Ich habe JBoss EAP 7.2-Server, die im Domänenmodus laufen:
10.10.26.61 jb-domain-arge (Domänencontroller)
10.10.26.62 jb-host-arge(Host Controller)
10.10.26.63 jb-host-arge2(Host Controller)
und ich habe einen Reverse-Proxy vor den JBoss-Host-Controllern:
10.10.26.60 jb-arge-apc
Die JBoss Managed Server sind wie folgt:
jb-host-arge
SG01-H01 (HTTP-Port: 2001)
http://10.10.26.62:2001/jboss-as-helloworld/Hallo Welt
SG02-H01 (HTTP-Port: 3001)
http://10.10.26.62:3001/Beispielprojekt
SG03-H01 (HTTP-Port: 4001)
http://10.10.26.62:4001/BeispielWebApp
jb-host-arge2
SG01-H02 (HTTP-Port: 2001)
http://10.10.26.63:2001/jboss-as-helloworld/Hallo Welt
SG03-H02 (HTTP-Port: 4001)
http://10.10.26.63:4001/BeispielWebApp
Ich möchte auf alle Apps über 10.10.26.60, HTTP-80-Port, zugreifen, wie:
http://10.10.26.60/jboss-as-helloworld/Hallo Welt
http://10.10.26.60/Beispielprojekt
http://10.10.26.60/BeispielWebApp
Und meinnginx.confist unterhalb:
# For more information on configuration, see:
# * Official English Documentation: http://nginx.org/en/docs/
# * Official Russian Documentation: http://nginx.org/ru/docs/
user nginx;
worker_processes auto;
error_log /var/log/nginx/error.log;
pid /run/nginx.pid;
# Load dynamic modules. See /usr/share/doc/nginx/README.dynamic.
include /usr/share/nginx/modules/*.conf;
events {
worker_connections 1024;
}
http {
log_format main '$remote_addr - $remote_user [$time_local] "$request" '
'$status $body_bytes_sent "$http_referer" '
'"$http_user_agent" "$http_x_forwarded_for"';
access_log /var/log/nginx/access.log main;
sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
include /etc/nginx/mime.types;
default_type application/octet-stream;
# Load modular configuration files from the /etc/nginx/conf.d directory.
# See http://nginx.org/en/docs/ngx_core_module.html#include
# for more information.
include /etc/nginx/conf.d/*.conf;
upstream arge_2001 {
server 10.10.26.62:2001;
server 10.10.26.63:2001;
}
server {
listen 80;
server_name arge_2001;
location / {
proxy_pass http://arge_2001;
}
}
upstream arge_3001 {
server 10.10.26.62:3001;
}
server {
listen 80;
server_name arge_3001;
location / {
proxy_pass http://arge_3001;
}
}
upstream arge_4001 {
server 10.10.26.62:4001;
server 10.10.26.63:4001;
}
server {
listen 80;
server_name arge_4001;
location / {
proxy_pass http://arge_4001;
}
}
}
Antwort1
Ich habe nginx.conf wie folgt geändert und jetzt funktioniert es:
# For more information on configuration, see:
# * Official English Documentation: http://nginx.org/en/docs/
# * Official Russian Documentation: http://nginx.org/ru/docs/
user nginx;
worker_processes auto;
error_log /var/log/nginx/error.log;
pid /run/nginx.pid;
# Load dynamic modules. See /usr/share/doc/nginx/README.dynamic.
include /usr/share/nginx/modules/*.conf;
events {
worker_connections 1024;
}
http {
log_format main '$remote_addr - $remote_user [$time_local] "$request" '
'$status $body_bytes_sent "$http_referer" '
'"$http_user_agent" "$http_x_forwarded_for"';
access_log /var/log/nginx/access.log main;
sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
include /etc/nginx/mime.types;
default_type application/octet-stream;
# Load modular configuration files from the /etc/nginx/conf.d directory.
# See http://nginx.org/en/docs/ngx_core_module.html#include
# for more information.
include /etc/nginx/conf.d/*.conf;
upstream arge {
hash $server_addr$server_port$request_uri consistent;
server 10.10.26.62:2001;
server 10.10.26.63:2001;
server 10.10.26.62:3001;
server 10.10.26.62:4001;
server 10.10.26.63:4001;
}
server {
listen 80;
server_name 10.10.26.60;
location / {
proxy_set_header Host $http_host;
proxy_set_header X-Forwarded-Host $host;
proxy_set_header X-Forwarded-Server $host;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Graylog-Server-URL http://$server_name/;
proxy_pass http://arge;
}
}
}
