Aquí hay un MWE. Los \addmilestonesque están comentados en el MWE son el problema. Las fechas reales que necesito se presentan al final de cada \addmilestonecomando. Además, el color de las burbujas debe variar en tonos de rojo de acuerdo con el tamaño de la burbuja. Burbuja pequeña = rojo claro, burbuja más grande = rojo sangre.
La timelinebiblioteca se puede encontrar enhttps://github.com/cfiandra/timeline
\documentclass[border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{timeline}
\begin{document}
\begin{tikzpicture}[timespan={}]
% timespan={Day} -> now we have days as reference
% timespan={} -> no label is displayed for the timespan
% default timespan is 'Week'
\timeline[custom interval=true]{1966, 1971, 1979, 1980, 1981,1986,1996,2001,2006,2011,2016}
% \timeline[custom interval=true]{3,...,9} -> i.e., from Day 3 to Day 9
% \timeline{8} -> i.e., from Week 1 to Week 8
% put here the phases
\begin{phases}
\initialphase{involvement degree=0cm,phase color=black}
\phase{between week=1 and 1 in 0.5,involvement degree=1.65cm}
\phase{between week=2 and 3 in 0.5,involvement degree=3.5cm}
\phase{between week=3 and 4 in 0.5,involvement degree=0cm}
\phase{between week=4 and 5 in 0.5,involvement degree=0cm}
\phase{between week=5 and 6 in 0.5,involvement degree=0}
\phase{between week=5 and 6 in 0.5,involvement degree=2.5cm} Guerilla
\phase{between week=6 and 7 in 0.5,involvement degree=1.9cm}
\phase{between week=7 and 8 in 0.5,involvement degree=3cm}
\phase{between week=8 and 9 in 0.5,involvement degree =1.7cm}
\end{phases}
% put here the milestones
\addmilestone{at=phase-0.270,direction=270:2cm,text={Obote/UPC win First Multiparty elections},text options={below}} %1962
\addmilestone{at=phase-1.110,direction=90:2cm,text={Obote attacks President Mutesa palace},text options={above}}
\addmilestone{at=phase-2.110,direction=90:1.5cm,text={Idi Amin's Reign of Terror},text options={above}}
\addmilestone{at=phase-6.270,direction=270:1cm,text={Museveni Bush War},text options={below}}
\addmilestone{at=phase-7.110,direction=110:1.5cm,text={Northern Uganda War I},text options={above}}
\addmilestone{at=phase-8.90,direction=90:1.5cm,text={Northern Uganda War II},text options={above}}
\addmilestone{at=phase-9.60,direction=60:1.5cm,text={Northern Uganda War III},text options={above}}
%These are the problematic milestones I cannot get them placed at individual point dates, eg. 1966, 1971 etc...
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Obote abrogates Constitution },text options={below}} % 1966
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Idi Amin overthrows Obote },text options={below}} % 1971
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Multiparty elections. Obote wins },text options={below}} % 1980
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Museveni starts Bush war},text options={below}} % 1981
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Okellos overthrow Obote II},text options={below}} 1985
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Museveni seizes power from Okellos},text options={below}} 1986
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={``No party'' elections. Museveni wins },text options={below}} % 1996
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={``No party'' elections, Museveni wins },text options={below}} % 2001
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Multiparty elections, Museveni wins },text options={below}} % 2006
\end{tikzpicture}
\end{document}
Respuesta1
No estoy del todo seguro de haberlo entendido correctamente, pero los nodos que contienen los años se denominan \timespan-\xi, donde \timespanes lo que usted define timespan={}(es decir, nada, en su caso), y \xies un contador que comienza desde 1. Por lo tanto, el nodo 1966, por ejemplo se llama -1, por lo que podrías poner tu hito en, por ejemplo -1.south. Hice los dos primeros como ejemplo, pero puedes completar el resto tú mismo. De todos modos, no sé cómo te gustaría colocar el texto:
Quizás notes que el círculo del hito no está exactamente centrado debajo del año. La razón de esto es un espacio explícito en el texto del nodo, como puede ver en las líneas98 y 102 pulgadastikzlibrarytimeline.code.tex. Agregar draw=whitea las opciones del nodo demuestra esto:
Sin embargo, puedes parchear la \timelinemacro para eliminar el espacio, con
\usepackage{xpatch}
\xpatchcmd{\timeline}{\timespan\ \x}{\x}{}{}
No tengo respuesta para la parte del color.
Código completo con parche aplicado:
\documentclass[border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{timeline}
\usepackage{xpatch}
\xpatchcmd{\timeline}{\timespan\ \x}{\x}{}{}
\begin{document}
\begin{tikzpicture}[timespan={}]
% timespan={Day} -> now we have days as reference
% timespan={} -> no label is displayed for the timespan
% default timespan is 'Week'
\timeline[custom interval=true]{1966, 1971, 1979, 1980, 1981,1986,1996,2001,2006,2011,2016}
% \timeline[custom interval=true]{3,...,9} -> i.e., from Day 3 to Day 9
% \timeline{8} -> i.e., from Week 1 to Week 8
% put here the phases
\begin{phases}
\initialphase{involvement degree=0cm,phase color=black}
\phase{between week=1 and 1 in 0.5,involvement degree=1.65cm}
\phase{between week=2 and 3 in 0.5,involvement degree=3.5cm}
\phase{between week=3 and 4 in 0.5,involvement degree=0cm}
\phase{between week=4 and 5 in 0.5,involvement degree=0cm}
\phase{between week=5 and 6 in 0.5,involvement degree=0}
\phase{between week=5 and 6 in 0.5,involvement degree=2.5cm}
\phase{between week=6 and 7 in 0.5,involvement degree=1.9cm}
\phase{between week=7 and 8 in 0.5,involvement degree=3cm}
\phase{between week=8 and 9 in 0.5,involvement degree =1.7cm}
\end{phases}
% put here the milestones
\addmilestone{at=phase-0.270,direction=270:2cm,text={Obote/UPC win First Multiparty elections},text options={below}} %1962
\addmilestone{at=phase-1.110,direction=90:2cm,text={Obote attacks President Mutesa palace},text options={above}}
\addmilestone{at=phase-2.110,direction=90:1.5cm,text={Idi Amin's Reign of Terror},text options={above}}
\addmilestone{at=phase-6.270,direction=270:1cm,text={Museveni Bush War},text options={below}}
\addmilestone{at=phase-7.110,direction=110:1.5cm,text={Northern Uganda War I},text options={above}}
\addmilestone{at=phase-8.90,direction=90:1.5cm,text={Northern Uganda War II},text options={above}}
\addmilestone{at=phase-9.60,direction=60:1.5cm,text={Northern Uganda War III},text options={above}}
%These are the problematic milestones I cannot get them placed at individual point dates, eg. 1966, 1971 etc...
\addmilestone{at=-1.south,direction=240:1.5cm,text={Obote abrogates Constitution },text options={below}} % 1966
\addmilestone{at=-2.south,direction=270:1.cm,text={Idi Amin overthrows Obote },text options={below}} % 1971
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Multiparty elections. Obote wins },text options={below}} % 1980
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Museveni starts Bush war},text options={below}} % 1981
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Okellos overthrow Obote II},text options={below}} 1985
%\addmilestone{at=phase-6.170,direction=170:1.5cm,text={Museveni seizes power from Okellos},text options={below}} 1986
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={``No party'' elections. Museveni wins },text options={below}} % 1996
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={``No party'' elections, Museveni wins },text options={below}} % 2001
%\addmilestone{at=phase-8.250,direction=240:1.5cm,text={Multiparty elections, Museveni wins },text options={below}} % 2006
\end{tikzpicture}
\end{document}
