내 프로젝트 에서 Gitlab의 파비콘을 표시하는 데 문제가 있습니다 . 내 생각에는 moderncv
.
저는 Ubuntu 컴퓨터를 사용하고 있으며 먼저 texlive-latex-extra
.
moderncv
인터넷 검색을 한 후에 TeX Live의 버전이 최신 버전이 아니라는 것을 알았습니다 . 그래서 git repo를 복제 moderncv
해서 /home/{user}/texmf/tex/latex/moderncv
.
$ kpsewhich -var-value=TEXMFHOME
/home/{user}/texmf
moderncv
따라서 내 홈 폴더에 있는 최신 버전이 우선 순위가 있다고 생각합니다 . 그러나 분명히 그렇지 않습니다.
예제 템플릿을 컴파일하려고 하면moderncv
%% start of file `template.tex'.
%% Copyright 2006-2015 Xavier Danaux ([email protected]).
%
% This work may be distributed and/or modified under the
% conditions of the LaTeX Project Public License version 1.3c,
% available at http://www.latex-project.org/lppl/.
\documentclass[11pt,a4paper,sans]{moderncv} % possible options include font size ('10pt', '11pt' and '12pt'), paper size ('a4paper', 'letterpaper', 'a5paper', 'legalpaper', 'executivepaper' and 'landscape') and font family ('sans' and 'roman')
% moderncv themes
\moderncvstyle{casual} % style options are 'casual' (default), 'classic', 'banking', 'oldstyle' and 'fancy'
\moderncvcolor{blue} % color options 'black', 'blue' (default), 'burgundy', 'green', 'grey', 'orange', 'purple' and 'red'
%\renewcommand{\familydefault}{\sfdefault} % to set the default font; use '\sfdefault' for the default sans serif font, '\rmdefault' for the default roman one, or any tex font name
%\nopagenumbers{} % uncomment to suppress automatic page numbering for CVs longer than one page
% character encoding
%\usepackage[utf8]{inputenc} % if you are not using xelatex ou lualatex, replace by the encoding you are using
%\usepackage{CJKutf8} % if you need to use CJK to typeset your resume in Chinese, Japanese or Korean
% adjust the page margins
\usepackage[scale=0.75]{geometry}
%\setlength{\hintscolumnwidth}{3cm} % if you want to change the width of the column with the dates
%\setlength{\makecvheadnamewidth}{10cm} % for the 'classic' style, if you want to force the width allocated to your name and avoid line breaks. be careful though, the length is normally calculated to avoid any overlap with your personal info; use this at your own typographical risks...
% personal data
\name{John}{Doe}
\title{Resumé title} % optional, remove / comment the line if not wanted
\address{street and number}{postcode city}{country}% optional, remove / comment the line if not wanted; the "postcode city" and "country" arguments can be omitted or provided empty
\phone[mobile]{+1~(234)~567~890} % optional, remove / comment the line if not wanted; the optional "type" of the phone can be "mobile" (default), "fixed" or "fax"
\phone[fixed]{+2~(345)~678~901}
\phone[fax]{+3~(456)~789~012}
\email{[email protected]} % optional, remove / comment the line if not wanted
\homepage{www.johndoe.com} % optional, remove / comment the line if not wanted
\social[linkedin]{john.doe} % optional, remove / comment the line if not wanted
\social[xing]{john\_doe} % optional, remove / comment the line if not wanted
\social[twitter]{jdoe} % optional, remove / comment the line if not wanted
\social[github]{jdoe} % optional, remove / comment the line if not wanted
\social[gitlab]{jdoe} % optional, remove / comment the line if not wanted
\social[skype]{jdoe} % optional, remove / comment the line if not wanted
\extrainfo{additional information} % optional, remove / comment the line if not wanted
\photo[64pt][0.4pt]{picture} % optional, remove / comment the line if not wanted; '64pt' is the height the picture must be resized to, 0.4pt is the thickness of the frame around it (put it to 0pt for no frame) and 'picture' is the name of the picture file
\quote{Some quote} % optional, remove / comment the line if not wanted
% bibliography adjustements (only useful if you make citations in your resume, or print a list of publications using BibTeX)
% to show numerical labels in the bibliography (default is to show no labels)
%\makeatletter\renewcommand*{\bibliographyitemlabel}{\@biblabel{\arabic{enumiv}}}\makeatother
\renewcommand*{\bibliographyitemlabel}{[\arabic{enumiv}]}
% to redefine the bibliography heading string ("Publications")
%\renewcommand{\refname}{Articles}
% bibliography with mutiple entries
%\usepackage{multibib}
%\newcites{book,misc}{{Books},{Others}}
%----------------------------------------------------------------------------------
% content
%----------------------------------------------------------------------------------
\begin{document}
%\begin{CJK*}{UTF8}{gbsn} % to typeset your resume in Chinese using CJK
%----- resume ---------------------------------------------------------
\makecvtitle
\section{Education}
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description} % arguments 3 to 6 can be left empty
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description}
\section{Master thesis}
\cvitem{title}{\emph{Title}}
\cvitem{supervisors}{Supervisors}
\cvitem{description}{Short thesis abstract}
\section{Experience}
\subsection{Vocational}
\cventry{year--year}{Job title}{Employer}{City}{}{General description no longer than 1--2 lines.\newline{}%
Detailed achievements:%
\begin{itemize}%
\item Achievement 1;
\item Achievement 2, with sub-achievements:
\begin{itemize}%
\item Sub-achievement (a);
\item Sub-achievement (b), with sub-sub-achievements (don't do this!);
\begin{itemize}
\item Sub-sub-achievement i;
\item Sub-sub-achievement ii;
\item Sub-sub-achievement iii;
\end{itemize}
\item Sub-achievement (c);
\end{itemize}
\item Achievement 3.
\end{itemize}}
\cventry{year--year}{Job title}{Employer}{City}{}{Description line 1\newline{}Description line 2}
\subsection{Miscellaneous}
\cventry{year--year}{Job title}{Employer}{City}{}{Description}
\section{Languages}
\cvitemwithcomment{Language 1}{Skill level}{Comment}
\cvitemwithcomment{Language 2}{Skill level}{Comment}
\cvitemwithcomment{Language 3}{Skill level}{Comment}
\section{Computer skills}
\cvdoubleitem{category 1}{XXX, YYY, ZZZ}{category 4}{XXX, YYY, ZZZ}
\cvdoubleitem{category 2}{XXX, YYY, ZZZ}{category 5}{XXX, YYY, ZZZ}
\cvdoubleitem{category 3}{XXX, YYY, ZZZ}{category 6}{XXX, YYY, ZZZ}
\section{Interests}
\cvitem{hobby 1}{Description}
\cvitem{hobby 2}{Description}
\cvitem{hobby 3}{Description}
\section{Extra 1}
\cvlistitem{Item 1}
\cvlistitem{Item 2}
\cvlistitem{Item 3. This item is particularly long and therefore normally spans over several lines. Did you notice the indentation when the line wraps?}
\section{Extra 2}
\cvlistdoubleitem{Item 1}{Item 4}
\cvlistdoubleitem{Item 2}{Item 5\cite{book1}}
\cvlistdoubleitem{Item 3}{Item 6. Like item 3 in the single column list before, this item is particularly long to wrap over several lines.}
\section{References}
\begin{cvcolumns}
\cvcolumn{Category 1}{\begin{itemize}\item Person 1\item Person 2\item Person 3\end{itemize}}
\cvcolumn{Category 2}{Amongst others:\begin{itemize}\item Person 1, and\item Person 2\end{itemize}(more upon request)}
\cvcolumn[0.5]{All the rest \& some more}{\textit{That} person, and \textbf{those} also (all available upon request).}
\end{cvcolumns}
% Publications from a BibTeX file without multibib
% for numerical labels: \renewcommand{\bibliographyitemlabel}{\@biblabel{\arabic{enumiv}}}% CONSIDER MERGING WITH PREAMBLE PART
% to redefine the heading string ("Publications"): \renewcommand{\refname}{Articles}
\nocite{*}
\bibliographystyle{plain}
\bibliography{publications} % 'publications' is the name of a BibTeX file
% Publications from a BibTeX file using the multibib package
%\section{Publications}
%\nocitebook{book1,book2}
%\bibliographystylebook{plain}
%\bibliographybook{publications} % 'publications' is the name of a BibTeX file
%\nocitemisc{misc1,misc2,misc3}
%\bibliographystylemisc{plain}
%\bibliographymisc{publications} % 'publications' is the name of a BibTeX file
\clearpage
%----- letter ---------------------------------------------------------
% recipient data
\recipient{Company Recruitment team}{Company, Inc.\\123 somestreet\\some city}
\date{January 01, 1984}
\opening{Dear Sir or Madam,}
\closing{Yours faithfully,}
\enclosure[Attached]{curriculum vit\ae{}} % use an optional argument to use a string other than "Enclosure", or redefine \enclname
\makelettertitle
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Duis ullamcorper neque sit amet lectus facilisis sed luctus nisl iaculis. Vivamus at neque arcu, sed tempor quam. Curabitur pharetra tincidunt tincidunt. Morbi volutpat feugiat mauris, quis tempor neque vehicula volutpat. Duis tristique justo vel massa fermentum accumsan. Mauris ante elit, feugiat vestibulum tempor eget, eleifend ac ipsum. Donec scelerisque lobortis ipsum eu vestibulum. Pellentesque vel massa at felis accumsan rhoncus.
Suspendisse commodo, massa eu congue tincidunt, elit mauris pellentesque orci, cursus tempor odio nisl euismod augue. Aliquam adipiscing nibh ut odio sodales et pulvinar tortor laoreet. Mauris a accumsan ligula. Class aptent taciti sociosqu ad litora torquent per conubia nostra, per inceptos himenaeos. Suspendisse vulputate sem vehicula ipsum varius nec tempus dui dapibus. Phasellus et est urna, ut auctor erat. Sed tincidunt odio id odio aliquam mattis. Donec sapien nulla, feugiat eget adipiscing sit amet, lacinia ut dolor. Phasellus tincidunt, leo a fringilla consectetur, felis diam aliquam urna, vitae aliquet lectus orci nec velit. Vivamus dapibus varius blandit.
Duis sit amet magna ante, at sodales diam. Aenean consectetur porta risus et sagittis. Ut interdum, enim varius pellentesque tincidunt, magna libero sodales tortor, ut fermentum nunc metus a ante. Vivamus odio leo, tincidunt eu luctus ut, sollicitudin sit amet metus. Nunc sed orci lectus. Ut sodales magna sed velit volutpat sit amet pulvinar diam venenatis.
Albert Einstein discovered that $e=mc^2$ in 1905.
\[ e=\lim_{n \to \infty} \left(1+\frac{1}{n}\right)^n \]
\makeletterclosing
%\clearpage\end{CJK*} % if you are typesetting your resume in Chinese using CJK; the \clearpage is required for fancyhdr to work correctly with CJK, though it kills the page numbering by making \lastpage undefined
\end{document}
%% end of file `template.tex'.
다음 오류가 발생합니다.
Undefined control sequence.
\gitlabsocialsymbol ->{\small \faGitlab
차이가 있다면 LaTeX Workshop 플러그인과 함께 VS Code를 사용하고 있습니다. 사용하고 있는 컴파일러는 latexmk
.
라인을 꺼내면 social[gitlab]{jdoe}
모든 것이 잘 작동합니다.
누구든지 이 문제를 해결하는 데 도움을 주시면 정말 감사하겠습니다. 필요한 추가 정보를 제공해 드리겠습니다.
답변1
modencv
어떤 버전을 사용 하고 있는지 알려주지 않았습니다 fontawesome
.
마침내 우분투(및 데비안)는 TeX Live의 오래된 버전을 설치했습니다. 더 나은 방법은 다음과 같이 설치할 수 있는 원본 TeX Live를 사용하는 것입니다. 이 질문.
fontawesome
Ubuntu에서만 설치를 시도하려면 다음 명령을 사용하십시오.
sudo apt-get install texlive-fonts-extra
FNDB가 업데이트되고 모든 글꼴 맵이 로드되었는지 확인하십시오(저는 우분투를 사용하지 않으며 해당 OS에서 어떻게 수행되는지 모르겠습니다).
TeX Live new를 설치한 후 수동으로 업데이트된 moderncv
. 따라서 moderncv
이력서의 서문 에 필요한 변경 사항을 추가하는 것이 좋습니다 .
다음 코드를 참조하세요(중요한 코드 변경 사항은 모두 로 표시했습니다 . 링크에서 오늘 사용하고 더 안전한 코드 <=========
로 변경했음을 확인하세요 ).http
https
\documentclass[11pt,a4paper,sans]{moderncv}
% moderncv themes
\moderncvstyle{casual} % casual, classic, banking, oldstyle and fancy
\moderncvcolor{blue}
\usepackage[utf8]{inputenc}
\usepackage[scale=0.75]{geometry}
% makes a https hyperlink
% usage: \httpslink[optional text]{link}
\newcommand*{\httpslink}[2][]{% <=======================================
\ifthenelse{\equal{#1}{}}%
{\href{https://#2}{#2}}%
{\href{https://#2}{#1}}}
\newcommand*{\xingsocialsymbol} {{\small\faXing}~} % <===============
\newcommand*{\gitlabsocialsymbol} {{\small\faGitlab}~} % <=============
\newcommand*{\skypesocialsymbol} {{\small\faSkype}~} % <==============
\makeatletter % <=======================================================
\RenewDocumentCommand{\social}{O{}O{}m}{%
\ifthenelse{\equal{#2}{}}%
{%
\ifthenelse{\equal{#1}{linkedin}}{\collectionadd[linkedin]{socials}{\protect\httpslink[#3]{www.linkedin.com/in/#3}}} {}%
\ifthenelse{\equal{#1}{xing}} {\collectionadd[xing]{socials} {\protect\httpslink[#3]{www.xing.com/profile/#3}}}{}%
\ifthenelse{\equal{#1}{twitter}} {\collectionadd[twitter]{socials} {\protect\httpslink[#3]{www.twitter.com/#3}}} {}%
\ifthenelse{\equal{#1}{github}} {\collectionadd[github]{socials} {\protect\httpslink[#3]{www.github.com/#3}}} {}%
\ifthenelse{\equal{#1}{gitlab}} {\collectionadd[gitlab]{socials} {\protect\httpslink[#3]{www.gitlab.com/#3}}} {}%
\ifthenelse{\equal{#1}{skype}} {\collectionadd[skype]{socials} {#3}} {}%
}
{\collectionadd[#1]{socials}{\protect\httpslink[#3]{#2}}}}
\makeatother % <========================================================
% personal data
\name{John}{Doe}
\title{Resumé title}
\address{street and number}{postcode city}{country}
\phone[mobile]{+1~(234)~567~890}
\phone[fixed]{+2~(345)~678~901}
\phone[fax]{+3~(456)~789~012}
\email{[email protected]}
\homepage{www.johndoe.com}
\social[linkedin]{john.doe}
\social[xing]{john\_doe} % <============================================
\social[twitter]{jdoe}
\social[github]{jdoe}
\social[gitlab]{jdoe}
\social[skype]{jdoe} % <================================================
\extrainfo{additional information}
\quote{Some quote}
\setlength{\footskip}{66pt}
\begin{document}
\makecvtitle
\section{Education}
\cventry{year--year}{Degree}{Institution--3}{City--4}{\textit{Grade}--5}{Description--6} % arguments 3 to 6 can be left empty
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description}
\section{Master thesis}
\cvitem{title}{\emph{Title}}
\cvitem{supervisors}{Supervisors}
\cvitem{description}{Short thesis abstract}
\section{Experience}
\subsection{Vocational}
\cventry{year--year}{Job title}{Employer}{City}{}{General description
no longer than 1--2 lines.\newline{}%
Detailed achievements:%
\begin{itemize}%
\item Achievement 1;
\item Achievement 2, with sub-achievements:
\begin{itemize}%
\item Sub-achievement (a);
\item Sub-achievement (b), with sub-sub-achievements (don't do this!);
\begin{itemize}
\item Sub-sub-achievement i;
\item Sub-sub-achievement ii;
\item Sub-sub-achievement iii;
\end{itemize}
\item Sub-achievement (c);
\end{itemize}
\item Achievement 3.
\end{itemize}}
\cventry{year--year}{Job title}{Employer}{City}{}{Description
line 1\newline{}Description line 2}
\subsection{Miscellaneous}
\cventry{year--year}{Job title}{Employer}{City}{}{Description}
\section{Languages}
\cvitemwithcomment{Language 1}{Skill level}{Comment}
\cvitemwithcomment{\textbf{Language} 2}{\textbf{Skill} level}{Comment}
\cvitemwithcomment{Language 3}{Skill level}{Comment}
\section{Computer skills}
\cvdoubleitem{category 1}{XXX, YYY, ZZZ}{category 4}{XXX, YYY, ZZZ}
\cvdoubleitem{category 2}{XXX, YYY, ZZZ}{category 5}{XXX, YYY, ZZZ}
\cvdoubleitem{category 3}{XXX, YYY, ZZZ}{category 6}{XXX, YYY, ZZZ}
\section{Interests}
\cvitem{hobby 1}{Description}
\cvitem{hobby 2}{Description}
\cvitem{hobby 3}{Description}
\section{Extra 1}
\cvlistitem{Item 1}
\cvlistitem{Item 2}
\cvlistitem{Item 3. This item is particularly long and therefore
normally spans over several lines. Did you notice the indentation
when the line wraps?}
\section{Extra 2}
\cvlistdoubleitem{Item 1}{Item 4}
\cvlistdoubleitem{Item 2}{Item 5}
\cvlistdoubleitem{Item 3}{Item 6. Like item 3 in the single column list before, this item is particularly long to wrap over several lines.}
\section{References}
\begin{cvcolumns}
\cvcolumn{Category 1}{\begin{itemize}\item Person 1\item Person 2\item Person 3\end{itemize}}
\cvcolumn{Category 2}{Amongst others:\begin{itemize}\item Person 1, and\item Person 2\end{itemize}(more upon request)}
\cvcolumn[0.5]{All the rest \& some more}{\textit{That} person, and \textbf{those} also (all available upon request).}
\end{cvcolumns}
\end{document}
결과는 다음과 같습니다.
moderncv
이것은 현재 클래스 2.0.0(github이 아닌 ctan의 것!), 현재 Fontawesome fontawesome.sty 2016/05/15 v4.6.3.1 font awesome icons
및 현재 MiKTeX 로 컴파일됩니다 pdfTeX, Version 3.14159265-2.6-1.40.20 (MiKTeX 2.9.6960 64-bit)
.
