Kombinationen von Ketten

Question

Ich habe gerade angefangen, die Kettenbibliothek zu verwenden. Ich möchte mit jeder Kette 3 Verständnisebenen zeigen

Kette 1. Ausgangsfelder Kette 2. Erklärung Kette 3. Bilder

An einer Stelle in meinem Dokument möchte ich chain 1nur, dann chain 1 & 2, dann chain 1 & 3und schließlich nur anzeigen chain 3.

Ich musste die Kette ausrichten und die Verwendung von right ofermöglicht mir nicht, ifAnweisungen zu verwenden. Ich brauche also nur ein wenig Hilfe, um denselben Code bedingt zu verwenden, um eine Kombination der Ketten zu erhalten.

Hier ist MWE

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}

\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going right,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        },
    every node/.append style = {
        on chain},
    ]

{[start chain=1]
   \node[Champs,]                       (Level1) {Field 1};
   \node[Champs,below=0.1cm of Level1]  (Level2) {Field 2};
   \node[Champs,below=0.1cm of Level2]  (Level3) {Field 3};
   \node[Champs,below=0.1cm of Level3,fill=\Couleur!50]     (Level4) {Field 4};
   \node[Champs,below=0.1cm of Level4]  (Level5) {Field 5};
   \node[Champs,below=0.1cm of Level5]  (Level6) {Field 6};
}

{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc,below=0.1cm of Desc1]     (Desc2) {Description a bit longer 2};
   \node[desc,below=0.1cm of Desc2]     (Desc3) {Description a bit longer 3};
   \node[desc,below=0.1cm of Desc3,fill=\Couleur!10]    (Desc4) {Description a bit longer 4};
   \node[desc,below=0.1cm of Desc4]     (Desc5) {Description a bit longer 4};
   \node[desc,below=0.1cm of Desc5]     (Desc6) {Description a bit longer 6};
}
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb1]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb,below=0.1cm of Symb2]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb3,fill=\Couleur!50] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb4]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb5]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}

\end{tikzpicture}

\end{document}

Answer 1

Ich glaube, Sie verwenden Ketten nicht richtig. Sie müssen nicht mehr alle „wenn“ hinzufügen, below=0.1cm of ...wenn Sie eine Kette verwenden going below. Ich habe einige „wenn“ hinzugefügt.

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}
\newif\ifChainTwo
\newif\ifChainThree
\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going below,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        },
    every node/.append style = {
        on chain},
    ]
%\ChainTwotrue
%\ChainThreetrue
{[start chain=1]
   \node[Champs,alias=Desc1]                       (Level1) {Field 1};
   \node[Champs]  (Level2) {Field 2};
   \node[Champs]  (Level3) {Field 3};
   \node[Champs,fill=\Couleur!50]     (Level4) {Field 4};
   \node[Champs]  (Level5) {Field 5};
   \node[Champs]  (Level6) {Field 6};
}
\ifChainTwo
{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc]     (Desc2) {Description a bit longer 2};
   \node[desc]     (Desc3) {Description a bit longer 3};
   \node[desc,fill=\Couleur!10]    (Desc4) {Description a bit longer 4};
   \node[desc]     (Desc5) {Description a bit longer 4};
   \node[desc]     (Desc6) {Description a bit longer 6};
}
\fi
\ifChainThree
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb,fill=\Couleur!50] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}
\fi
\end{tikzpicture}

\end{document}

Wenn Sie das Kommentarzeichen entfernen, \ChainTwotrueerhalten Sie

Wenn Sie das Kommentarzeichen entfernen, \ChainThreetrueerhalten Sie

Und wenn Sie beides auskommentieren, erhalten Sie

Bitte beachten Sie, dass man die Orangefärbung auch etwas automatischer gestalten könnte.

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}
\newif\ifChainTwo
\newif\ifChainThree
\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going below,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20,
        cond={4}{fill=\Couleur!50}
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5,
        cond={4}{fill=\Couleur!10}
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        cond={4}{fill=\Couleur!50}
        },
    every node/.append style = {
        on chain},
    cond/.code 2 args={\ifnum\tikzchaincount=#1
     \tikzset{#2}
    \fi}
    ]
\ChainTwotrue
\ChainThreetrue
{[start chain=1,nodes=Champs]
   \node[Champs,alias=Desc1]                       (Level1) {Field 1};
   \node[Champs]  (Level2) {Field 2};
   \node[Champs]  (Level3) {Field 3};
   \node[Champs]  (Level4) {Field 4};
   \node[Champs]  (Level5) {Field 5};
   \node[Champs]  (Level6) {Field 6};
}
\ifChainTwo
{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc]     (Desc2) {Description a bit longer 2};
   \node[desc]     (Desc3) {Description a bit longer 3};
   \node[desc]    (Desc4) {Description a bit longer 4};
   \node[desc]     (Desc5) {Description a bit longer 4};
   \node[desc]     (Desc6) {Description a bit longer 6};
}
\fi
\ifChainThree
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}
\fi
\end{tikzpicture}

\end{document}
