Vertikale Ausrichtung, wenn der Titel in der Beamer-Vorlage leer ist

Ich verwende eine angepasste Vorlage für Beamer. Unter anderem habe ich die Überschriftenvorlage komplett neu geschrieben. Wenn ich jedoch einen Rahmen ohne Titel verwende, ist die vertikale Ausrichtung nicht dieselbe wie bei anderen Folien mit Titel. Überraschenderweise funktioniert es gut, unabhängig davon, ob der Titel eine oder zwei Zeilen hat ... Es ist schwer zu erklären, aber im folgenden Beispiel sehr leicht zu erkennen. Beachten Sie die falsche vertikale Ausrichtung in der dritten Folie. Der interessante Teil ist Zeile 68. Irgendeine Idee, was hier los ist?

\PassOptionsToPackage{draft}{graphicx}
\documentclass[xcolor=dvipsnames]{beamer}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{tikz}
\usepackage{amsfonts}
\usepackage{cmbright}
\usepackage[T1]{fontenc}
\usepackage{etoolbox}
\usepackage{gnuplot-lua-tikz}
\usepackage{environ}
\usepackage{ulem}
\usepackage{textpos}

\makeatletter
\patchcmd{\beamer@sectionintoc}{\vskip1.5em}{\vskip0.5em}{}{}
\makeatother

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%TWO COLOURS OF THE TEMPLATE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\definecolor{azul}{rgb}{0.603,0.733,0.833}
\definecolor{verde}{rgb}{0.647,0.663,0.2.7}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING COLOURS IN SEVERAL ELEMENTS
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamercolor{frametitle}{fg=black}
\setbeamercolor{headline}{fg=black}
\setbeamercolor{footline}{fg=black}
\setbeamercolor{block body}{bg=azul}
\setbeamercolor{block title}{bg=verde,fg=black}
\setbeamercolor{item}{fg=verde}
\setbeamercolor{alerted text}{fg=Red}
\setbeamercolor{section in toc}{fg=azul}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING ASPECT OF DIVERSE FRAME ELEMENTS
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\useoutertheme[]{default}

\setbeamertemplate{section in toc}[circle]
\setbeamertemplate{subsection in toc}[square]
\setbeamertemplate{itemize item}{$\bullet$}
\setbeamertemplate{navigation symbols}{}
\setbeamercovered{invisible}
\setbeamertemplate{sections in toc}[ball]

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING THE FOOTLINE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamertemplate{footline}{
  \hspace{.6cm}
  \vspace{.2cm}
  \tikz \fill [azul] (0,0) rectangle (11.4, 2pt);

  \parbox[c][0.8cm][t]{\textwidth}{\hspace{3em} \scriptsize\bf 17 November 2014 $\rangle$ J.J. G\'omez-Navarro $\rangle$ edit the footline in the preamble}
}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%THIS THEME DISCARDS THE TITLE IN THE SLIDES, AND USES HEADLINE INSTEAD
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamertemplate{frametitle}{}
\providecommand\insertframetitle{}
\setbeamertemplate{headline}{

  \hspace{1cm}
  \parbox[c][1.2cm][c]{.65\textwidth}{\raggedright{}\bf\Large\insertframetitle}

  \begin{textblock*}{100mm}(.8\textwidth,-1.0cm)
    \includegraphics[width=2.0cm]{logo.pdf}
  \end{textblock*}

  \vspace*{0.1cm}

  \hspace*{0.6cm}
  \tikz \fill [azul] (0,0) rectangle (9.0, 2pt);
}



%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% PRESENTATION  STARTS HERE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

\begin{document}


\begin{frame}{title}

  frame with title

\end{frame}



\begin{frame}{Very very long title with so much text it does not fit in one lines }

  frame frame frame

\end{frame}

\begin{frame}{ }

  frame frame frame

\end{frame}

\end{document}

Antwort1

Wenn Sie {}im dritten Frame das entfernen, das einen leeren Titel anzeigt, sehen Sie dasselbe vertikale Ausrichtungsproblem. Das zeigt mir, dass man eine Eingabe machen muss. In diesem Fall wird {}oder \emptyoder \phantom{text}funktionieren.

\begin{frame}{{}} or \begin{frame}{\empty} or \begin{frame}{\phantom{a}}

Bildbeschreibung hier eingeben Bildbeschreibung hier eingeben

Code

\PassOptionsToPackage{draft}{graphicx}
\documentclass[xcolor=dvipsnames]{beamer}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{tikz}
\usepackage{amsfonts}
\usepackage{cmbright}
\usepackage[T1]{fontenc}
\usepackage{etoolbox}
\usepackage{gnuplot-lua-tikz}
\usepackage{environ}
\usepackage{ulem}
\usepackage{textpos}

\makeatletter
\patchcmd{\beamer@sectionintoc}{\vskip1.5em}{\vskip0.5em}{}{}
\makeatother

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%TWO COLOURS OF THE TEMPLATE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\definecolor{azul}{rgb}{0.603,0.733,0.833}
\definecolor{verde}{rgb}{0.647,0.663,0.2.7}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING COLOURS IN SEVERAL ELEMENTS
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamercolor{frametitle}{fg=black}
\setbeamercolor{headline}{fg=black}
\setbeamercolor{footline}{fg=black}
\setbeamercolor{block body}{bg=azul}
\setbeamercolor{block title}{bg=verde,fg=black}
\setbeamercolor{item}{fg=verde}
\setbeamercolor{alerted text}{fg=Red}
\setbeamercolor{section in toc}{fg=azul}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING ASPECT OF DIVERSE FRAME ELEMENTS
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\useoutertheme[]{default}

\setbeamertemplate{section in toc}[circle]
\setbeamertemplate{subsection in toc}[square]
\setbeamertemplate{itemize item}{$\bullet$}
\setbeamertemplate{navigation symbols}{}
\setbeamercovered{invisible}
\setbeamertemplate{sections in toc}[ball]

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%SETTING THE FOOTLINE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamertemplate{footline}{
  \hspace{.6cm}
  \vspace{.2cm}
  \tikz \fill [azul] (0,0) rectangle (11.4, 2pt);

  \parbox[c][0.8cm][t]{\textwidth}{\hspace{3em} \scriptsize\bf 17 November 2014 $\rangle$ J.J. G\'omez-Navarro $\rangle$ edit the footline in the preamble}
}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%THIS THEME DISCARDS THE TITLE IN THE SLIDES, AND USES HEADLINE INSTEAD
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\setbeamertemplate{frametitle}{}
\providecommand\insertframetitle{}
\setbeamertemplate{headline}{

  \hspace{1cm}
  \parbox[c][1.2cm][c]{.65\textwidth}{\raggedright{}\bf\Large\insertframetitle}

  \begin{textblock*}{100mm}(.8\textwidth,-1.0cm)
    \includegraphics[width=2.0cm]{logo.pdf}
  \end{textblock*}

  \vspace*{0.1cm}

  \hspace*{0.6cm}
  \tikz \fill [azul] (0,0) rectangle (9.0, 2pt);
}



%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% PRESENTATION  STARTS HERE
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

\begin{document}


\begin{frame}{title}

  frame with title

\end{frame}



\begin{frame}{Very very long title with so much text it does not fit in one lines }

  frame frame frame

\end{frame}

\begin{frame}{ }

  frame frame frame

\end{frame}

\end{document}
