He leído algunas preguntas sobre longtablecómo hacer que se ajuste al ancho de la página, pero no he tenido éxito. En el ejemplo, la tabla se ajusta al ancho de la página pero sale de los márgenes especificados. MWE adjunto. ¡Gracias!
\documentclass[12pt, oneside]{article} % use "amsart" instead of "article" for AMSLaTeX format
\usepackage{geometry} % See geometry.pdf to learn the layout options. There are lots.
\geometry{letterpaper}
\geometry{left=1.5in, right=1in, top=1in, bottom=1in} % ... or a4paper or a5paper or ...
%\geometry{landscape} % Activate for rotated page geometry
\usepackage{graphicx} % Use pdf, png, jpg, or eps§ with pdflatex; use eps in DVI mode
% TeX will automatically convert eps --> pdf in pdflatex
\usepackage{amssymb}
\renewcommand{\labelitemi}{--}
\usepackage [english]{babel}
\usepackage [autostyle, english = american]{csquotes}
\MakeOuterQuote{"}
\usepackage{floatrow}
\floatsetup[table]{capposition=top}
\floatsetup[figure]{capposition=top}
\DeclareCaptionFont{xipt}{\fontsize{11}{13}\mdseries}
\usepackage[font=xipt]{caption}
\usepackage{tabularx}
\newcolumntype{C}{>{\centering\arraybackslash}X}
\renewcommand\tabularxcolumn[1]{m{#1}}
\usepackage[title,titletoc]{appendix}
\renewcommand{\appendixpagename}{\centering Appendices}
\usepackage{amsmath}
\newcommand{\dd}[1]{\mathrm{d}#1}
\usepackage{enumerate}
\usepackage[nottoc]{tocbibind}
\usepackage{caption}
\captionsetup{justification=centerlast}
\usepackage{setspace}
\setstretch{1.6}
\usepackage{color,soul}
\usepackage{longtable}
\graphicspath{ {Images/} }
\begin{document}
\begin{center}
\begin{longtable}{|*{2}{>{\centering\arraybackslash}p{8cm}|}}
\hline \textbf{Material} & \textbf{Description} \\
\hline Nickel Titanium Alloy (50/50) Thin Walls & Otherwise known as Nitinol; exhibits shape memory effect--ability to undergo deformation and resume original shape above "transformation temperature"--and super elasticity \cite{borges} \\
\hline Maraging Steel & Group of steels that possesses superior strength and toughness without losing malleability; this is due to aging, which incorporates heat treatment resulting in the precipitation of intermetallic compounds \cite{degarmo} \\
\hline Aluminum Copper Alloy & Aluminum is one of the most versatile, economical, and attractive metallic materials; these alloys are most valuable for their high strength and corrosion resistance \cite{ahmad} \\
\hline Ceramic with Polyamide Coating & Polyamide coatings afford materials durability, thermal properties, chemical resistance, electrical properties, and abrasion and chemical resistance \\
\hline Amdry, Inconel 718 & High-strength corrosion-resistant nickel chromium material; age-hardened, post-weld crack resistant, and has good tensile, fatigue, creep, and rupture strength properties \cite{specialmetals} \\
\hline Stainless Steel & Notable for its corrosion and oxidation resistance; comes with various finishes to suit the applicable environment \cite{british} \\
\hline Neodymium Magnet & Strongest permanent commercial magnet available; graded according to maximum energy product (Joules per cubic meter); sintered neodymium generally not corrosion resistant \cite{fraden, wisegeek, warren} \\
\hline Hot Work Tool Steel Cubes & Group of steels used to cut or shape material at high temperatures; good hot hardness and toughness and fair wear resistance due to substantial amounts of carbide \cite{reardon} \\
\hline O-1 Tool Steel & Part of the cold work, oil-hardening tool steels group; used to materials at low temperatures possessing high hardenability and wear resistance along with average toughness and heat softening resistance \cite{machinery} \\
\hline Unknown Tensile Specimens & EDX analysis suggests that this unknown specimen is iron-chromium \\
\hline Unknown Mounted Specimens & EDX analysis suggests that this unknown specimen is silumin (aluminum-silicon alloy) \\ \hline
\caption{Analyzed Material Descriptions} \end{longtable} \end{center}
\end{document}
Respuesta1
Creo que la tabla se vería mucho mejor si (a) usara 'raggedright` en lugar de alineación centrada y (b) usara espacio simple. Además, examine la exactitud de su afirmación de que "la tabla se ajusta al ancho de la página". En mis cálculos (que se muestran en el código siguiente), el ancho de las columnas debe ser estrictamente inferior a 8 cm.
Ah, y tenga en cuenta que longtablelos entornos se centran automáticamente, no es necesario encerrarlos en centerentornos.
\documentclass[12pt, oneside]{article}
\usepackage{geometry}
\geometry{letterpaper,left=1.5in,right=1in,vmargin=1in}
\usepackage{graphicx}
\usepackage{amssymb}
\renewcommand{\labelitemi}{--}
\usepackage [english]{babel}
\usepackage [autostyle, english = american]{csquotes}
\MakeOuterQuote{"}
\usepackage{floatrow}
\floatsetup[table]{capposition=top}
\floatsetup[figure]{capposition=top}
\DeclareCaptionFont{xipt}{\fontsize{11}{13}\mdseries}
\usepackage[font=xipt]{caption}
\usepackage{tabularx}
\newcolumntype{C}{>{\centering\arraybackslash}X}
\renewcommand\tabularxcolumn[1]{m{#1}}
\usepackage[title,titletoc]{appendix}
\renewcommand{\appendixpagename}{\centering Appendices}
\usepackage{amsmath}
\newcommand{\dd}[1]{\mathrm{d}#1}
\usepackage{enumerate}
\usepackage[nottoc]{tocbibind}
%%%\usepackage{caption}
\captionsetup{justification=centerlast}
\usepackage{setspace}
\setstretch{1.6}
\usepackage{color,soul,ragged2e}
\setlength\extrarowheight{2pt}
\usepackage{longtable}
\graphicspath{ {Images/} }
% Calculate width of columns in 'longtable'
% Width of "letterpaper" page is 8.5"
\newlength\mylen
\setlength\mylen{3in} % 3" = (8.5"-1"-1.5")/2
\addtolength\mylen{\dimexpr-2\tabcolsep-1.5\arrayrulewidth\relax}
\begin{document}
\begin{singlespacing} % optional but recommended
\begin{longtable}{|*{2}{>{\RaggedRight\arraybackslash}p{\mylen}|}}
\hline
\textbf{Material} & \textbf{Description} \\
\hline
\endhead
\hline
\caption{Analyzed Material Descriptions}
\endlastfoot
Nickel Titanium Alloy (50/50) Thin Walls & Otherwise known as Nitinol; exhibits shape memory effect--ability to undergo deformation and resume original shape above "transformation temperature"--and super elasticity \cite{borges} \\
\hline
Maraging Steel & Group of steels that possesses superior strength and toughness without losing malleability; this is due to aging, which incorporates heat treatment resulting in the precipitation of intermetallic compounds \cite{degarmo} \\
\hline
Aluminum Copper Alloy & Aluminum is one of the most versatile, economical, and attractive metallic materials; these alloys are most valuable for their high strength and corrosion resistance \cite{ahmad} \\
\hline
Ceramic with Polyamide Coating & Polyamide coatings afford materials durability, thermal properties, chemical resistance, electrical properties, and abrasion and chemical resistance \\
\hline
Amdry, Inconel 718 & High-strength corrosion-resistant nickel chromium material; age-hardened, post-weld crack resistant, and has good tensile, fatigue, creep, and rupture strength properties \cite{specialmetals} \\
\hline
Stainless Steel & Notable for its corrosion and oxidation resistance; comes with various finishes to suit the applicable environment \cite{british} \\
\hline
Neodymium Magnet & Strongest permanent commercial magnet available; graded according to maximum energy product (Joules per cubic meter); sintered neodymium generally not corrosion resistant \cite{fraden, wisegeek, warren} \\
\hline
Hot Work Tool Steel Cubes & Group of steels used to cut or shape material at high temperatures; good hot hardness and toughness and fair wear resistance due to substantial amounts of carbide \cite{reardon} \\
\hline
O-1 Tool Steel & Part of the cold work, oil-hardening tool steels group; used to materials at low temperatures possessing high hardenability and wear resistance along with average toughness and heat softening resistance \cite{machinery} \\
\hline
Unknown Tensile Specimens & EDX analysis suggests that this unknown specimen is iron-chromium \\
\hline Unknown Mounted Specimens & EDX analysis suggests that this unknown specimen is silumin (aluminum-silicon alloy) \\
\end{longtable}
\end{singlespacing}
\end{document}
Respuesta2
Personalmente, usaría ltablex(hace tabularxuna "tabla larga") y luego las tabularxcolumnas (como quieras usar tabularxde cualquier manera). Aquí hay una imagen del resultado (con showframe, para que pueda ver que se ajusta al margen):
\documentclass[12pt, oneside]{article} % use "amsart" instead of "article" for AMSLaTeX format
\usepackage{geometry} % See geometry.pdf to learn the layout options. There are lots.
\geometry{letterpaper}
\geometry{left=1.5in, right=1in, top=1in, bottom=1in,showframe} % ... or a4paper or a5paper or ...
%\geometry{landscape} % Activate for rotated page geometry
\usepackage{graphicx} % Use pdf, png, jpg, or eps§ with pdflatex; use eps in DVI mode
% TeX will automatically convert eps --> pdf in pdflatex
\usepackage{amssymb}
\renewcommand{\labelitemi}{--}
\usepackage [english]{babel}
\usepackage [autostyle, english = american]{csquotes}
\MakeOuterQuote{"}
\usepackage{floatrow}
\floatsetup[table]{capposition=top}
\floatsetup[figure]{capposition=top}
\DeclareCaptionFont{xipt}{\fontsize{11}{13}\mdseries}
\usepackage[font=xipt]{caption}
\usepackage{ltablex}
\newcolumntype{C}{>{\centering\arraybackslash}X}
\renewcommand\tabularxcolumn[1]{m{#1}}
\usepackage[title,titletoc]{appendix}
\renewcommand{\appendixpagename}{\centering Appendices}
\usepackage{amsmath}
\newcommand{\dd}[1]{\mathrm{d}#1}
\usepackage{enumerate}
\usepackage[nottoc]{tocbibind}
\usepackage{caption}
\captionsetup{justification=centerlast}
\usepackage{setspace}
\setstretch{1.6}
\usepackage{color,soul}
\graphicspath{ {Images/} }
\begin{document}
\begingroup\renewcommand\tabularxcolumn[1]{p{#1}}
\begin{tabularx}{\textwidth}{|*{2}{C|}}
\hline \textbf{Material} & \textbf{Description} \\
\hline Nickel Titanium Alloy (50/50) Thin Walls & Otherwise known as Nitinol; exhibits shape memory effect--ability to undergo deformation and resume original shape above "transformation temperature"--and super elasticity \cite{borges} \\
\hline Maraging Steel & Group of steels that possesses superior strength and toughness without losing malleability; this is due to aging, which incorporates heat treatment resulting in the precipitation of intermetallic compounds \cite{degarmo} \\
\hline Aluminum Copper Alloy & Aluminum is one of the most versatile, economical, and attractive metallic materials; these alloys are most valuable for their high strength and corrosion resistance \cite{ahmad} \\
\hline Ceramic with Polyamide Coating & Polyamide coatings afford materials durability, thermal properties, chemical resistance, electrical properties, and abrasion and chemical resistance \\
\hline Amdry, Inconel 718 & High-strength corrosion-resistant nickel chromium material; age-hardened, post-weld crack resistant, and has good tensile, fatigue, creep, and rupture strength properties \cite{specialmetals} \\
\hline Stainless Steel & Notable for its corrosion and oxidation resistance; comes with various finishes to suit the applicable environment \cite{british} \\
\hline Neodymium Magnet & Strongest permanent commercial magnet available; graded according to maximum energy product (Joules per cubic meter); sintered neodymium generally not corrosion resistant \cite{fraden, wisegeek, warren} \\
\hline Hot Work Tool Steel Cubes & Group of steels used to cut or shape material at high temperatures; good hot hardness and toughness and fair wear resistance due to substantial amounts of carbide \cite{reardon} \\
\hline O-1 Tool Steel & Part of the cold work, oil-hardening tool steels group; used to materials at low temperatures possessing high hardenability and wear resistance along with average toughness and heat softening resistance \cite{machinery} \\
\hline Unknown Tensile Specimens & EDX analysis suggests that this unknown specimen is iron-chromium \\
\hline Unknown Mounted Specimens & EDX analysis suggests that this unknown specimen is silumin (aluminum-silicon alloy) \\ \hline
\caption{Analyzed Material Descriptions} \end{tabularx}\endgroup
\end{document}
