Combinações de correntes

Question

Acabei de começar a usar a biblioteca chain. Quero mostrar 3 níveis de compreensão com cada cadeia

cadeia 1. Cadeia de campos iniciais 2. Cadeia de explicação 3. Imagens

Em algum momento do meu documento, quero exibir chain 1apenas então chain 1 & 2, então chain 1 & 3e finalmente apenas chain 3.

Eu precisava alinhar a cadeia e o uso de right ofnão me permite usar ifdeclarações. Então, preciso apenas de uma ajudinha para usar condicionalmente o mesmo código para ter uma combinação das cadeias.

Aqui está MWE

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}

\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going right,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        },
    every node/.append style = {
        on chain},
    ]

{[start chain=1]
   \node[Champs,]                       (Level1) {Field 1};
   \node[Champs,below=0.1cm of Level1]  (Level2) {Field 2};
   \node[Champs,below=0.1cm of Level2]  (Level3) {Field 3};
   \node[Champs,below=0.1cm of Level3,fill=\Couleur!50]     (Level4) {Field 4};
   \node[Champs,below=0.1cm of Level4]  (Level5) {Field 5};
   \node[Champs,below=0.1cm of Level5]  (Level6) {Field 6};
}

{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc,below=0.1cm of Desc1]     (Desc2) {Description a bit longer 2};
   \node[desc,below=0.1cm of Desc2]     (Desc3) {Description a bit longer 3};
   \node[desc,below=0.1cm of Desc3,fill=\Couleur!10]    (Desc4) {Description a bit longer 4};
   \node[desc,below=0.1cm of Desc4]     (Desc5) {Description a bit longer 4};
   \node[desc,below=0.1cm of Desc5]     (Desc6) {Description a bit longer 6};
}
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb1]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb,below=0.1cm of Symb2]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb3,fill=\Couleur!50] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb4]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb,below=0.1cm of Symb5]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}

\end{tikzpicture}

\end{document}

Answer 1

Acho que você não está usando correntes corretamente. Você não precisa mais adicionar todos os below=0.1cm of ...se usar uma cadeia que seja going below. Eu adicionei alguns ifs.

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}
\newif\ifChainTwo
\newif\ifChainThree
\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going below,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        },
    every node/.append style = {
        on chain},
    ]
%\ChainTwotrue
%\ChainThreetrue
{[start chain=1]
   \node[Champs,alias=Desc1]                       (Level1) {Field 1};
   \node[Champs]  (Level2) {Field 2};
   \node[Champs]  (Level3) {Field 3};
   \node[Champs,fill=\Couleur!50]     (Level4) {Field 4};
   \node[Champs]  (Level5) {Field 5};
   \node[Champs]  (Level6) {Field 6};
}
\ifChainTwo
{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc]     (Desc2) {Description a bit longer 2};
   \node[desc]     (Desc3) {Description a bit longer 3};
   \node[desc,fill=\Couleur!10]    (Desc4) {Description a bit longer 4};
   \node[desc]     (Desc5) {Description a bit longer 4};
   \node[desc]     (Desc6) {Description a bit longer 6};
}
\fi
\ifChainThree
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb,fill=\Couleur!50] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}
\fi
\end{tikzpicture}

\end{document}

Se você descomentar \ChainTwotruevocê obtém

Se você descomentar \ChainThreetruevocê obtém

E se você descomentar ambos, você obtém

Observe que também é possível tornar a coloração laranja um pouco mais automática.

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\def\Couleur{orange}
\newif\ifChainTwo
\newif\ifChainThree
\begin{document}


\begin{tikzpicture}[
        start chain=1 going below,
        start chain=2 going below,
        start chain=3 going below,
        node distance=2mm,
    Champs/.style={
        on chain=1,
        rectangle,
        rounded corners,
        draw=blue!30,
        very thick,
        text centered,
        text width=3cm,
        minimum height=12mm,
        fill=blue!20,
        cond={4}{fill=\Couleur!50}
        },
    desc/.style={
        on chain=2,
        rectangle,
        draw=blue!10,
        very thick,
        text centered,
        text width=6cm,
        minimum height=12mm,
        fill=blue!5,
        cond={4}{fill=\Couleur!10}
        },
    symb/.style={Champs,
        on chain=3,
        text width=2.3cm,
        cond={4}{fill=\Couleur!50}
        },
    every node/.append style = {
        on chain},
    cond/.code 2 args={\ifnum\tikzchaincount=#1
     \tikzset{#2}
    \fi}
    ]
\ChainTwotrue
\ChainThreetrue
{[start chain=1,nodes=Champs]
   \node[Champs,alias=Desc1]                       (Level1) {Field 1};
   \node[Champs]  (Level2) {Field 2};
   \node[Champs]  (Level3) {Field 3};
   \node[Champs]  (Level4) {Field 4};
   \node[Champs]  (Level5) {Field 5};
   \node[Champs]  (Level6) {Field 6};
}
\ifChainTwo
{[start chain=2]
   \node[desc,right=of Level1]      (Desc1) {Description a bit longer 1};
   \node[desc]     (Desc2) {Description a bit longer 2};
   \node[desc]     (Desc3) {Description a bit longer 3};
   \node[desc]    (Desc4) {Description a bit longer 4};
   \node[desc]     (Desc5) {Description a bit longer 4};
   \node[desc]     (Desc6) {Description a bit longer 6};
}
\fi
\ifChainThree
{
[start chain=3]
   \node[symb,right=of Desc1]           (Symb1) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb2) {\includegraphics[width=1cm]{example-image}};
   \node[symb]     (Symb3) {\includegraphics[width=1cm]{example-image} };
   \node[symb] (Symb4) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb5) {\includegraphics[width=1cm]{example-image} };
   \node[symb]     (Symb6) {\includegraphics[width=1cm]{example-image} };
}
\fi
\end{tikzpicture}

\end{document}
