Gostaria de desenhar isso para um de meus relatórios. Mas não sei como.
Responder1
Doo a você o anel carregado uniformemente usando Mathcha indicado anteriormente em meu comentário.
\documentclass[a4paper,12pt]{article}
\usepackage{newtxtext,newtxmath}
\usepackage{tikz}
\begin{document}
\begin{figure}[h]
\centering
\tikzset{every picture/.style={line width=0.75pt}} %set default line width to 0.75pt
\begin{tikzpicture}[x=0.75pt,y=0.75pt,yscale=-1,xscale=1]
%uncomment if require: \path (0,444); %set diagram left start at 0, and has height of 444
%Shape: Arc [id:dp796341774674139]
\draw [draw opacity=0] (262.37,163.17) .. controls (263.64,157.97) and (266.21,153.41) .. (269.66,149.76) -- (291.5,170.33) -- cycle ; \draw (262.37,163.17) .. controls (263.64,157.97) and (266.21,153.41) .. (269.66,149.76) ;
%Shape: Arc [id:dp46939057871839585]
\draw [draw opacity=0] (356.12,162.23) .. controls (355.71,167.57) and (353.93,172.5) .. (351.13,176.67) -- (326.2,159.96) -- cycle ; \draw (356.12,162.23) .. controls (355.71,167.57) and (353.93,172.5) .. (351.13,176.67) ;
%Straight Lines [id:da14186153692575143]
\draw [color={rgb, 255:red, 245; green, 166; blue, 35 } ,draw opacity=1 ][line width=2.25] (308.75,164) -- (388.71,187.9) ;
\draw [shift={(393.5,189.33)}, rotate = 196.64] [fill={rgb, 255:red, 245; green, 166; blue, 35 } ,fill opacity=1 ][line width=0.08] [draw opacity=0] (14.29,-6.86) -- (0,0) -- (14.29,6.86) -- cycle ;
%Straight Lines [id:da24228394907316253]
\draw [color={rgb, 255:red, 245; green, 166; blue, 35 } ,draw opacity=1 ][line width=2.25] (308.75,164) -- (392.64,143.52) ;
\draw [shift={(397.5,142.33)}, rotate = 526.28] [fill={rgb, 255:red, 245; green, 166; blue, 35 } ,fill opacity=1 ][line width=0.08] [draw opacity=0] (14.29,-6.86) -- (0,0) -- (14.29,6.86) -- cycle ;
%Shape: Donut [id:dp6846402688267834]
\draw (81.5,164) .. controls (81.5,108.77) and (98.18,64) .. (118.75,64) .. controls (139.32,64) and (156,108.77) .. (156,164) .. controls (156,219.23) and (139.32,264) .. (118.75,264) .. controls (98.18,264) and (81.5,219.23) .. (81.5,164)(72.5,164) .. controls (72.5,103.8) and (93.21,55) .. (118.75,55) .. controls (144.29,55) and (165,103.8) .. (165,164) .. controls (165,224.2) and (144.29,273) .. (118.75,273) .. controls (93.21,273) and (72.5,224.2) .. (72.5,164) ;
%Shape: Axis 2D [id:dp8209371942963568]
\draw (78.57,164) -- (480.33,164)(118.75,24.5) -- (118.75,179.5) (473.33,159) -- (480.33,164) -- (473.33,169) (113.75,31.5) -- (118.75,24.5) -- (123.75,31.5) ;
%Straight Lines [id:da9986252650298479]
\draw (118.75,164) -- (38.75,264.44) ;
\draw [shift={(37.5,266)}, rotate = 308.53999999999996] [color={rgb, 255:red, 0; green, 0; blue, 0 } ][line width=0.75] (10.93,-4.9) .. controls (6.95,-2.3) and (3.31,-0.67) .. (0,0) .. controls (3.31,0.67) and (6.95,2.3) .. (10.93,4.9) ;
%Rounded Rect [id:dp709019453920531]
\draw [fill={rgb, 255:red, 245; green, 166; blue, 35 } ,fill opacity=1 ] (76.58,209.59) .. controls (76.51,209.37) and (76.64,209.14) .. (76.86,209.07) -- (84.31,206.94) .. controls (84.54,206.88) and (84.77,207) .. (84.83,207.23) -- (92.27,233.18) .. controls (92.33,233.41) and (92.2,233.64) .. (91.98,233.7) -- (84.53,235.84) .. controls (84.31,235.9) and (84.08,235.77) .. (84.01,235.55) -- cycle ;
%Rounded Rect [id:dp44607882852530323]
\draw [fill={rgb, 255:red, 245; green, 166; blue, 35 } ,fill opacity=1 ] (147.31,97.84) .. controls (147.25,97.63) and (147.39,97.41) .. (147.6,97.36) -- (154.77,95.6) .. controls (154.98,95.55) and (155.2,95.68) .. (155.25,95.9) -- (161.69,122.16) .. controls (161.75,122.37) and (161.61,122.59) .. (161.4,122.64) -- (154.23,124.4) .. controls (154.02,124.45) and (153.8,124.32) .. (153.75,124.1) -- cycle ;
%Straight Lines [id:da8011775407671766]
\draw [color={rgb, 255:red, 74; green, 74; blue, 74 } ,draw opacity=1 ][line width=1.5] (118.75,164) -- (85.96,218.81) ;
\draw [shift={(84.42,221.39)}, rotate = 300.89] [color={rgb, 255:red, 74; green, 74; blue, 74 } ,draw opacity=1 ][line width=1.5] (14.21,-4.28) .. controls (9.04,-1.82) and (4.3,-0.39) .. (0,0) .. controls (4.3,0.39) and (9.04,1.82) .. (14.21,4.28) ;
%Straight Lines [id:da30073330719810465]
\draw [color={rgb, 255:red, 74; green, 74; blue, 74 } ,draw opacity=1 ][line width=1.5] (118.75,164) -- (149.94,112.57) ;
\draw [shift={(151.5,110)}, rotate = 481.24] [color={rgb, 255:red, 74; green, 74; blue, 74 } ,draw opacity=1 ][line width=1.5] (14.21,-4.28) .. controls (9.04,-1.82) and (4.3,-0.39) .. (0,0) .. controls (4.3,0.39) and (9.04,1.82) .. (14.21,4.28) ;
%Shape: Circle [id:dp5131849801327677]
\draw [fill={rgb, 255:red, 0; green, 0; blue, 0 } ,fill opacity=1 ] (114.25,164) .. controls (114.25,161.51) and (116.26,159.5) .. (118.75,159.5) .. controls (121.24,159.5) and (123.25,161.51) .. (123.25,164) .. controls (123.25,166.49) and (121.24,168.5) .. (118.75,168.5) .. controls (116.26,168.5) and (114.25,166.49) .. (114.25,164) -- cycle ;
%Straight Lines [id:da23183967668813366]
\draw [dash pattern={on 4.5pt off 4.5pt}] (154.5,110) -- (308.75,164) ;
%Straight Lines [id:da8296397184934552]
\draw (90.5,100.33) -- (118.75,164) ;
%Straight Lines [id:da3042917546526054]
\draw (234.5,179.33) -- (306.5,179.33) ;
\draw [shift={(309.5,179.33)}, rotate = 180] [fill={rgb, 255:red, 0; green, 0; blue, 0 } ][line width=0.08] [draw opacity=0] (10.72,-5.15) -- (0,0) -- (10.72,5.15) -- (7.12,0) -- cycle ;
%Straight Lines [id:da8852247752349167]
\draw (122.5,179.33) -- (215.5,179.33) ;
\draw [shift={(119.5,179.33)}, rotate = 0] [fill={rgb, 255:red, 0; green, 0; blue, 0 } ][line width=0.08] [draw opacity=0] (10.72,-5.15) -- (0,0) -- (10.72,5.15) -- (7.12,0) -- cycle ;
%Straight Lines [id:da42460233641055156]
\draw [dash pattern={on 4.5pt off 4.5pt}] (84.42,221.39) -- (308.75,164) ;
%Straight Lines [id:da9037440476041276]
\draw [color={rgb, 255:red, 126; green, 211; blue, 33 } ,draw opacity=1 ][line width=2.25] (308.75,164) -- (418.5,163.36) ;
\draw [shift={(423.5,163.33)}, rotate = 539.6700000000001] [fill={rgb, 255:red, 126; green, 211; blue, 33 } ,fill opacity=1 ][line width=0.08] [draw opacity=0] (14.29,-6.86) -- (0,0) -- (14.29,6.86) -- cycle ;
%Shape: Circle [id:dp8200585017632998]
\draw [fill={rgb, 255:red, 0; green, 0; blue, 0 } ,fill opacity=1 ] (304.25,164) .. controls (304.25,161.51) and (306.26,159.5) .. (308.75,159.5) .. controls (311.24,159.5) and (313.25,161.51) .. (313.25,164) .. controls (313.25,166.49) and (311.24,168.5) .. (308.75,168.5) .. controls (306.26,168.5) and (304.25,166.49) .. (304.25,164) -- cycle ;
% Text Node
\draw (229,122) node [anchor=north west][inner sep=0.75pt] {$r$};
% Text Node
\draw (99,101.73) node [anchor=north west][inner sep=0.75pt] {$R$};
% Text Node
\draw (164,91.73) node [anchor=north west][inner sep=0.75pt] {$dq_{2}$};
% Text Node
\draw (97,215.73) node [anchor=north west][inner sep=0.75pt] {$dq_{1}$};
% Text Node
\draw (219,174) node [anchor=north west][inner sep=0.75pt] {$x$};
% Text Node
\draw (454,169.73) node [anchor=north west][inner sep=0.75pt] {$x$};
% Text Node
\draw (126,19.73) node [anchor=north west][inner sep=0.75pt] {$y$};
% Text Node
\draw (40,232.73) node [anchor=north west][inner sep=0.75pt] {$z$};
% Text Node
\draw (281,134.73) node [anchor=north west][inner sep=0.75pt] {$P( x,0,0)$};
% Text Node
\draw (243,145.73) node [anchor=north west][inner sep=0.75pt] {$\theta$};
% Text Node
\draw (362.13,164.07) node [anchor=north west][inner sep=0.75pt] {$\theta$};
% Text Node
\draw (343,187.73) node [anchor=north west][inner sep=0.75pt] {$d\vec{\mathbf E}_{2}$};
% Text Node
\draw (365,115.73) node [anchor=north west][inner sep=0.75pt] {$d\vec{\mathbf E}_{1}$};
% Text Node
\draw (417,140.73) node [anchor=north west][inner sep=0.75pt] {$d\vec{\mathbf E}_{x}$};
\end{tikzpicture}
\caption{Ring uniformly charged.}
\end{figure}
\end{document}
