Multiserver-Warteschlangensystem mit Tikz

Multiserver-Warteschlangensystem mit Tikz

Ich brauche den Server dieses Systems

\usepackage{graphicx}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{amsmath}
\usepackage{amsthm}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{tikz}
\usetikzlibrary{chains,shapes.multipart}
\usetikzlibrary{shapes}
\usetikzlibrary{automata,positioning}

\begin{document}
       \begin{figure}
       \centering
       \begin{tikzpicture}[start chain=going right,>=latex,node distance=0pt]
         \node[draw,rectangle,on chain,minimum size=1.5cm] (rr) {$I$};
         \node[draw,rectangle,on chain,draw=white,minimum size=1.3cm]{};
         % the rectangular shape with vertical lines
         \node[rectangle split, rectangle split parts=6,
         draw, rectangle split horizontal,text height=1cm,text depth=0.5cm,on chain,inner ysep=0pt] (wa) {};
         \fill[white] ([xshift=-\pgflinewidth,yshift=-\pgflinewidth]wa.north west) rectangle ([xshift=-15pt,yshift=\pgflinewidth]wa.south);
         % the circle
         \node[draw,circle,on chain,minimum size=1.5cm] (se) {$U$};
         % the arrows and labels
         \draw[->] (se.east) -- +(20pt,0) node[right] {$\mu$};
         \draw[<-] (wa.west) -- +(-20pt,0) node[left] {$\lambda$};
         \node[align=center,below] at (rr.south) {Input \\ process};
         \node[align=center,below] at (wa.south) {Queue \\ subsystem};
         \node[align=center,below] at (se.south) {Server \\ process};
       \end{tikzpicture}
          \caption{The model represented as a queuing system.}
             \label{fig:queue}
       \end{figure}
\end{document}

Bildbeschreibung hier eingeben

aus zwei parallel laufenden Subservern bestehen. Wie kann ich das machen?

Das ist, was ich erreichen möchte

Bildbeschreibung hier eingeben

Antwort1

Als etwas längere Methode können Sie mit dem folgenden Code etwas zeichnen:

\documentclass{article}
\usepackage{graphicx}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{amsmath}
\usepackage{amsthm}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{tikz}
\usetikzlibrary{chains,shapes.multipart}
\usetikzlibrary{shapes,calc}
\usetikzlibrary{automata,positioning}

\begin{document}
       \begin{figure}
       \centering
       \begin{tikzpicture}[start chain=going right,>=latex,node distance=0pt]
         \node[draw,rectangle,on chain,minimum size=1.5cm] (rr) {$I$};
         \node[draw,rectangle,on chain,draw=white,minimum size=1.3cm]{};
         % the rectangular shape with vertical lines
        \node[rectangle split, rectangle split parts=6,
        draw, rectangle split horizontal,text height=1cm,text depth=0.5cm,on chain,inner ysep=0pt] (wa) {};
         \fill[white] ([xshift=-\pgflinewidth,yshift=-\pgflinewidth]wa.north west) rectangle ([xshift=-15pt,yshift=\pgflinewidth]wa.south);
        \node at (wa.east) (A){};
        \draw [-latex] (A) --+(30:1.5) coordinate (B1);
        \draw [-latex] (A) --+(-30:1.5) coordinate (B2);
         % the circle
         \node [draw,circle,on chain,minimum size=1cm] at (B1) (se1) {$U_1$};
         \node [draw,circle,on chain,minimum size=1cm] at (B2) (se2) {$U_2$};
         \draw [-latex] (se1.east) --+(-25:1.65) coordinate (C1);
          \draw [-latex] (se2.east) --+(25:1.65) coordinate (C2);
         \node (O) at ($(C1)!0.5!(C2)$) {};
         \node [draw,circle,on chain,minimum size=3pt] at (O) (C3){};
         \draw [-latex] (C3)--+(0:2)node[right] {$\mu$};
         % the arrows and labels
      %   \draw[->] (se.east) -- +(20pt,0) node[right] {$\mu$};
         \draw[<-] (wa.west) -- +(-20pt,0) node[left] {$\lambda$};
         \node[align=center,below] at (rr.south) {Input \\ process};
         \node[align=center,below] at (wa.south) {Queue \\ subsystem};
        \node[align=center,below] at (se2.south) {Server \\ process};

       \end{tikzpicture}
          \caption{The model represented as a queuing system.}
             \label{fig:queue}
       \end{figure}
\end{document}

Bildbeschreibung hier eingeben
