Glade Ubuntu - Transparenter Button auf einem Hintergrundbild

Ich versuche, eine Ubuntu-Anwendung zu erstellen. Ich muss transparente Schaltflächen an bestimmten Stellen auf einem Hintergrundbild in Glade platzieren, sodass sich das Bild beim Klicken auf die Schaltfläche ändert.

Bisher ist mir das nicht gelungen. Mein Button landet einfach nicht auf dem Bild. Außerdem ist es mir nicht gelungen, den Button komplett transparent zu machen (d. h. er ist sichtbar, wenn er gedrückt wird).

Antwort1

  1. Für feste Tastenpositionen ist es besser, GtkFixedoder GtkLayout(mit Scrollen) zu verwenden.
  2. Bei der Transparenz von Schaltflächen funktioniert es bei mir wie es soll. Wenn nicht, versuchen Sie:
    • Border Relief: Nonefür flachen Knopf
    • Deaktivieren Sie das Kontrollkästchen Focus on Click, um Fokushervorhebungen zu vermeiden.

Beispiel:

<?xml version="1.0" encoding="UTF-8"?>
<!-- Generated with glade 3.16.1 -->
<interface>
  <requires lib="gtk+" version="3.10"/>
  <object class="GtkWindow" id="window1">
    <property name="can_focus">False</property>
    <child>
      <object class="GtkLayout" id="layout1">
        <property name="visible">True</property>
        <property name="can_focus">False</property>
        <child>
          <object class="GtkButton" id="button1">
            <property name="label" translatable="yes">button</property>
            <property name="width_request">59</property>
            <property name="height_request">30</property>
            <property name="visible">True</property>
            <property name="can_focus">True</property>
            <property name="receives_default">True</property>
            <property name="opacity">0</property>
          </object>
          <packing>
            <property name="x">87</property>
            <property name="y">64</property>
          </packing>
        </child>
      </object>
    </child>
  </object>
</interface>

Beim ersten Mal dachte ich, Sie meinen den Desktop-Hintergrund. Ich lasse es also einfach stehen, vielleicht hilft es anderen.

Ich bin nicht sicher, welche Version von PyGTK von Quickly in (Ubuntu 13.04) verwendet wird. Zum Testen ist es besser, 0,1 Deckkraft zu verwenden. Glade bietet keine Möglichkeit, keep_belowEigenschaften festzulegen.

PyGTK 3

Hinzufügen:

    <property name="opacity">0.0</property>
    <property name="decorated">False</property>

Zu

builder_example.glade

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <!-- interface-requires gtk+ 3.0 -->
  <object class="GtkWindow" id="window1">
    <property name="can_focus">False</property>
    <!-- <property name="keep_below">True</property> -->
    <property name="opacity">0.0</property>
    <property name="decorated">False</property>
    <!-- <property name="position">gtk.WIN_POS_CENTER_ALWAYS</property> -->
    <signal name="delete-event" handler="onDeleteWindow" swapped="no"/>
    <child>
      <object class="GtkButton" id="button1">
        <property name="label" translatable="yes">button</property>
        <property name="use_action_appearance">False</property>
        <property name="visible">True</property>
        <property name="can_focus">True</property>
        <property name="receives_default">True</property>
        <property name="use_action_appearance">False</property>
        <signal name="pressed" handler="onButtonPressed" swapped="no"/>
      </object>
    </child>
  </object>
</interface>

Ich habe diese kommentiert, da sie Fehler verursacht haben (ich bin nicht sicher, ob es in Glade einen anderen Weg gibt)

    <!-- <property name="keep_below">True</property> -->
    <!-- <property name="position">gtk.WIN_POS_CENTER_ALWAYS</property> -->

Also füge ich sie der .py-Datei hinzu, damit sie dynamisch angewendet werden:

window.set_keep_below(True)
window.set_position(Gtk.WindowPosition.CENTER_ALWAYS)

builder_example.py

from gi.repository import Gtk

class Handler:
    def onDeleteWindow(self, *args):
        Gtk.main_quit(*args)

    def onButtonPressed(self, button):
        print("Hello World!")

builder = Gtk.Builder()
builder.add_from_file("builder_example.glade")
builder.connect_signals(Handler())

window = builder.get_object("window1")
window.set_keep_below(True)
window.set_position(Gtk.WindowPosition.CENTER_ALWAYS)
window.show_all()

Gtk.main()

PyGTK 2

Hinzufügen:

        self.window.set_keep_below(True)
        self.window.set_opacity(0.0)
        self.window.set_decorated(False)
        self.window.set_position(gtk.WIN_POS_CENTER_ALWAYS)

Zuhelloworld.py

#!/usr/bin/env python

# example helloworld.py

import pygtk
pygtk.require('2.0')
import gtk

class HelloWorld:

    # This is a callback function. The data arguments are ignored
    # in this example. More on callbacks below.
    def hello(self, widget, data=None):
        print "Hello World"

    def delete_event(self, widget, event, data=None):
        # If you return FALSE in the "delete_event" signal handler,
        # GTK will emit the "destroy" signal. Returning TRUE means
        # you don't want the window to be destroyed.
        # This is useful for popping up 'are you sure you want to quit?'
        # type dialogs.
        print "delete event occurred"

        # Change FALSE to TRUE and the main window will not be destroyed
        # with a "delete_event".
        return False

    def destroy(self, widget, data=None):
        print "destroy signal occurred"
        gtk.main_quit()

    def __init__(self):
        # create a new window
        self.window = gtk.Window(gtk.WINDOW_TOPLEVEL)

        # Add these
        self.window.set_keep_below(True)
        self.window.set_opacity(0.0)
        self.window.set_decorated(False)
        self.window.set_position(gtk.WIN_POS_CENTER_ALWAYS)

        # When the window is given the "delete_event" signal (this is given
        # by the window manager, usually by the "close" option, or on the
        # titlebar), we ask it to call the delete_event () function
        # as defined above. The data passed to the callback
        # function is NULL and is ignored in the callback function.
        self.window.connect("delete_event", self.delete_event)

        # Here we connect the "destroy" event to a signal handler.
        # This event occurs when we call gtk_widget_destroy() on the window,
        # or if we return FALSE in the "delete_event" callback.
        self.window.connect("destroy", self.destroy)

        # Sets the border width of the window.
        self.window.set_border_width(10)

        # Creates a new button with the label "Hello World".
        self.button = gtk.Button("Hello World")

        # When the button receives the "clicked" signal, it will call the
        # function hello() passing it None as its argument.  The hello()
        # function is defined above.
        self.button.connect("clicked", self.hello, None)

        # This will cause the window to be destroyed by calling
        # gtk_widget_destroy(window) when "clicked".  Again, the destroy
        # signal could come from here, or the window manager.
        self.button.connect_object("clicked", gtk.Widget.destroy, self.window)

        # This packs the button into the window (a GTK container).
        self.window.add(self.button)

        # The final step is to display this newly created widget.
        self.button.show()

        # and the window
        self.window.show()

    def main(self):
        # All PyGTK applications must have a gtk.main(). Control ends here
        # and waits for an event to occur (like a key press or mouse event).
        gtk.main()

# If the program is run directly or passed as an argument to the python
# interpreter then create a HelloWorld instance and show it
if __name__ == "__main__":
    hello = HelloWorld()
    hello.main()

Verweise:
