
\usepackage{amssymb}
\usepackage[dcucite,abbr]{harvard}
\usepackage{tikz}
\usepackage{pgfplots}
\pgfplotsset{compat=1.8}
\usepgfplotslibrary{external}
\usetikzlibrary{matrix,chains,positioning,decorations.pathreplacing,arrows}
\tikzexternalize
\textwidth 150mm \textheight 230mm \topmargin -20mm
\renewcommand{\baselinestretch}{1.25}
\marginparwidth 17mm
\oddsidemargin 7mm
\newcommand{\cvd}{\hfill\raisebox{3pt}{\fbox{\rule{0mm}{1mm}\hspace*{1mm}\rule{0mm}{1mm}}\,} \vspace{5mm}}
\newcommand{\proof}{\vspace{1mm}\noindent{\it Proof}\quad}
\renewcommand{\thefootnote}{\arabic{footnote}}
\newcounter{bean}
\date{}
\begin{document}
\pagestyle{empty}
\begin{figure}[h]\begin{center}
\begin{tikzpicture}[
init/.style={
draw,
circle,
inner sep=2pt,
font=\Huge,
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; & \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; & \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; & \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};
\node [init, left=of m] (s) {$s$};
\node [init, right=of m] (e) {$e$};
\path (s) edge[->, dotted] (x0);
\path (s) edge[->, dotted] (y0);
\path (s) edge[->, dotted] (z0);
\path (s) edge[->, dotted] (x1);
%\path (s) edge[->, dotted] (y1);
\path (s) edge[->, thick] (z1);
\path (s) edge[->, dotted] (x2);
%\path (s) edge[->, dotted] (y2);
\path (s) edge[->, dotted] (z2);
\path (s) edge[->, dotted] (x3);
%\path (s) edge[->, dotted] (y3);
\path (s) edge[->, dotted] (z3);
\path (s) edge[->, dotted] (x4);
%\path (s) edge[->, dotted] (y4);
\path (s) edge[->, dotted] (z4);
\path (s) edge[->, dotted] (x5);
%\path (s) edge[->, dotted] (y5);
\path (s) edge[->, dotted] (z5);
\path (s) edge[->, dotted] (x6);
%\path (s) edge[->, dotted] (y6);
\path (s) edge[->, dotted] (z6);
\path (s) edge[->, dotted] (x7);
%\path (s) edge[->, dotted] (y7);
\path (s) edge[->, dotted] (z7);
\path (x0) edge[->, dotted] (x1);
\path (x0) edge[->, dotted] (y1);
\path (x0) edge[->, dotted] (z1);
\path (y0) edge[->, dotted] (x1);
\path (y0) edge[->, dotted] (y1);
\path (y0) edge[->, dotted] (z1);
\path (z0) edge[->, dotted] (x1);
\path (z0) edge[->, dotted] (y1);
\path (z0) edge[->, dotted] (z1);
\path (x1) edge[->, dotted] (x2);
\path (x1) edge[->, dotted] (y2);
\path (x1) edge[->, dotted] (z2);
\path (y1) edge[->, dotted] (x2);
\path (y1) edge[->, dotted] (y2);
\path (y1) edge[->, dotted] (z2);
\path (z1) edge[->, dotted] (x2);
\path (z1) edge[->, thick] (y2);
\path (z1) edge[->, dotted] (z2);
\path (x2) edge[->, dotted] (x3);
\path (x2) edge[->, dotted] (y3);
\path (x2) edge[->, dotted] (z3);
\path (y2) edge[->, dotted] (x3);
\path (y2) edge[->, thick] (y3);
\path (y2) edge[->, dotted] (z3);
\path (z2) edge[->, dotted] (x3);
\path (z2) edge[->, dotted] (y3);
\path (z2) edge[->, dotted] (z3);
\path (x3) edge[->, dotted] (x4);
\path (x3) edge[->, dotted] (y4);
\path (x3) edge[->, dotted] (z4);
\path (y3) edge[->, dotted] (x4);
\path (y3) edge[->, thick] (y4);
\path (y3) edge[->, dotted] (z4);
\path (z3) edge[->, dotted] (x4);
\path (z3) edge[->, dotted] (y4);
\path (z3) edge[->, dotted] (z4);
\path (x4) edge[->, dotted] (x5);
\path (x4) edge[->, dotted] (y5);
\path (x4) edge[->, dotted] (z5);
\path (y4) edge[->, thick] (x5);
\path (y4) edge[->, thick] (y5);
\path (y4) edge[->, dotted] (z5);
\path (z4) edge[->, dotted] (x5);
\path (z4) edge[->, dotted] (y5);
\path (z4) edge[->, dotted] (z5);
\path (x5) edge[->, thick] (x6);
\path (x5) edge[->, dotted] (y6);
\path (x5) edge[->, dotted] (z6);
\path (y5) edge[->, thick] (x6);
\path (y5) edge[->, dotted] (y6);
\path (y5) edge[->, dotted] (z6);
\path (z5) edge[->, dotted] (x6);
\path (z5) edge[->, dotted] (y6);
\path (z5) edge[->, dotted] (z6);
\path (x6) edge[->, thick] (x7);
\path (x6) edge[->, dotted] (y7);
\path (x6) edge[->, dotted] (z7);
\path (y6) edge[->, dotted] (x7);
\path (y6) edge[->, dotted] (y7);
\path (y6) edge[->, dotted] (z7);
\path (z6) edge[->, dotted] (x7);
\path (z6) edge[->, dotted] (y7);
\path (z6) edge[->, dotted] (z7);
\path (x0) edge[->, dotted] (e);
%\path (y0) edge[->, dotted] (e);
\path (z0) edge[->, dotted] (e);
\path (x1) edge[->, dotted] (e);
%\path (y1) edge[->, dotted] (e);
\path (z1) edge[->, dotted] (e);
\path (x2) edge[->, dotted] (e);
%\path (y2) edge[->, dotted] (e);
\path (z2) edge[->, dotted] (e);
\path (x3) edge[->, dotted] (e);
%\path (y3) edge[->, dotted] (e);
\path (z3) edge[->, dotted] (e);
\path (x4) edge[->, dotted] (e);
%\path (y4) edge[->, dotted] (e);
\path (z4) edge[->, dotted] (e);
\path (x5) edge[->, dotted] (e);
%\path (y5) edge[->, dotted] (e);
\path (z5) edge[->, dotted] (e);
\path (x6) edge[->, dotted] (e);
%\path (y6) edge[->, dotted] (e);
\path (z6) edge[->, dotted] (e);
\path (x7) edge[->, dotted] (e);
\path (x7) edge[->, thick] (e);
\path (z7) edge[->, dotted] (e);
\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};
\node [above=of A1] (types) {Title 1};
\node [above=of m] (types) {Title 2};
\node [below=of z0, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{a}};
\node [below=of z1, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{b}};
\node [below=of z2, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{c}};
\node [below=of z3, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{d}};
\node [below=of z4, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{e}};
\node [below=of z5, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{f}};
\node [below=of z6, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{g}};
\node [below=of z7, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{h}};
\end{tikzpicture}
\end{center}\end{figure}
\begin{figure}[h!]\begin{center}
\begin{tikzpicture}[
init/.style={
draw,
circle,
inner sep=2pt,
font=\Huge,
%join = by -latex
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; & \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; & \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; & \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};
\node [init, left=of m] (s) {$s$};
\node [init, right=of m] (e) {$e$};
\path (s) edge[->, dotted, very thick] node {\textbf{7}} (x0);
\path (s) edge[->, dotted, very thick] node {\textbf{1}} (y0);
\path (s) edge[->, dotted, very thick] node {\textbf{2}} (z0);
\path (s) edge[->, dotted] (x1);
\path (s) edge[->, dotted] (e);
\path (s) edge[->, dotted] (z1);
\path (s) edge[->, dotted] (x2);
\path (s) edge[->, dotted] (z2);
\path (s) edge[->, dotted] (x3);
\path (s) edge[->, dotted] (z3);
\path (s) edge[->, dotted] (x4);
\path (s) edge[->, dotted] (z4);
\path (s) edge[->, dotted] (x5);
\path (s) edge[->, dotted] (z5);
\path (s) edge[->, dotted] (x6);
\path (s) edge[->, dotted] (z6);
\path (s) edge[->, dotted] (x7);
\path (s) edge[->, dotted] (z7);
\path (x0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (x0) edge[->, dotted] (y1);
\path (x0) edge[->, dotted] (z1);
\path (y0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (y0) edge[->, dotted] (z1);
\path (z0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (z0) edge[->, dotted] (y1);
\path (z0) edge[->, dotted] (z7);
\path (x1) edge[->, dotted] (x7);
\path (x1) edge[->, dotted, very thick] node {\textbf{1}} (y2);
\path (x1) edge[->, dotted] (z2);
\path (y1) edge[->, dotted] (x2);
\path (y1) edge[->, dotted, very thick] node {\textbf{1}} (y2);
\path (y1) edge[->, dotted] (z2);
\path (z1) edge[->, dotted] (x2);
\path (z1) edge[->, dotted, very thick] node {\textbf{1}} (y2);
\path (x2) edge[->, dotted] (y3);
\path (x2) edge[->, dotted, very thick] node {\textbf{2}} (z3);
\path (y2) edge[->, dotted] (x3);
\path (y2) edge[->, dotted, very thick] node {\textbf{2}} (z3);
\path (z2) edge[->, dotted] (x3);
\path (z2) edge[->, dotted] (y3);
\path (z2) edge[->, dotted, very thick] node {\textbf{2}} (z3);
\path (x3) edge[->, dotted] (y4);
\path (x3) edge[->, dotted] (z4);
\path (y3) edge[->, dotted] (x4);
%\path (y3) edge[->, dotted] (y4);
\path (y3) edge[->, dotted] (z4);
\path (z3) edge[->, dotted] (x4);
\path (z3) edge[->, dotted] (y4);
%\path (z3) edge[->, dotted] (z4);
%
%\path (x4) edge[->, dotted] (x5);
\path (x4) edge[->, dotted] (y5);
\path (x4) edge[->, dotted[ (z5);
\path (y4) edge[->, dotted] (x5);
%\path (y4) edge[->, dotted] (y5);
\path (y4) edge[->, dotted] (z5);
%\path (z4) edge[->, dotted] (x5);
%\path (z4) edge[->, dotted] (y5);
%\path (z4) edge[->, dotted] (z5);
%
%\path (x5) edge[->, dotted] (x6);
%\path (x5) edge[->, dotted] (y6);
%\path (x5) edge[->, dotted] (z6);
%\path (y5) edge[->, dotted] (x6);
%\path (y5) edge[->, dotted] (y6);
%\path (y5) edge[->, dotted] (z6);
%\path (z5) edge[->, dotted] (x6);
%\path (z5) edge[->, dotted] (y6);
%\path (z5) edge[->, dotted] (z6);
%
%\path (x6) edge[->, dotted] (x7);
%\path (x6) edge[->, dotted] (y7);
%\path (x6) edge[->, dotted] (z7);
%\path (y6) edge[->, dotted] (x7);
%\path (y6) edge[->, dotted] (y7);
%\path (y6) edge[->, dotted] (z7);
%\path (z6) edge[->, dotted] (x7);
%\path (z6) edge[->, dotted] (y7);
%\path (z6) edge[->, dotted] (z7);
%
%\path (x0) edge[->, dotted] (e);
%\path (y0) edge[->, dotted] (e);
%\path (z0) edge[->, dotted] (e);
%\path (x1) edge[->, dotted] (e);
%\path (y1) edge[->, dotted] (e);
%\path (z1) edge[->, dotted] (e);
%\path (x2) edge[->, dotted] (e);
%\path (y2) edge[->, dotted] (e);
%\path (z2) edge[->, dotted] (e);
%\path (x3) edge[->, dotted] (e);
%\path (y3) edge[->, dotted] (e);
%\path (z3) edge[->, dotted] (e);
%\path (x4) edge[->, dotted] (e);
%\path (y4) edge[->, dotted] (e);
%\path (z4) edge[->, dotted] (e);
%\path (x5) edge[->, dotted] (e);
%\path (y5) edge[->, dotted] (e);
%\path (z5) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (x6) edge[->, dotted] (e);
%\path (y6) edge[->, dotted] (e);
%\path (z6) edge[->, dotted] (e);
%\path (x7) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (y7) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (z7) edge[->, dotted, very thick] node {\textbf{0}} (e);
\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};
\node [below=of z0, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{a}};
\node [below=of z1, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{b}};
\node [below=of z2, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{c}};
\node [below=of z3, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{d}};
\node [below=of z4, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{e}};
\node [below=of z5, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{f}};
\node [below=of z6, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{g}};
\node [below=of z7, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{h}};
\end{tikzpicture}
\end{center}\end{figure}
\end{document}
Dies erstellt die Dateien test-figure0.dep, .dpth, .log, .md5 und .pdf, aber für figure1 gibt es alle außer PDF. Ich verwende TeXShop zum Kompilieren mit „pdflatex -shell-escape“ als Standardbefehl
Antwort1
Das Problem besteht in der übermäßigen Anzahl von edge
in Ihrer zweiten Abbildung, die irgendwie (ich habe den genauen Grund nicht herausgefunden) den Compiler einfriert, ohne dass ein „Nicht genügend Arbeitsspeicher“-Fehler auftritt.
Das Externalisieren der Abbildung hilft nicht, da pdflatex schließlich sowieso über die externe Abbildung aufgerufen werden muss, was den Compiler erneut einfriert.
Zwei Strategien können den Code und die Kompilierung verbessern:
Verwenden Sie statt
\path (a) edge[options] (b);
. Die Verwendung\draw[options] (a) -- (b);
von draw anstelle von edge reduziert den Speicherverbrauch (ich weiß nicht, warum)Verwenden Sie Schleifen! Auch wenn mir kein Grund einfällt, warum dies den Speicherverbrauch reduzieren würde, würde es den Code zumindest kürzer, lesbarer und wartbarer machen.
Dies ist meine Interpretation der zweiten Zahl.
\begin{tikzpicture}[
init/.style={
draw,
circle,
inner sep=2pt,
font=\Huge,
%join = by -latex
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; & → \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; & → \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; & → \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};
\node [init, left=of m] (s) {$s$};
\node [init, right=of m] (e) {$e$};
\foreach \start/\end/\label in {
s/x0/7, s/y0/1, s/z0/2,
x0/x1/7, y0/x1/7, z0/x1/7,
x1/y2/1, y1/y2/1, z1/y2/1,
x2/z3/2, y2/z3/2, z2/z3/2 } {
\draw[->,dotted,very thick] (\start) -- (\end) node[midway] {\textbf{\label}};
};
\foreach \n [count=\previous from 0] in {1,...,7} {
\draw[->,dotted] (s) -- (x\n); \draw[->,dotted] (x\n) -- (e);
\draw[->,dotted] (s) -- (z\n); \draw[->,dotted] (z\n) -- (e);
\draw[->,dotted] (x\previous) -- (y\n);
\draw[->,dotted] (x\previous) -- (z\n);
\draw[->,dotted] (y\previous) -- (x\n);
\draw[->,dotted] (y\previous) -- (z\n);
\draw[->,dotted] (z\previous) -- (x\n);
\draw[->,dotted] (z\previous) -- (y\n);
}
\path (s) edge[->, dotted] (e);
\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};
\foreach \letter [count=\n from 0]in {a,b,c,d,e,f,g,h} {
\node [below=of z\n, xshift=-0.3cm, yshift=0.5cm] {\rotatebox{60}{\letter}};
}
\end{tikzpicture}
Dieser Code lässt sich problemlos kompilieren und erzeugt in kurzer Zeit:
Aktualisieren
Mir sind einige fehlende Kanten aufgefallen (also, ich bin mir nicht sicher, was die beabsichtigte Abbildung ist) und eine Möglichkeit, den Code mit inneren Schleifen noch weiter zu komprimieren, in dem Teil, der die Myriaden kleiner Kanten zwischen den Knoten zeichnet:
\foreach \n [count=\previous from 0] in {1,...,7} {
\draw[->,dotted] (s) -- (x\n); \draw[->,dotted] (x\n) -- (e);
\draw[->,dotted] (s) -- (z\n); \draw[->,dotted] (z\n) -- (e);
\foreach \s in {x,y,z} {
\foreach \e in {x,y,z} {
\draw[->,dotted] (\s\previous) -- (\e\n);
}
}
}
Das Ergebnis ist nun:
