Traefik 대시보드는 404 페이지를 찾을 수 없음 + TLS 핸드셰이크 오류: 원격 오류: tls: 잘못된 인증서를 반환합니다(traefik + bin9 + CloudFlare + Let's Encrypt)

tag-icon • tag-icon ssl docker bind wildcard traefik
Traefik 대시보드는 404 페이지를 찾을 수 없음 + TLS 핸드셰이크 오류: 원격 오류: tls: 잘못된 인증서를 반환합니다(traefik + bin9 + CloudFlare + Let's Encrypt)

가이드를 사용하여 docker에서 Traefik을 구성했습니다.모든 것에 와일드카드 인증서와 SSL을 적용하세요 - Traefik Tutorial

하지만 대시보드에 액세스하려고 하면 404 페이지를 찾을 수 없다는 오류가 표시됩니다. 여기에 이미지 설명을 입력하세요

나는 여러 포럼에서 이 질문을 했습니다.

  1. 도커 포럼
  2. Traefik 포럼
  3. AskUbuntu 포럼
  4. StackOverFlow 포럼
  5. ServerFault 포럼

나는 모든 것을 시도했습니다:

  1. Ubuntu 및 라우터에서 방화벽을 비활성화했습니다.
  2. 로컬 IP와 로컬 컴퓨터 IP 모두에서 로그인을 시도했습니다: localhost 및 192.168.88.253
  3. Traefik과 Bind9가 모두 동일한 네트워크에 있도록 docker compose 파일을 구성하고 Traefik-dashboard 항목을 추가하여 Bind 9에 하위 도메인을 구성했습니다. 도메인에서 Traefik 대시보드에 액세스할 수 없었고 여전히 액세스할 수 없습니다. 그런데 로컬 ip로도, localhost로도 입력이 안되네요.

아래에서는 docker-compose 파일, 오류 로그 등을 포함한 모든 팁을 제공하겠습니다. 제 결함을 지적하고 이 문제를 해결하는 데 도움을 주시면 매우 감사하겠습니다.

traefik docker-compose.yml부터 시작해 보겠습니다.

version: '3.8'

services:
  traefik:
    image: traefik:latest
    container_name: traefik
    restart: unless-stopped
    security_opt:
      - no-new-privileges:true
    networks:
      proxy1:
      dns-server_dns-network:
        ipv4_address: 10.20.3.5
    ports:
      - 80:80
      - 443:443
    environment:
      - CF_API_EMAIL=****@protonmail.com
      - CF_DNS_API_TOKEN=mdc3Xlhxpuidm***
      # - CF_API_KEY=YOUR_API_KEY
      # be sure to use the correct one depending on if you are using a token or key
    volumes:
      - /etc/localtime:/etc/localtime:ro
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - /root/traefik/data/traefik.yml:/traefik.yml:ro
      - /root/traefik/data/acme.json:/acme.json
      - /root/traefik/data/config.yml:/config.yml:ro
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.traefik.entrypoints=http"
      - "traefik.http.routers.traefik.rule=Host(`traefik-dashboard.local.****.com`)"
      - "traefik.http.middlewares.traefik-auth.basicauth.users=USER:BASIC_AUTH_PASSWORD"
      - "traefik.http.middlewares.traefik-https-redirect.redirectscheme.scheme=https"
      - "traefik.http.middlewares.sslheader.headers.customrequestheaders.X-Forwarded-Proto=https"
      - "traefik.http.routers.traefik.middlewares=traefik-https-redirect"
      - "traefik.http.routers.traefik-secure.entrypoints=https"
      - "traefik.http.routers.traefik-secure.rule=Host(`traefik-dashboard.local.****.com`)"
      - "traefik.http.routers.traefik-secure.middlewares=traefik-auth"
      - "traefik.http.routers.traefik-secure.tls=true"
      - "traefik.http.routers.traefik-secure.tls.certresolver=cloudflare"
      - "traefik.http.routers.traefik-secure.tls.domains[0].main=local.****.com"
      - "traefik.http.routers.traefik-secure.tls.domains[0].sans=*.local.****.com"
      - "traefik.http.routers.traefik-secure.service=api@internal"

networks:
  dns-server_dns-network:
    external: true
  proxy1:
    external: true

조금 설명하겠습니다. dns-server_dns-network는 dns-server(bind9)의 네트워크입니다. 이 역시 docker 컨테이너 내부에 있지만 다른 것입니다. 이 경우 로컬 하위 도메인을 할당해야 하며 모든 것이 올바르게 작동합니다..proxy1 - Traefik 자체의 네트워크입니다.

Traefik config.yml:

http:
 #region routers
  routers:
    bind9:
      entryPoints:
        - "https"
      rule: "Host(`bind9.local.*****.com`)"
      middlewares:
        - default-headers
        - https-redirectscheme
      tls: {}
      service: bind9
    pterodactyl:
      entryPoints:
        - "https"
      rule: "Host(`pterodactyl.local.*****.com`)"
      middlewares:
        - default-headers
        - https-redirectscheme
      tls: {}
      service: pterodactyl
#endregion
#region services
  services:
    bind9:
      loadBalancer:
        servers:
          - url: "https://10.20.3.2:53"
        passHostHeader: true
    pterodactyl:
      loadBalancer:
        servers:
          - url: "http://10.20.3.6:8082"
        passHostHeader: true
#endregion
  middlewares:
    addprefix-pihole:
      addPrefix:
prefix: "/admin"
    https-redirectscheme:
      redirectScheme:
        scheme: https
        permanent: true
    redirectregex-pihole:
      redirectRegex:
        regex: /admin/$
        replacement: /

    default-headers:
      headers:
        frameDeny: true
        browserXssFilter: true
        contentTypeNosniff: true
        forceSTSHeader: true
        stsIncludeSubdomains: true
        stsPreload: true
        stsSeconds: 15552000
        customFrameOptionsValue: SAMEORIGIN
        customRequestHeaders:
          X-Forwarded-Proto: https

    idrac:
      headers:
        frameDeny: true
        browserXssFilter: true
        forceSTSHeader: true
        stsIncludeSubdomains: true
        stsSeconds: 15552000
        customFrameOptionsValue: SAMEORIGIN
        customRequestHeaders:
          X-Forwarded-Proto: https

    default-whitelist:
      ipWhiteList:
        sourceRange:
        - "10.0.0.0/8"
        - "192.168.88.0/24"
        - "172.16.0.0/12"

    secured:
      chain:
        middlewares:
        - default-whitelist
        - default-headers

Traefik.yml:

api:
  dashboard: true
  debug: true
entryPoints:
  http:
    address: ":80"
    http:
      redirections:
        entryPoint:
          to: https
          scheme: https
  https:
    address: ":443"
serversTransport:
  insecureSkipVerify: true
providers:
  docker:
    endpoint: "unix:///var/run/docker.sock"
    exposedByDefault: false
  file:
    filename: /config.yml
certificatesResolvers:
  cloudflare:
    acme:
      email: ****@protonmail.com
      storage: acme.json
      dnsChallenge:
        delayBeforeCheck: 5
        provider: cloudflare
       #disablePropagationCheck: true # uncomment this if you have issues pulling certificates through cloudflare, By setting this flag to true disables>
        resolvers:
          - "1.1.1.1:53"
          - "1.0.0.1:53"

acme.json 파일:

{
  "cloudflare": {
    "Account": {
      "Email": "*****@protonmail.com",
      "Registration": {
        "body": {
          "status": "valid",
          "contact": [
            "mailto:****@protonmail.com"
          ]
        },
        "uri": "https://acme-v02.api.letsencrypt.org/acme/acct/1308****76"
      },
      "PrivateKey": "MIIJKQ**********fhYGyV2xowwa/O9WSHf+3GU>
      "KeyType": "4096"
    },
    "Certificates": [
      {
        "domain": {
          "main": "local.*****.com",
          "sans": [
            "*.local.*****.com"
          ]
        },
        "certificate": "LS0tLS1C***********N3VUEKTURJ>
        "key": "LS0tLS1CRUdJTiBS*******Bejk4bzdCeTBtCnhLVFFC>
        "Store": "default"
      }
    ]
  }
}

컨테이너와 함께 Traefik을 실행하면 로그에 아무것도 없습니다.

root@riven:~/traefik/data# docker logs --tail=100 traefik
time="2023-09-14T03:47:43+03:00" level=info msg="Configuration loaded from file: /traefik.yml"

그러나 restart를 작성하면 로그에 오류가 표시됩니다.

root@riven:~/traefik/data# docker restart traefik
traefik
root@riven:~/traefik/data# docker logs --tail=100 traefik
time="2023-09-14T03:47:43+03:00" level=info msg="Configuration loaded from file: /traefik.yml"
time="2023-09-14T14:37:35+03:00" level=error msg="accept tcp [::]:80: use of closed network connection" entryPointName=http
time="2023-09-14T14:37:35+03:00" level=error msg="accept tcp [::]:443: use of closed network connection" entryPointName=https
time="2023-09-14T14:37:35+03:00" level=error msg="close tcp [::]:80: use of closed network connection" entryPointName=http
time="2023-09-14T14:37:35+03:00" level=error msg="close tcp [::]:443: use of closed network connection" entryPointName=https
time="2023-09-14T14:37:36+03:00" level=info msg="Configuration loaded from file: /traefik.yml"

혹시라도 모든 컨테이너 목록은 다음과 같습니다.

root@riven:~/dns-server/config# docker ps -a
CONTAINER ID   IMAGE                 COMMAND                  CREATED        STATUS          PORTS                                                                           NAMES
78296a683271   traefik:latest        "/entrypoint.sh trae…"   11 hours ago   Up 25 minutes   0.0.0.0:80->80/tcp, :::80->80/tcp, 0.0.0.0:443->443/tcp, :::443->443/tcp        traefik
5c3081b0c7df   ubuntu/bind9:latest   "docker-entrypoint.sh"   12 hours ago   Up 8 minutes    0.0.0.0:53->53/tcp, 0.0.0.0:53->53/udp, :::53->53/tcp, :::53->53/udp, 953/tcp   dns-server

이제 역시 컨테이너에서 실행되는 DNS 서버 바인딩9로 이동해 보겠습니다.

바인드9 docker-compose.yml:

version: '3'

networks:
  dns-network:
    driver: bridge
    ipam:
      config:
        - subnet: 10.20.0.0/16

services:
  bind9:
    container_name: dns-server
    image: ubuntu/bind9:latest
    environment:
      - BIND9_USER=root
      - TZ=Europe/Moscow
    networks:
      dns-network:
        ipv4_address: 10.20.3.2
    ports:
      - "53:53/tcp"
      - "53:53/udp"
    volumes:
      - ./config:/etc/bind
      - ./cache:/var/cache/bind
      - ./records:/var/lib/bind
    restart: unless-stopped

명명된.conf 파일:

acl internal {
    10.10.0.0/16;
    10.11.0.0/16;
    10.20.0.0/16;
    10.50.0.0/16;
    192.168.88.0/24;
};

options {
    forwarders {
        1.1.1.1;
        1.0.0.1;
    };
    allow-query { internal; };
};

zone "local.*****.com" IN {
    type master;
    file "/etc/bind/local-*****-com.zone";
};

local-*****-com.zone 파일:

$TTL 2D

$ORIGIN local.*****.com.

@       IN      SOA     ns.local.*****.com.  admin.*****.com. (
                        2023083100      ; serial
                        12h             ; refresh
                        15m             ; retry
                        3w              ; expire
                        2h              ; minimum ttl
)

        IN      NS      ns.local.*****.com.

ns      IN      A       10.20.3.2

; -- add dns records below

servers IN      A       10.20.3.4
*.servers IN    A       10.20.3.4
traefik-dashboard IN A 10.20.3.5

Bind9 로그:

root@riven:~/dns-server/config# docker logs --tail=200 dns-server
Starting named....
exec /usr/sbin/named -u "root" "-g" ""
14-Sep-2023 14:54:56.133 starting BIND 9.18.12-1ubuntu1.1-Ubuntu (Extended Support Version) <id:>
14-Sep-2023 14:54:56.133 running on Linux x86_64 6.2.0-32-generic #32~22.04.1-Ubuntu SMP PREEMPT_DYNAMIC Fri Aug 18 10:40:13 UTC 2
14-Sep-2023 14:54:56.133 built with  '--build=x86_64-linux-gnu' '--prefix=/usr' '--includedir=${prefix}/include' '--mandir=${prefix}/share/man' '--infodir=${prefix}/share/info' '--sysconfdir=/etc' '--localstatedir=/var' '--disable-option-checking' '--disable-silent-rules' '--libdir=${prefix}/lib/x86_64-linux-gnu' '--runstatedir=/run' '--disable-maintainer-mode' '--disable-dependency-tracking' '--libdir=/usr/lib/x86_64-linux-gnu' '--sysconfdir=/etc/bind' '--with-python=python3' '--localstatedir=/' '--enable-threads' '--enable-largefile' '--with-libtool' '--enable-shared' '--disable-static' '--with-gost=no' '--with-openssl=/usr' '--with-gssapi=yes' '--with-libidn2' '--with-json-c' '--with-lmdb=/usr' '--with-gnu-ld' '--with-maxminddb' '--with-atf=no' '--enable-ipv6' '--enable-rrl' '--enable-filter-aaaa' '--disable-native-pkcs11' 'build_alias=x86_64-linux-gnu' 'CFLAGS=-g -O2 -ffile-prefix-map=/build/bind9-2zwQl8/bind9-9.18.12=. -flto=auto -ffat-lto-objects -fstack-protector-strong -Wformat -Werror=format-security -fdebug-prefix-map=/build/bind9-2zwQl8/bind9-9.18.12=/usr/src/bind9-1:9.18.12-1ubuntu1.1 -fno-strict-aliasing -fno-delete-null-pointer-checks -DNO_VERSION_DATE -DDIG_SIGCHASE' 'LDFLAGS=-Wl,-Bsymbolic-functions -flto=auto -ffat-lto-objects -Wl,-z,relro -Wl,-z,now' 'CPPFLAGS=-Wdate-time -D_FORTIFY_SOURCE=2'
14-Sep-2023 14:54:56.133 running as: named -u root -g
14-Sep-2023 14:54:56.133 compiled by GCC 12.2.0
14-Sep-2023 14:54:56.133 compiled with OpenSSL version: OpenSSL 3.0.8 7 Feb 2023
14-Sep-2023 14:54:56.133 linked to OpenSSL version: OpenSSL 3.0.8 7 Feb 2023
14-Sep-2023 14:54:56.133 compiled with libxml2 version: 2.9.14
14-Sep-2023 14:54:56.133 linked to libxml2 version: 20914
14-Sep-2023 14:54:56.133 compiled with json-c version: 0.16
14-Sep-2023 14:54:56.133 linked to json-c version: 0.16
14-Sep-2023 14:54:56.133 compiled with zlib version: 1.2.13
14-Sep-2023 14:54:56.133 linked to zlib version: 1.2.13
14-Sep-2023 14:54:56.133 ----------------------------------------------------
14-Sep-2023 14:54:56.133 BIND 9 is maintained by Internet Systems Consortium,
14-Sep-2023 14:54:56.133 Inc. (ISC), a non-profit 501(c)(3) public-benefit
14-Sep-2023 14:54:56.133 corporation.  Support and training for BIND 9 are
14-Sep-2023 14:54:56.133 available at https://www.isc.org/support
14-Sep-2023 14:54:56.133 ----------------------------------------------------
14-Sep-2023 14:54:56.133 found 8 CPUs, using 8 worker threads
14-Sep-2023 14:54:56.133 using 8 UDP listeners per interface
14-Sep-2023 14:54:56.133 DNSSEC algorithms: RSASHA1 NSEC3RSASHA1 RSASHA256 RSASHA512 ECDSAP256SHA256 ECDSAP384SHA384 ED25519 ED448
14-Sep-2023 14:54:56.133 DS algorithms: SHA-1 SHA-256 SHA-384
14-Sep-2023 14:54:56.133 HMAC algorithms: HMAC-MD5 HMAC-SHA1 HMAC-SHA224 HMAC-SHA256 HMAC-SHA384 HMAC-SHA512
14-Sep-2023 14:54:56.133 TKEY mode 2 support (Diffie-Hellman): yes
14-Sep-2023 14:54:56.133 TKEY mode 3 support (GSS-API): yes
14-Sep-2023 14:54:56.137 config.c: option 'trust-anchor-telemetry' is experimental and subject to change in the future
14-Sep-2023 14:54:56.137 loading configuration from '/etc/bind/named.conf'
14-Sep-2023 14:54:56.137 unable to open '/etc/bind/bind.keys'; using built-in keys instead
14-Sep-2023 14:54:56.137 looking for GeoIP2 databases in '/usr/share/GeoIP'
14-Sep-2023 14:54:56.137 using default UDP/IPv4 port range: [32768, 60999]
14-Sep-2023 14:54:56.137 using default UDP/IPv6 port range: [32768, 60999]
14-Sep-2023 14:54:56.137 listening on IPv4 interface lo, 127.0.0.1#53
14-Sep-2023 14:54:56.141 listening on IPv4 interface eth0, 10.20.3.2#53
14-Sep-2023 14:54:56.141 Could not open '//run/named/named.pid'.
14-Sep-2023 14:54:56.141 Please check file and directory permissions or reconfigure the filename.
14-Sep-2023 14:54:56.141 could not open file '//run/named/named.pid': Permission denied
14-Sep-2023 14:54:56.141 generating session key for dynamic DNS
14-Sep-2023 14:54:56.141 Could not open '//run/named/session.key'.
14-Sep-2023 14:54:56.141 Please check file and directory permissions or reconfigure the filename.
14-Sep-2023 14:54:56.141 could not open file '//run/named/session.key': Permission denied
14-Sep-2023 14:54:56.141 could not create //run/named/session.key
14-Sep-2023 14:54:56.141 failed to generate session key for dynamic DNS: permission denied
14-Sep-2023 14:54:56.141 sizing zone task pool based on 1 zones
14-Sep-2023 14:54:56.141 none:99: 'max-cache-size 90%' - setting to 57829MB (out of 64255MB)
14-Sep-2023 14:54:56.141 using built-in root key for view _default
14-Sep-2023 14:54:56.141 set up managed keys zone for view _default, file 'managed-keys.bind'
14-Sep-2023 14:54:56.141 automatic empty zone: 10.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 16.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 17.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 18.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 19.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 20.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 21.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 22.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 23.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 24.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 25.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 26.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 27.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 28.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 29.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 30.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 31.172.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 168.192.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 64.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 65.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 66.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 67.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 68.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 69.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 70.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 71.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 72.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 73.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 74.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 75.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 76.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 77.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 78.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 79.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 80.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 81.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 82.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 83.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 84.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 85.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 86.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 87.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 88.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 89.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 90.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 91.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 92.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 93.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 94.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 95.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 96.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 97.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 98.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 99.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 100.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 101.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 102.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 103.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 104.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 105.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 106.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 107.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 108.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 109.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 110.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 111.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 112.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 113.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 114.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 115.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 116.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 117.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 118.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 119.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 120.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 121.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 122.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 123.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 124.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 125.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 126.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 127.100.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 0.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 127.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 254.169.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 2.0.192.IN-ADDR.ARPA
14-Sep-2023 14:54:56.141 automatic empty zone: 100.51.198.IN-ADDR.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 113.0.203.IN-ADDR.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 255.255.255.255.IN-ADDR.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 1.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: D.F.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 8.E.F.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 9.E.F.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: A.E.F.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: B.E.F.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: 8.B.D.0.1.0.0.2.IP6.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: EMPTY.AS112.ARPA
14-Sep-2023 14:54:56.145 automatic empty zone: HOME.ARPA
14-Sep-2023 14:54:56.145 configuring command channel from '/etc/bind/rndc.key'
14-Sep-2023 14:54:56.145 command channel listening on 127.0.0.1#953
14-Sep-2023 14:54:56.145 configuring command channel from '/etc/bind/rndc.key'
14-Sep-2023 14:54:56.145 command channel listening on ::1#953
14-Sep-2023 14:54:56.145 not using config file logging statement for logging due to -g option
14-Sep-2023 14:54:56.145 managed-keys-zone: loaded serial 2
14-Sep-2023 14:54:56.149 zone local.*****.com/IN: loaded serial 2023083100
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:1::53#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:dc3::35#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:503:ba3e::2:30#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:7fe::53#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:12::d0d#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:2::c#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:2f::f#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:a8::e#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:9f::42#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:7fd::1#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:503:c27::2:30#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:200::b#53
14-Sep-2023 14:54:56.149 address not available resolving './NS/IN': 2001:500:2d::d#53
14-Sep-2023 14:54:56.153 all zones loaded
14-Sep-2023 14:54:56.153 running
14-Sep-2023 14:54:56.173 managed-keys-zone: Key 20326 for zone . is now trusted (acceptance timer complete)
14-Sep-2023 14:54:56.177 resolver priming query complete: success

내 모든 네트워크:

root@riven:~/dns-server/config# docker network ls
NETWORK ID     NAME                     DRIVER    SCOPE
bed0ea1726ee   bridge                   bridge    local
37f54b168f7e   dns-server_dns-network   bridge    local
8db2a758902a   host                     host      local
d5d2a3a56006   none                     null      local
44f6196d71d9   proxy1                   bridge    local

컨테이너의 IP 주소 확인:

root@riven:~/dns-server/config# docker ps -a
CONTAINER ID   IMAGE                 COMMAND                  CREATED        STATUS          PORTS                                                                           NAMES
78296a683271   traefik:latest        "/entrypoint.sh trae…"   11 hours ago   Up 25 minutes   0.0.0.0:80->80/tcp, :::80->80/tcp, 0.0.0.0:443->443/tcp, :::443->443/tcp        traefik
5c3081b0c7df   ubuntu/bind9:latest   "docker-entrypoint.sh"   12 hours ago   Up 8 minutes    0.0.0.0:53->53/tcp, 0.0.0.0:53->53/udp, :::53->53/tcp, :::53->53/udp, 953/tcp   dns-server
root@riven:~/dns-server/config# docker inspect -f '{{range .NetworkSettings.Networks}}{{.IPAddress}}{{end}}' 78296a683271
10.20.3.5172.18.0.2
root@riven:~/dns-server/config# docker inspect -f '{{range .NetworkSettings.Networks}}{{.IPAddress}}{{end}}' 5c3081b0c7df
10.20.3.2

그러나 DNS 서버가 제대로 작동하는 것을 볼 수 있듯이 nslookup 쿼리에서 볼 수 있습니다.

root@riven:~/dns-server/config# nslookup local.*****.com
Server:         192.168.88.1
Address:        192.168.88.1#53

Non-authoritative answer:
Name:   local.*****.com
Address: 91.***.***.1*4

root@riven:~/dns-server/config# nslookup servers.local.*****.com 10.20.3.2
Server:         10.20.3.2
Address:        10.20.3.2#53

Name:   servers.local.*****.com
Address: 10.20.3.4

root@riven:~/dns-server/config# nslookup traefik-dashboard.local.*****.com 10.20.3.2
Server:         10.20.3.2
Address:        10.20.3.2#53

Name:   traefik-dashboard.local.*****.com
Address: 10.20.3.5

또한 로컬 도메인(local.*****.com)으로 이동하면 내 microtik 라우터 페이지가 표시됩니다. 여기에 이미지 설명을 입력하세요

하지만 traefik 패널에 들어가면 아무것도 작동하지 않는 것을 볼 수 있습니다.

여기에 이미지 설명을 입력하세요

곱슬 곱슬하다:

여기에 이미지 설명을 입력하세요 여기에 이미지 설명을 입력하세요

위의 모든 작업은 로컬 호스트 시스템에서 UFW(Ubuntu Firewall)가 완전히 비활성화된 상태에서 수행되고 있으며 mikrotik 방화벽도 비활성화되어 있습니다!!!

나는 내가 무엇을 잘못했는지, 어떻게 모든 것을 작동시킬 수 있는지 전혀 모릅니다. 적어도 Traefik 패널을 작동시키는 방법. 도움과 조언을 주시면 감사하겠습니다.

관련 정보
