Como posso desenhar diagramas de loop para teoria de campo livre (física)

Como posso desenhar diagramas de loop para teoria de campo livre (física)

diagrama de loop

Eu tenho que desenhar as figuras mostradas na imagem. Estes são diagramas de loop dentro da equação.

Responder1

Aqui está uma coleção de diagramas para a teoria do campo livre, fornecida como phinman.sty(código no final desta resposta). Por motivos de espaçamento, existem duas versões de cada comando, uma com rótulos e outra sem.

insira a descrição da imagem aqui

O código da demonstração acima:

\documentclass{article}
\usepackage{phinman} % pronounce like Feynman
\usepackage{amsmath}
\usepackage{lipsum}
\begin{document}
\begin{center}
\begin{tabular}{lc@{\quad}lc}
\verb"\PM{-}"    & \PM{-}    & \verb"\PMl{-}{x}{y}"          & \PMl{-}{x}{y}          \\
\verb"\PM{x}"    & \PM{x}    & \verb"\PMl{x}{x}"             & \PMl{x}{x}             \\
\verb"\PM{||}"   & \PM{||}   & \verb"\PMl{||}{u}{v}{x}{y}"   & \PMl{||}{u}{v}{x}{y}   \\
\verb"\PM{=}"    & \PM{=}    & \verb"\PMl{=}{u}{v}{x}{y}"    & \PMl{=}{u}{v}{x}{y}    \\
\verb"\PM{X}"    & \PM{X}    & \verb"\PMl{X}{u}{v}{x}{y}"    & \PMl{X}{u}{v}{x}{y}    \\
\verb"\PM{--}"   & \PM{--}   & \verb"\PMl{--}{x}{y}"         & \PMl{--}{x}{y}         \\
\verb"\PM{-o-}"  & \PM{-o-}  & \verb"\PMl{-o-}{x}{y}{z}"     & \PMl{-o-}{x}{y}{z}     \\
\verb"\PM{8}"    & \PM{8}    & \verb"\PMl{8}{x}"             & \PMl{8}{x}             \\
\verb"\PM{88}"   & \PM{88}   & \verb"\PMl{88}{x}{y}"         & \PMl{88}{x}{y}         \\
\verb"\PM{ooo}"  & \PM{ooo}  & \verb"\PMl{ooo}{x}{y}"        & \PMl{ooo}{x}{y}        \\
\verb"\PM{-8-}"  & \PM{-8-}  & \verb"\PMl{-8-}{x}{y}{z}"     & \PMl{-8-}{x}{y}{z}     \\
\verb"\PM{-88-}" & \PM{-88-} & \verb"\PMl{-88-}{x}{u}{v}{y}" & \PMl{-88-}{x}{u}{v}{y} \\
\verb"\PM{-ooo-}"& \PM{-ooo-}& \verb"\PMl{-ooo-}{x}{u}{v}{y}"& \PMl{-ooo-}{x}{u}{v}{y}\\
\verb"\PM{-o8-}" & \PM{-o8-} & \verb"\PMl{-o8-}{x}{u}{v}{y}" & \PMl{-o8-}{x}{u}{v}{y}
\end{tabular}
\end{center}
\clearpage
\lipsum[1]
\begin{align*}
  \PMl{-}{x}{y}         & = i\Delta(x,y)\\
  \PMl{x}{y}            & = -i\lambda\\
  \langle\phi(x_1)\phi(x_2)\phi(x_3)\phi(x_4)\rangle_0
                        &= \PMl{||}{x_1}{x_2}{x_3}{x_4} + \PMl{=}{x_1}{x_2}{x_3}{x_4}
                           + \PMl{X}{x_1}{x_2}{x_3}{x_4}\\
  \PMl{-o-}{x_1}{x_2}{y}&=\frac{-i\lambda}2\int\cdots\\
  \PMl{-8-}{x_1}{y}{x_2}&=\frac{-i\lambda}6i\Delta(x_1,x_2)\int\cdots\\
  \PMl{8}{y}            &=\frac{-i\lambda}6\int\cdots\\
  \text{denominator}    &=1+\PM{8}+\PM{88}+\PM{ooo}+\cdots\\
  \text{numerator}      &=\PM{--}+\PM{-8-}+\PM{-88-}+\PM{-ooo-}+\cdots\\
                        &\quad+\PM{-o-}+\PM{-o8-}+\cdots
\end{align*}
\lipsum[2]
\end{document}

O código do pacote phinman.sty(pronuncia-se como Feynman):

\NeedsTeXFormat{LaTeX2e}
\ProvidesPackage{phinman}[2017/04/14 Diagrams for the free field theory]
\RequirePackage{tikz}
\newcommand\PMset{\pgfqkeys{/PM}}
\newcommand\PMldef[1]{\expandafter\def\csname PMl:#1\endcsname}
\newcommand\PMl[1]{\csname PMl:#1\endcsname}
\newcommand\PMdef[1]{\expandafter\def\csname PM:#1\endcsname}
\newcommand\PM[1]{\csname PM:#1\endcsname}
\newlength\PMu
\PMu=2ex

\PMset
  {dot/.style={circle,fill,draw,inner sep=0pt,outer sep=0pt,minimum size=2.5pt},
   line/.style={line width=0.6pt},
   ghostline/.style={line width=2pt,color=white}
  }

\newcommand\PMdot{node[/PM/dot]{}}
\newcommand\PMdotx[1]{node[/PM/dot,label={#1}]{}}
\newcommand\PMdota[1]{\PMdotx{[yshift=-0.5ex]above:{$#1$}}}
\newcommand\PMdotb[1]{\PMdotx{[yshift=0.5ex]below:{$#1$}}}
\newcommand\PMdotl[1]{\PMdotx{[xshift=0.5ex]left:{$#1$}}}
\newcommand\PMdotr[1]{\PMdotx{[xshift=-0.5ex]right:{$#1$}}}

\PMdef{-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot -- (2\PMu,0)\PMdot;%
  }

\PMldef{-}#1#2%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotb{#1} -- (2\PMu,0)\PMdotb{#2};%
  }

\PMdef{--}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot -- (4\PMu,0)\PMdot;%
  }

\PMldef{--}#1#2%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotb{#1} -- (4\PMu,0)\PMdotb{#2};%
  }

\PMdef{x}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot
   (\PMu,\PMu) -- (-\PMu,-\PMu)
   (\PMu,-\PMu) -- (-\PMu,\PMu);%
  }

\PMldef{x}#1%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotx{below:{$#1$}}
   (\PMu,\PMu) -- (-\PMu,-\PMu)
   (\PMu,-\PMu) -- (-\PMu,\PMu);%
  }

\PMdef{||}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,\PMu) \PMdot -- (0,-\PMu) \PMdot
   (2\PMu,\PMu) \PMdot -- (2\PMu,-\PMu)\PMdot;%
  }

\PMldef{||}#1#2#3#4%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,\PMu) \PMdotl{#3} -- (0,-\PMu) \PMdotl{#4}
   (2\PMu,\PMu) \PMdotr{#1} -- (2\PMu,-\PMu)\PMdotr{#2};%
  }

\PMdef{=}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,\PMu) \PMdot -- (2\PMu,\PMu) \PMdot
   (0,-\PMu) \PMdot -- (2\PMu,-\PMu)\PMdot;%
  }

\PMldef{=}#1#2#3#4%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,\PMu) \PMdotl{#3} -- (2\PMu,\PMu) \PMdotr{#1}
   (0,-\PMu) \PMdotl{#4} -- (2\PMu,-\PMu)\PMdotr{#2};%
  }

\PMdef{X}%
  {\tikz[baseline={(0,-0.5ex)}]%
    {\draw[/PM/line] (0,\PMu) \PMdot -- (2\PMu,-\PMu)\PMdot;
     \draw[/PM/ghostline] (0,-\PMu)-- (2\PMu,\PMu);
     \draw[/PM/line](0,-\PMu)\PMdot -- (2\PMu,\PMu) \PMdot;
    }%
  }

\PMldef{X}#1#2#3#4%
  {\tikz[baseline={(0,-0.5ex)}]%
    {\draw[/PM/line] (0,\PMu) \PMdotl{#3} -- (2\PMu,-\PMu)\PMdotr{#2};
     \draw[/PM/ghostline] (0,-\PMu)-- (2\PMu,\PMu);
     \draw[/PM/line](0,-\PMu)\PMdotl{#4}-- (2\PMu,\PMu) \PMdotr{#1};
    }%
  }

\PMdef{-o-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot -- ++(2\PMu,0)\PMdot
   arc(-90:270:0.6\PMu) -- ++(2\PMu,0)\PMdot;%
  }

\PMldef{-o-}#1#2#3%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotb{#1} -- ++(2\PMu,0)\PMdotb{#2}
   arc(-90:270:0.6\PMu) -- ++(2\PMu,0)\PMdotb{#3};%
  }

\PMdef{-8-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot -- ++(4\PMu,0)\PMdot
   (2\PMu,0.8\PMu)\PMdot arc (0:360:0.6\PMu)
   arc (180:540:0.6\PMu);%
  }

\PMldef{-8-}#1#2#3%
  {\tikz[baseline={(0,0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotb{#1} -- ++(4\PMu,0)\PMdotb{#3}
   (2\PMu,0.8\PMu)\PMdotx{above:{$#2$}} arc (0:360:0.6\PMu)
   arc (180:540:0.6\PMu);%
  }


\PMdef{-ooo-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot -- ++(4\PMu,0)\PMdot
   (1.3\PMu,0.8\PMu)\PMdot arc (0:360:0.6\PMu)
   arc (180:360:0.6\PMu) \PMdot
   arc (180:540:0.6\PMu) arc (0:180:0.6\PMu);%
  }

\PMldef{-ooo-}#1#2#3#4%
  {\tikz[baseline={(0,0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotb{#1} -- ++(4\PMu,0)\PMdotb{#4}
   (1.3\PMu,0.8\PMu)\PMdotx{above:{$#2$}} arc (0:360:0.6\PMu)
   arc (180:360:0.6\PMu) \PMdotx{above:{$#3$}}
   arc (180:540:0.6\PMu) arc (0:180:0.6\PMu);%
  }

\PMdef{8}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot arc (0:360:0.6\PMu)
   arc (180:540:0.6\PMu);%
  }

\PMldef{8}#1%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotx{below:{$#1$}} arc (0:360:0.6\PMu)
   arc (180:540:0.6\PMu);%
  }

\PMdef{88}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-0.7\PMu) \PMdot arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (0,0.7\PMu) \PMdot arc (0:360:0.6\PMu) arc (180:540:0.6\PMu);%
  }

\PMldef{88}#1#2%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-0.7\PMu) \PMdotx{below:{$#2$}} arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (0,0.7\PMu) \PMdotx{above:{$#1$}} arc (0:360:0.6\PMu) arc (180:540:0.6\PMu);%
  }

\PMdef{ooo}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdot arc (0:360:0.6\PMu)
   arc (180:360:0.6\PMu) \PMdot
   arc (180:540:0.6\PMu) arc (0:180:0.6\PMu);%
  }

\PMldef{ooo}#1#2%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,0) \PMdotx{below:{$#1$}} arc (0:360:0.6\PMu)
   arc (180:360:0.6\PMu) \PMdotx{below:{$#2$}}
   arc (180:540:0.6\PMu) arc (0:180:0.6\PMu);%
  }

\PMdef{-88-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-0.8\PMu) \PMdot arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (-2\PMu,0) \PMdot -- (2\PMu,0)\PMdot
   (0,0.8\PMu) \PMdot arc (0:360:0.6\PMu) arc (180:540:0.6\PMu);%
  }

\PMldef{-88-}#1#2#3#4%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-0.8\PMu) \PMdotx{below:{$#3$}} arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (-2\PMu,0) \PMdotb{#1} -- (2\PMu,0)\PMdotb{#4}
   (0,0.8\PMu) \PMdotx{above:{$#2$}} arc (0:360:0.6\PMu) arc (180:540:0.6\PMu);%
  }


\PMdef{-o8-}%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-0.8\PMu) \PMdot arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (-2\PMu,0) \PMdot -- (0,0) \PMdot
   arc (-90:270:0.6\PMu) -- (2\PMu,0)\PMdot;%
  }

\PMldef{-o8-}#1#2#3#4%
  {\tikz[baseline={(0,-0.5ex)}]\draw[/PM/line]
   (0,-1.5\PMu) \PMdotx{below:{$#3$}} arc (0:360:0.6\PMu) arc (180:540:0.6\PMu)
   (-2\PMu,0) \PMdotb{#1} -- (0,0) \PMdotb{#2}
   arc (-90:270:0.6\PMu) -- (2\PMu,0)\PMdotb{#4};%
  }


\endinput

Responder2

Você pode desenhá-lo com Tikz. Abaixo, criei alguns comandos para os símbolos do seu desenho (provavelmente você encontrará nomes melhores para eles). Tive que ajustar a altura 2ptmanualmente para alinhar as linhas com as +placas. Os lipsums são apenas para ver o espaçamento vertical. Você pode ajustar o comprimento das linhas e o tamanho dos círculos.

\documentclass{article}
\usepackage{amsmath}
\usepackage{lipsum}
\usepackage{tikz}
\usetikzlibrary{calc,arrows}
\newcommand\SajadLineLength{15mm}
\newcommand\SajadCircleRadii{3mm}
\newcommand\SajadLine[2]{\tikz[baseline=-2pt]{%
    \draw[*-*](0,0) -- (\SajadLineLength,0)node[pos=0,below]{$#1$}node[pos=1,below]{$#2$};
  }}
\newcommand\SajadLineCircleMid[2]{\tikz[baseline=-2pt]{%
    \draw[*-*](0,0) -- (\SajadLineLength,0)node[pos=0,below]{$#1$}node[pos=1,below]{$#2$};
    \draw (0.5*\SajadLineLength,0) circle (\SajadCircleRadii);
  }}
\newcommand\SajadLineCircle[2]{\tikz[baseline=-2pt]{%
    \draw[*-*](0,0) -- (\SajadLineLength,0)node[pos=0,below]{$#1$}node[pos=1,below]{$#2$};
    \draw (0.5*\SajadLineLength,\SajadCircleRadii) circle (\SajadCircleRadii);
  }}
\newcommand\SajadLineDoubleCircle[2]{\tikz[baseline=-2pt]{%
    \draw[*-*](0,0) -- (\SajadLineLength,0)node[pos=0,below]{$#1$}node[pos=1,below]{$#2$};
    \draw (0.5*\SajadLineLength,\SajadCircleRadii) circle (\SajadCircleRadii);
    \draw (0.5*\SajadLineLength,3*\SajadCircleRadii) circle (\SajadCircleRadii);
  }}

\begin{document}
\lipsum[1]
\begin{displaymath}
  A=
  \SajadLine{x_1}{x_2}
  +\SajadLineCircle{x_1}{x_2}
  +\SajadLineCircleMid{x_1}{x_2}
  +\SajadLineDoubleCircle{x_1}{x_2}
\end{displaymath}
\lipsum[2]
\end{document}

insira a descrição da imagem aqui
