Eu configurei o servidor DNS no bind conforme este artigo
Master=192.168.1.206=master.example.com
Client=192.168.1.3=client.example.com
//
// /etc/named.conf
//
// Provided by Red Hat bind package to configure the ISC BIND named(8) DNS
// server as a caching only nameserver (as a localhost DNS resolver only).
//
// See /usr/share/doc/bind*/sample/ for example named configuration files.
//
options {
#listen-on port 53 { 127.0.0.1; 192.168.1.2; };
#listen-on-v6 port 53 { ::1; };
directory "/var/named";
dump-file "/var/named/data/cache_dump.db";
statistics-file "/var/named/data/named_stats.txt";
memstatistics-file "/var/named/data/named_mem_stats.txt";
secroots-file "/var/named/data/named.secroots";
recursing-file "/var/named/data/named.recursing";
allow-query { localhost; 192.168.1.0/24; };
/*
- If you are building an AUTHORITATIVE DNS server, do NOT enable recursion.
- If you are building a RECURSIVE (caching) DNS server, you need to enable
recursion.
- If your recursive DNS server has a public IP address, you MUST enable access
control to limit queries to your legitimate users. Failing to do so will
cause your server to become part of large scale DNS amplification
attacks. Implementing BCP38 within your network would greatly
reduce such attack surface
*/
recursion yes;
#dnssec-validation yes;
managed-keys-directory "/var/named/dynamic";
geoip-directory "/usr/share/GeoIP";
pid-file "/run/named/named.pid";
session-keyfile "/run/named/session.key";
/* https://fedoraproject.org/wiki/Changes/CryptoPolicy */
include "/etc/crypto-policies/back-ends/bind.config";
};
logging {
channel default_debug {
file "data/named.run";
severity dynamic;
};
};
zone "." IN {
type hint;
file "named.ca";
};
include "/etc/named.rfc1912.zones";
include "/etc/named.root.key";
zone "example.com" IN {
type master;
file "forward";
allow-update { none; };
};
zone "1.168.192.in-addr.arpa" IN {
type master;
file "reverse";
allow-update { none; };
};
Eu configurei o arquivo de zona direta e reversa assim.
#forward
$TTL 86400
@ IN SOA master.example.com. admin.example.com. (
2023010401 ;Serial
3600 ;Refresh
1800 ;Retry
604800 ;Expire
86400 ;Minimum TTL
)
@ IN NS master.example.com.
@ IN A 192.168.1.206
@ IN A 192.168.1.3
@ IN A 192.168.1.4
master IN A 192.168.1.206
webserver IN A 192.168.1.4
#reverse
$TTL 86400
@ IN SOA master.example.com. admin.example.com. (
2023010401 ;Serial
3600 ;Refresh
1800 ;Retry
604800 ;Expire
86400 ;Minimum TTL
)
@ IN NS master.example.com.
@ IN PTR example.com.
master IN A 192.168.1.206
webserver IN A 192.168.1.4
206 IN PTR master.example.com.
4 IN PTR webserver.example.com.
Então eu configurei /etc/resolv.confisso no servidor mestre
search example.com
nameserver 192.168.1.206
Agora eu vou dominar e faço
dig example.com
Eu recebo a resposta, mas eu entendoAUTHORITY=0
[root@dns01 named]# dig example.com
; <<>> DiG 9.16.23-RH <<>> example.com
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 55501
;; flags: qr aa rd ra; QUERY: 1, ANSWER: 3, AUTHORITY: 0, ADDITIONAL: 1
;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 1232
; COOKIE: b15240d00532152a010000006623f6970bb37622180b1f28 (good)
;; QUESTION SECTION:
;example.com. IN A
;; ANSWER SECTION:
example.com. 86400 IN A 192.168.1.3
example.com. 86400 IN A 192.168.1.206
example.com. 86400 IN A 192.168.1.4
;; Query time: 0 msec
;; SERVER: 192.168.1.206#53(192.168.1.206)
;; WHEN: Sat Apr 20 18:08:39 WEST 2024
;; MSG SIZE rcvd: 123
Responder1
Se o seu sistema estiver usando systemd-resolved, você /etc/resolv.confpode estar sendo reescrito para apontar para nameserver 127.0.0.53o resolvedor de cache do systemd-resolved. Isso pode explicar a resposta não oficial: você pode obtê-la no cache do resolvedor.
(Se isso estiver acontecendo, é um sinal de que você deve considerar /etc/resolv.confesse sistema como um arquivo de configuração obsoleto que existe apenas para compatibilidade herdada. Consulte resolvectlas configurações reais do resolvedor de DNS nesse caso.)
Tente dizer explicitamente digpara conectar-se diretamente ao servidor autoritativo, em vez de confiar nos padrões:
dig example.com @192.168.1.206
