In meinem Abbildungsverzeichnis möchte ich das Wort „Abbildung“ nicht vor meinen Unterabbildungen haben. Außerdem möchte ich die Nummerierung der Unterabbildungen in Klammern (also „(a)“ statt „a“) in meinem Abbildungsverzeichnis und auch direkt unter dem „S“ der „SuperTest“-Abbildung im Abbildungsverzeichnis haben.
Vielen Dank im Voraus!
Hier ist mein MWE:
\documentclass[11pt]{article}
\usepackage{blindtext,tabularx,graphicx}
\usepackage[margin=1in]{geometry}
\usepackage[list=true]{subcaption}
\usepackage[labelfont=bf,labelsep=period]{caption}
\usepackage{tocloft}
\captionsetup[subfigure]{skip=8pt,position=bottom,font=bf}
\captionsetup[table]{font=bf}
\captionsetup[figure]{labelfont=bf}
%%%%%%%%%%%% ToC, LoF, LoT ADJUSTMENTS %%%%%%%%%%%%%%%%%%%%
% Formatting ToC
% Adjust spacing between number and title in ToC
% Adjust dots in ToC, LoF, LoT
\renewcommand\cftdotsep{1}
\makeatletter
\renewcommand{\@dotsep}{1}
\makeatother
\setlength{\cftfigindent}{0pt} % remove indentation from figures in lof
\setlength{\cfttabindent}{0pt} % remove indentation from tables in lot
% Formatting LoF
\setcounter{lofdepth}{2}
\cftpagenumbersoff{subfigure}
\makeatletter
\renewcommand\cftfigfont{\bfseries}
\makeatother
\makeatletter
\newcommand\cftsubtabdotsep{\cftdotsep}
\newcommand\cftsubfigfont{\normalfont}
\newcommand\cftsubfigpresnum{}
\newcommand\cftsubfigaftersnum{}
\newcommand\cftsubfigaftersnumb{}
\newcommand\cftsubfigleader{\hfill}
\newcommand\cftsubfigpagefont{\normalfont}
\newcommand\cftsubfigafterpnum{}
\providecommand{\toclevel@subfigure}{1}
\renewcommand*\l@subfigure[2]{%
\ifnum \c@lofdepth > \toclevel@subfigure
\vskip \cftbeforesubfigskip
{\leftskip \cftsubfigindent\relax
\rightskip \@tocrmarg
\parfillskip -\rightskip
\parindent \cftsubfigindent\relax\@afterindenttrue
\interlinepenalty\@M
\leavevmode
\@tempdima \cftsubfignumwidth\relax
\let\@cftbsnum \cftsubfigpresnum
\let\@cftasnum \cftsubfigaftersnum
\let\@cftasnumb \cftsubfigaftersnumb
\advance\leftskip \@tempdima \null\nobreak\hskip -\leftskip
{\cftsubfigfont #1}\nobreak
\cftsubfigfillnum{#2}}%
\fi
}%
\newlength\cftbeforesubfigskip
\setlength\cftbeforesubfigskip{\z@ \@plus.2\p@}
\newlength\cftsubfigindent
\setlength\cftsubfigindent{3.8em}
\newlength\cftsubfignumwidth
\setlength\cftsubfignumwidth{2.5em}
\renewcommand{\cftsubfigfillnum}[1]{%
{\cftsubfigleader\hfill}\par
}
\makeatother
% Formatting LoT
\setcounter{lotdepth}{1}
\makeatletter
\renewcommand\cfttabfont{\bfseries}
\makeatother
\begin{document}
\tableofcontents
\clearpage
{%
\let\oldnumberline\numberline%
\renewcommand{\numberline}{\figurename~\oldnumberline}%
\listoffigures%
}
%\listoffigures
\addcontentsline{toc}{section}{List of Figures}
\clearpage
{%
\let\oldnumberline\numberline%
\renewcommand{\numberline}{\tablename~\oldnumberline}%
\listoftables
}
\addcontentsline{toc}{section}{List of Tables}
\clearpage
\section{Nice0}
\begin{figure}[htb] \label{figure:Test}
\centering
\includegraphics[width=\textwidth]{example-image}
\captionsetup[subfigure]{skip=8pt,position=bottom}
\parbox{0.5\textwidth}{\subcaption[Test]{Test}}\hfill
\parbox{0.5\textwidth}{\subcaption[Test2]{Test2}}
\caption[SuperTest]{{\bf Test} \\Histogram of (a) Test and (b) most common Test sample.}
\end{figure}
\clearpage
\section{Nice1}
\begin{table}[htbp]\label{table:Test}
\caption[Test]{Test} \blindtext
\begin{center}
\begin{tabular}{|l||c|c|} \hline\hline
Ice Cream Store & Location & How to Get There \\ \hline
Toscanini’s & Central Square & Just walk! \\
Herrell’s & Harvard Square & Red Line \\
J.P. Licks & Davis Square & Red Line \\
Ben \& Jerry’s & Newbury Street & Green Line \\ \hline\hline
\end{tabular}
\end{center}
\end{table}
\end{document}
Antwort1
Für die Klammern um die Unterabbildungsbuchstaben können Sie Ihr eigenes Listenformat definieren mit
\DeclareCaptionListFormat{myListFormat}{(#2)}
und verwenden Sie es bei der Definition des Subcaption-Pakets wie
\usepackage[list=true, listformat=myListFormat]{subcaption}
Wenn Sie das Präfix "Figure" vor den Unterfiguren nicht möchten, ersetzen Sie den Teil
\let\oldnumberline\numberline%
\renewcommand{\numberline}{\figurename~\oldnumberline}%
Ihres Codes mit
\renewcommand{\cftfigpresnum}{Figure~}
\setlength{\cftfignumwidth}{5em}
Ich habe ein vollständig funktionierendes, geändertes Beispiel Ihres Codes hinzugefügt.
\documentclass[11pt]{article}
\usepackage{blindtext,tabularx,graphicx}
\usepackage[margin=1in]{geometry}
\usepackage[labelfont=bf,labelsep=period]{caption}
\DeclareCaptionListFormat{myListFormat}{(#2)}
\usepackage[list=true, listformat=myListFormat]{subcaption}
\usepackage{tocloft}
\captionsetup[subfigure]{skip=8pt,position=bottom,font=bf}
\captionsetup[table]{font=bf}
\captionsetup[figure]{labelfont=bf}
%%%%%%%%%%%% ToC, LoF, LoT ADJUSTMENTS %%%%%%%%%%%%%%%%%%%%
% Formatting ToC
% Adjust spacing between number and title in ToC
% Adjust dots in ToC, LoF, LoT
\renewcommand\cftdotsep{1}
\makeatletter
\renewcommand{\@dotsep}{1}
\makeatother
\setlength{\cftfigindent}{0pt} % remove indentation from figures in lof
\setlength{\cfttabindent}{0pt} % remove indentation from tables in lot
% Formatting LoF
\setcounter{lofdepth}{2}
\cftpagenumbersoff{subfigure}
\makeatletter
\renewcommand\cftfigfont{\bfseries}
\makeatother
\makeatletter
\newcommand\cftsubtabdotsep{\cftdotsep}
\newcommand\cftsubfigfont{\normalfont}
\newcommand\cftsubfigpresnum{}
\newcommand\cftsubfigaftersnum{}
\newcommand\cftsubfigaftersnumb{}
\newcommand\cftsubfigleader{\hfill}
\newcommand\cftsubfigpagefont{\normalfont}
\newcommand\cftsubfigafterpnum{}
\providecommand{\toclevel@subfigure}{1}
\renewcommand*\l@subfigure[2]{%
\ifnum \c@lofdepth > \toclevel@subfigure
\vskip \cftbeforesubfigskip
{\leftskip \cftsubfigindent\relax
\rightskip \@tocrmarg
\parfillskip -\rightskip
\parindent \cftsubfigindent\relax\@afterindenttrue
\interlinepenalty\@M
\leavevmode
\@tempdima \cftsubfignumwidth\relax
\let\@cftbsnum \cftsubfigpresnum
\let\@cftasnum \cftsubfigaftersnum
\let\@cftasnumb \cftsubfigaftersnumb
\advance\leftskip \@tempdima \null\nobreak\hskip -\leftskip
{\cftsubfigfont #1}\nobreak
\cftsubfigfillnum{#2}}%
\fi
}%
\newlength\cftbeforesubfigskip
\setlength\cftbeforesubfigskip{\z@ \@plus.2\p@}
\newlength\cftsubfigindent
\setlength\cftsubfigindent{3.8em}
\newlength\cftsubfignumwidth
\setlength\cftsubfignumwidth{2.5em}
\renewcommand{\cftsubfigfillnum}[1]{%
{\cftsubfigleader\hfill}\par
}
\makeatother
% Formatting LoT
\setcounter{lotdepth}{1}
\makeatletter
\renewcommand\cfttabfont{\bfseries}
\makeatother
\begin{document}
\tableofcontents
\clearpage
{%
\renewcommand{\cftfigpresnum}{Figure~}
\setlength{\cftfignumwidth}{5em}
\listoffigures%
}
%\listoffigures
\addcontentsline{toc}{section}{List of Figures}
\clearpage
{%
\let\oldnumberline\numberline%
\renewcommand{\numberline}{\tablename~\oldnumberline}%
\listoftables
}
\addcontentsline{toc}{section}{List of Tables}
\clearpage
\section{Nice0}
\begin{figure}[htb] \label{figure:Test}
\centering
\includegraphics[width=\textwidth]{example-image}
\captionsetup[subfigure]{skip=8pt,position=bottom}
\parbox{0.5\textwidth}{\subcaption[Test]{Test}}\hfill
\parbox{0.5\textwidth}{\subcaption[Test2]{Test2}}
\caption[SuperTest]{{\bf Test} \\Histogram of (a) Test and (b) most common Test sample.}
\end{figure}
\clearpage
\section{Nice1}
\begin{table}[htbp]\label{table:Test}
\caption[Test]{Test} \blindtext
\begin{center}
\begin{tabular}{|l||c|c|} \hline\hline
Ice Cream Store & Location & How to Get There \\ \hline
Toscanini’s & Central Square & Just walk! \\
Herrell’s & Harvard Square & Red Line \\
J.P. Licks & Davis Square & Red Line \\
Ben \& Jerry’s & Newbury Street & Green Line \\ \hline\hline
\end{tabular}
\end{center}
\end{table}
\end{document}
