Ich habe folgende Grafik:
Welches wird aus der Lösung entnommenHier. Ich möchte der Grafik noch etwas Text hinzufügen, sodass sie etwa so aussieht:
Um die hohe Verzerrung, die niedrige Verzerrung und die Kombination aus beiden anzuzeigen - zusammen mit den Bezeichnungen "Überanpassung", "Unteranpassung" und "Gute Balance". Wie kann ich diesen Text in die aktuelletikzpicture
Code:
\documentclass[tikz,border=3.14mm]{standalone}
\usetikzlibrary{calc}
\begin{document}
\begin{tikzpicture}[font=\sffamily,
declare function={f(\x)=0.5*pow(abs(\x-2),2)-0.06*pow(\x-2,3);}]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\X}{\Z/10}
\pgfmathsetmacro{\Y}{f(\X)+0.9*rnd}
\ifnum\Z=1
\xdef\LstOne{(\X,\Y)}
\xdef\LstTwo{"(\X,\Y)"}
\else
\xdef\LstOne{\LstOne (\X,\Y)}
\xdef\LstTwo{\LstTwo,"(\X,\Y)"}
\fi}
% \begin{scope}[local bounding box=over0]
% \foreach \Z in {1,...,42}
% {\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
% \fill \Coor circle[radius=1pt];
% }
% \draw plot[smooth] coordinates \LstOne;
% \end{scope}
\begin{scope}[local bounding box=over,xshift=-5cm]
\foreach \Z in {1,...,40}
{\pgfmathsetmacro{\Last}{{\LstTwo}[\Z-1]}
\pgfmathsetmacro{\Current}{{\LstTwo}[\Z]}
\pgfmathsetmacro{\Next}{{\LstTwo}[\Z+1]}
%\typeout{\Last,\Current,\Next}
\edef\temp{\noexpand\path ($0.6*\Current+0.2*\Last+0.2*\Next$) coordinate
(p\Z);}
\temp
\ifnum\Z=1
\xdef\LstThree{(p\Z)}
\else
\xdef\LstThree{\LstThree (p\Z)}
\fi
}
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] plot[smooth] coordinates \LstThree;
\end{scope}
%
\begin{scope}[local bounding box=good,xshift=-10cm]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] plot[smooth,domain=0.1:4.2,variable=\x] (\x,{f(\x)+0.45});
\end{scope}
%
\begin{scope}[local bounding box=under,xshift=-15cm]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] (0.1,0.4) -- (4.2,2);
\end{scope}
%
\foreach \X in {over,good,under}
{\draw[gray,thin] ([xshift=-3pt,yshift=3pt]\X.north west) rectangle
([xshift=3pt,yshift=-3pt]\X.south east);
\draw[stealth-stealth,thick] ([xshift=-3pt,yshift=3pt]\X.north west) node[right=1.5pt,fill=white]{Values}
|- ([xshift=3pt,yshift=-3pt]\X.south east) node[below left]{Time};}
\end{tikzpicture}
\end{document}
Antwort1
Sie können Kommentare oder Text mit \node[<options>](<name>) at (<coordinate>){<text>};innerhalb von hinzufügen scope. Darüber hinaus ermöglicht die TikZBibliothek positioningdie Lokalisierung von Knoten in Bezug auf andere Knoten mitoben/unten,rechts/links<shifting part>und deren Kombinationen. Darauf können die optionalen Argumente und folgen <of part>.
Zum Beispiel im Inneren scope:
\node[red] (lowlow) at (2.2,2.5) {Low bias, low variance}; % <-- here
oder
\node[red, below= -2.75cm of over] (lowlow) {Low bias, low variance}; % <-- here
und dann draußen:
\node[green,below = 3cm of lowlow] {Good balance}; % <-- here
MWE:
\documentclass[tikz,border=3.14mm]{standalone}
\usetikzlibrary{calc,positioning}
\begin{document}
\begin{tikzpicture}[font=\sffamily,
declare function={f(\x)=0.5*pow(abs(\x-2),2)-0.06*pow(\x-2,3);}]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\X}{\Z/10}
\pgfmathsetmacro{\Y}{f(\X)+0.9*rnd}
\ifnum\Z=1
\xdef\LstOne{(\X,\Y)}
\xdef\LstTwo{"(\X,\Y)"}
\else
\xdef\LstOne{\LstOne (\X,\Y)}
\xdef\LstTwo{\LstTwo,"(\X,\Y)"}
\fi}
% \begin{scope}[local bounding box=over0]
% \foreach \Z in {1,...,42}
% {\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
% \fill \Coor circle[radius=1pt];
% }
% \draw plot[smooth] coordinates \LstOne;
% \end{scope}
\begin{scope}[local bounding box=over,xshift=-5cm]
\foreach \Z in {1,...,40}
{\pgfmathsetmacro{\Last}{{\LstTwo}[\Z-1]}
\pgfmathsetmacro{\Current}{{\LstTwo}[\Z]}
\pgfmathsetmacro{\Next}{{\LstTwo}[\Z+1]}
%\typeout{\Last,\Current,\Next}
\edef\temp{\noexpand\path ($0.6*\Current+0.2*\Last+0.2*\Next$) coordinate
(p\Z);}
\temp
\ifnum\Z=1
\xdef\LstThree{(p\Z)}
\else
\xdef\LstThree{\LstThree (p\Z)}
\fi
}
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] plot[smooth] coordinates \LstThree;
% \node[red] (lowlow) at (2.2,2.5) {Low bias, low variance}; % <-- here
\node[red, below= -2.75cm of over] (lowlow) {Low bias, low variance}; % <-- here
\end{scope}
%
\begin{scope}[local bounding box=good,xshift=-10cm]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] plot[smooth,domain=0.1:4.2,variable=\x] (\x,{f(\x)+0.45});
% \node[red] (highb) at (2.2,2.5) {High bias}; % <-- here
\node[red, below= -2.75cm of good] (highb) {High bias}; % <-- here
\end{scope}
%
\begin{scope}[local bounding box=under,xshift=-15cm]
\foreach \Z in {1,...,42}
{\pgfmathsetmacro{\Coor}{{\LstTwo}[\Z-1]}
\fill \Coor circle[radius=1pt];
}
\draw[thick,blue] (0.1,0.4) -- (4.2,2);
% \node[red] (highv) at (2.2,2.5) {High variance}; % <-- here
\node[red, below= -2.75cm of under] (highv) {High variance}; % <-- here
\end{scope}
%
\foreach \X in {over,good,under}
{\draw[gray,thin] ([xshift=-3pt,yshift=3pt]\X.north west) rectangle
([xshift=3pt,yshift=-3pt]\X.south east);
\draw[stealth-stealth,thick] ([xshift=-3pt,yshift=3pt]\X.north west) node[right=1.5pt,fill=white]{Values}
|- ([xshift=3pt,yshift=-3pt]\X.south east) node[below left]{Time};}
\node[green,below = 3cm of lowlow] {Good balance}; % <-- here
\node[green,below = 3cm of highb] {underfitting}; % <-- here
\node[green,below = 3cm of highv] {overfitting}; % <-- here
\end{tikzpicture}
\end{document}
