У меня проблемы с отображением фавикона Gitlab в моем moderncv
проекте. Я думаю, это связано с моей установкой moderncv
.
Я работаю на компьютере с Ubuntu и первым делом установил texlive-latex-extra
.
После некоторого гугления я обнаружил, что moderncv
версия в TeX Live устарела. Поэтому я клонировал moderncv
репозиторий git и поместил его в /home/{user}/texmf/tex/latex/moderncv
.
$ kpsewhich -var-value=TEXMFHOME
/home/{user}/texmf
Поэтому я бы подумал, что более новая версия moderncv
в моей домашней папке имеет приоритет. Но, видимо, это не так.
Когда я пытаюсь скомпилировать пример шаблона изmoderncv
%% start of file `template.tex'.
%% Copyright 2006-2015 Xavier Danaux ([email protected]).
%
% This work may be distributed and/or modified under the
% conditions of the LaTeX Project Public License version 1.3c,
% available at http://www.latex-project.org/lppl/.
\documentclass[11pt,a4paper,sans]{moderncv} % possible options include font size ('10pt', '11pt' and '12pt'), paper size ('a4paper', 'letterpaper', 'a5paper', 'legalpaper', 'executivepaper' and 'landscape') and font family ('sans' and 'roman')
% moderncv themes
\moderncvstyle{casual} % style options are 'casual' (default), 'classic', 'banking', 'oldstyle' and 'fancy'
\moderncvcolor{blue} % color options 'black', 'blue' (default), 'burgundy', 'green', 'grey', 'orange', 'purple' and 'red'
%\renewcommand{\familydefault}{\sfdefault} % to set the default font; use '\sfdefault' for the default sans serif font, '\rmdefault' for the default roman one, or any tex font name
%\nopagenumbers{} % uncomment to suppress automatic page numbering for CVs longer than one page
% character encoding
%\usepackage[utf8]{inputenc} % if you are not using xelatex ou lualatex, replace by the encoding you are using
%\usepackage{CJKutf8} % if you need to use CJK to typeset your resume in Chinese, Japanese or Korean
% adjust the page margins
\usepackage[scale=0.75]{geometry}
%\setlength{\hintscolumnwidth}{3cm} % if you want to change the width of the column with the dates
%\setlength{\makecvheadnamewidth}{10cm} % for the 'classic' style, if you want to force the width allocated to your name and avoid line breaks. be careful though, the length is normally calculated to avoid any overlap with your personal info; use this at your own typographical risks...
% personal data
\name{John}{Doe}
\title{Resumé title} % optional, remove / comment the line if not wanted
\address{street and number}{postcode city}{country}% optional, remove / comment the line if not wanted; the "postcode city" and "country" arguments can be omitted or provided empty
\phone[mobile]{+1~(234)~567~890} % optional, remove / comment the line if not wanted; the optional "type" of the phone can be "mobile" (default), "fixed" or "fax"
\phone[fixed]{+2~(345)~678~901}
\phone[fax]{+3~(456)~789~012}
\email{[email protected]} % optional, remove / comment the line if not wanted
\homepage{www.johndoe.com} % optional, remove / comment the line if not wanted
\social[linkedin]{john.doe} % optional, remove / comment the line if not wanted
\social[xing]{john\_doe} % optional, remove / comment the line if not wanted
\social[twitter]{jdoe} % optional, remove / comment the line if not wanted
\social[github]{jdoe} % optional, remove / comment the line if not wanted
\social[gitlab]{jdoe} % optional, remove / comment the line if not wanted
\social[skype]{jdoe} % optional, remove / comment the line if not wanted
\extrainfo{additional information} % optional, remove / comment the line if not wanted
\photo[64pt][0.4pt]{picture} % optional, remove / comment the line if not wanted; '64pt' is the height the picture must be resized to, 0.4pt is the thickness of the frame around it (put it to 0pt for no frame) and 'picture' is the name of the picture file
\quote{Some quote} % optional, remove / comment the line if not wanted
% bibliography adjustements (only useful if you make citations in your resume, or print a list of publications using BibTeX)
% to show numerical labels in the bibliography (default is to show no labels)
%\makeatletter\renewcommand*{\bibliographyitemlabel}{\@biblabel{\arabic{enumiv}}}\makeatother
\renewcommand*{\bibliographyitemlabel}{[\arabic{enumiv}]}
% to redefine the bibliography heading string ("Publications")
%\renewcommand{\refname}{Articles}
% bibliography with mutiple entries
%\usepackage{multibib}
%\newcites{book,misc}{{Books},{Others}}
%----------------------------------------------------------------------------------
% content
%----------------------------------------------------------------------------------
\begin{document}
%\begin{CJK*}{UTF8}{gbsn} % to typeset your resume in Chinese using CJK
%----- resume ---------------------------------------------------------
\makecvtitle
\section{Education}
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description} % arguments 3 to 6 can be left empty
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description}
\section{Master thesis}
\cvitem{title}{\emph{Title}}
\cvitem{supervisors}{Supervisors}
\cvitem{description}{Short thesis abstract}
\section{Experience}
\subsection{Vocational}
\cventry{year--year}{Job title}{Employer}{City}{}{General description no longer than 1--2 lines.\newline{}%
Detailed achievements:%
\begin{itemize}%
\item Achievement 1;
\item Achievement 2, with sub-achievements:
\begin{itemize}%
\item Sub-achievement (a);
\item Sub-achievement (b), with sub-sub-achievements (don't do this!);
\begin{itemize}
\item Sub-sub-achievement i;
\item Sub-sub-achievement ii;
\item Sub-sub-achievement iii;
\end{itemize}
\item Sub-achievement (c);
\end{itemize}
\item Achievement 3.
\end{itemize}}
\cventry{year--year}{Job title}{Employer}{City}{}{Description line 1\newline{}Description line 2}
\subsection{Miscellaneous}
\cventry{year--year}{Job title}{Employer}{City}{}{Description}
\section{Languages}
\cvitemwithcomment{Language 1}{Skill level}{Comment}
\cvitemwithcomment{Language 2}{Skill level}{Comment}
\cvitemwithcomment{Language 3}{Skill level}{Comment}
\section{Computer skills}
\cvdoubleitem{category 1}{XXX, YYY, ZZZ}{category 4}{XXX, YYY, ZZZ}
\cvdoubleitem{category 2}{XXX, YYY, ZZZ}{category 5}{XXX, YYY, ZZZ}
\cvdoubleitem{category 3}{XXX, YYY, ZZZ}{category 6}{XXX, YYY, ZZZ}
\section{Interests}
\cvitem{hobby 1}{Description}
\cvitem{hobby 2}{Description}
\cvitem{hobby 3}{Description}
\section{Extra 1}
\cvlistitem{Item 1}
\cvlistitem{Item 2}
\cvlistitem{Item 3. This item is particularly long and therefore normally spans over several lines. Did you notice the indentation when the line wraps?}
\section{Extra 2}
\cvlistdoubleitem{Item 1}{Item 4}
\cvlistdoubleitem{Item 2}{Item 5\cite{book1}}
\cvlistdoubleitem{Item 3}{Item 6. Like item 3 in the single column list before, this item is particularly long to wrap over several lines.}
\section{References}
\begin{cvcolumns}
\cvcolumn{Category 1}{\begin{itemize}\item Person 1\item Person 2\item Person 3\end{itemize}}
\cvcolumn{Category 2}{Amongst others:\begin{itemize}\item Person 1, and\item Person 2\end{itemize}(more upon request)}
\cvcolumn[0.5]{All the rest \& some more}{\textit{That} person, and \textbf{those} also (all available upon request).}
\end{cvcolumns}
% Publications from a BibTeX file without multibib
% for numerical labels: \renewcommand{\bibliographyitemlabel}{\@biblabel{\arabic{enumiv}}}% CONSIDER MERGING WITH PREAMBLE PART
% to redefine the heading string ("Publications"): \renewcommand{\refname}{Articles}
\nocite{*}
\bibliographystyle{plain}
\bibliography{publications} % 'publications' is the name of a BibTeX file
% Publications from a BibTeX file using the multibib package
%\section{Publications}
%\nocitebook{book1,book2}
%\bibliographystylebook{plain}
%\bibliographybook{publications} % 'publications' is the name of a BibTeX file
%\nocitemisc{misc1,misc2,misc3}
%\bibliographystylemisc{plain}
%\bibliographymisc{publications} % 'publications' is the name of a BibTeX file
\clearpage
%----- letter ---------------------------------------------------------
% recipient data
\recipient{Company Recruitment team}{Company, Inc.\\123 somestreet\\some city}
\date{January 01, 1984}
\opening{Dear Sir or Madam,}
\closing{Yours faithfully,}
\enclosure[Attached]{curriculum vit\ae{}} % use an optional argument to use a string other than "Enclosure", or redefine \enclname
\makelettertitle
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Duis ullamcorper neque sit amet lectus facilisis sed luctus nisl iaculis. Vivamus at neque arcu, sed tempor quam. Curabitur pharetra tincidunt tincidunt. Morbi volutpat feugiat mauris, quis tempor neque vehicula volutpat. Duis tristique justo vel massa fermentum accumsan. Mauris ante elit, feugiat vestibulum tempor eget, eleifend ac ipsum. Donec scelerisque lobortis ipsum eu vestibulum. Pellentesque vel massa at felis accumsan rhoncus.
Suspendisse commodo, massa eu congue tincidunt, elit mauris pellentesque orci, cursus tempor odio nisl euismod augue. Aliquam adipiscing nibh ut odio sodales et pulvinar tortor laoreet. Mauris a accumsan ligula. Class aptent taciti sociosqu ad litora torquent per conubia nostra, per inceptos himenaeos. Suspendisse vulputate sem vehicula ipsum varius nec tempus dui dapibus. Phasellus et est urna, ut auctor erat. Sed tincidunt odio id odio aliquam mattis. Donec sapien nulla, feugiat eget adipiscing sit amet, lacinia ut dolor. Phasellus tincidunt, leo a fringilla consectetur, felis diam aliquam urna, vitae aliquet lectus orci nec velit. Vivamus dapibus varius blandit.
Duis sit amet magna ante, at sodales diam. Aenean consectetur porta risus et sagittis. Ut interdum, enim varius pellentesque tincidunt, magna libero sodales tortor, ut fermentum nunc metus a ante. Vivamus odio leo, tincidunt eu luctus ut, sollicitudin sit amet metus. Nunc sed orci lectus. Ut sodales magna sed velit volutpat sit amet pulvinar diam venenatis.
Albert Einstein discovered that $e=mc^2$ in 1905.
\[ e=\lim_{n \to \infty} \left(1+\frac{1}{n}\right)^n \]
\makeletterclosing
%\clearpage\end{CJK*} % if you are typesetting your resume in Chinese using CJK; the \clearpage is required for fancyhdr to work correctly with CJK, though it kills the page numbering by making \lastpage undefined
\end{document}
%% end of file `template.tex'.
Я получаю следующую ошибку:
Undefined control sequence.
\gitlabsocialsymbol ->{\small \faGitlab
Если это имеет значение, я использую VS Code с плагином LaTeX Workshop. Я думаю, что компилятор, который он использует, это latexmk
.
Если я вытащу линию, social[gitlab]{jdoe}
все будет работать нормально.
Буду очень признателен, если кто-нибудь поможет мне разобраться с этими проблемами. Буду рад предоставить любую дополнительную информацию, которая понадобится.
решение1
Вы не сообщили нам, какие версии вы modencv
используете fontawesome
.
Наконец-то ubuntu (и debian) установили устаревшую версию TeX Live. Лучше использовать оригинальный TeX Live, который можно установить следующим образом этот вопрос.
Если вы хотите попробовать установку только fontawesome
в Ubuntu, используйте команду:
sudo apt-get install texlive-fonts-extra
Убедитесь, что FNDB обновлен и все карты шрифтов загружены (я не использую Ubuntu, я не знаю, как это делается в этой ОС).
После установки TeX Live new вы потеряли обновленный вручную moderncv
. Поэтому лучше внести необходимые изменения moderncv
в преамбулу вашего резюме.
Пожалуйста, ознакомьтесь со следующим кодом (я пометил все важные изменения кода значком <=========
; Пожалуйста, обратите внимание, что я изменил http
ссылки на используемые сегодня и более безопасные версии https
):
\documentclass[11pt,a4paper,sans]{moderncv}
% moderncv themes
\moderncvstyle{casual} % casual, classic, banking, oldstyle and fancy
\moderncvcolor{blue}
\usepackage[utf8]{inputenc}
\usepackage[scale=0.75]{geometry}
% makes a https hyperlink
% usage: \httpslink[optional text]{link}
\newcommand*{\httpslink}[2][]{% <=======================================
\ifthenelse{\equal{#1}{}}%
{\href{https://#2}{#2}}%
{\href{https://#2}{#1}}}
\newcommand*{\xingsocialsymbol} {{\small\faXing}~} % <===============
\newcommand*{\gitlabsocialsymbol} {{\small\faGitlab}~} % <=============
\newcommand*{\skypesocialsymbol} {{\small\faSkype}~} % <==============
\makeatletter % <=======================================================
\RenewDocumentCommand{\social}{O{}O{}m}{%
\ifthenelse{\equal{#2}{}}%
{%
\ifthenelse{\equal{#1}{linkedin}}{\collectionadd[linkedin]{socials}{\protect\httpslink[#3]{www.linkedin.com/in/#3}}} {}%
\ifthenelse{\equal{#1}{xing}} {\collectionadd[xing]{socials} {\protect\httpslink[#3]{www.xing.com/profile/#3}}}{}%
\ifthenelse{\equal{#1}{twitter}} {\collectionadd[twitter]{socials} {\protect\httpslink[#3]{www.twitter.com/#3}}} {}%
\ifthenelse{\equal{#1}{github}} {\collectionadd[github]{socials} {\protect\httpslink[#3]{www.github.com/#3}}} {}%
\ifthenelse{\equal{#1}{gitlab}} {\collectionadd[gitlab]{socials} {\protect\httpslink[#3]{www.gitlab.com/#3}}} {}%
\ifthenelse{\equal{#1}{skype}} {\collectionadd[skype]{socials} {#3}} {}%
}
{\collectionadd[#1]{socials}{\protect\httpslink[#3]{#2}}}}
\makeatother % <========================================================
% personal data
\name{John}{Doe}
\title{Resumé title}
\address{street and number}{postcode city}{country}
\phone[mobile]{+1~(234)~567~890}
\phone[fixed]{+2~(345)~678~901}
\phone[fax]{+3~(456)~789~012}
\email{[email protected]}
\homepage{www.johndoe.com}
\social[linkedin]{john.doe}
\social[xing]{john\_doe} % <============================================
\social[twitter]{jdoe}
\social[github]{jdoe}
\social[gitlab]{jdoe}
\social[skype]{jdoe} % <================================================
\extrainfo{additional information}
\quote{Some quote}
\setlength{\footskip}{66pt}
\begin{document}
\makecvtitle
\section{Education}
\cventry{year--year}{Degree}{Institution--3}{City--4}{\textit{Grade}--5}{Description--6} % arguments 3 to 6 can be left empty
\cventry{year--year}{Degree}{Institution}{City}{\textit{Grade}}{Description}
\section{Master thesis}
\cvitem{title}{\emph{Title}}
\cvitem{supervisors}{Supervisors}
\cvitem{description}{Short thesis abstract}
\section{Experience}
\subsection{Vocational}
\cventry{year--year}{Job title}{Employer}{City}{}{General description
no longer than 1--2 lines.\newline{}%
Detailed achievements:%
\begin{itemize}%
\item Achievement 1;
\item Achievement 2, with sub-achievements:
\begin{itemize}%
\item Sub-achievement (a);
\item Sub-achievement (b), with sub-sub-achievements (don't do this!);
\begin{itemize}
\item Sub-sub-achievement i;
\item Sub-sub-achievement ii;
\item Sub-sub-achievement iii;
\end{itemize}
\item Sub-achievement (c);
\end{itemize}
\item Achievement 3.
\end{itemize}}
\cventry{year--year}{Job title}{Employer}{City}{}{Description
line 1\newline{}Description line 2}
\subsection{Miscellaneous}
\cventry{year--year}{Job title}{Employer}{City}{}{Description}
\section{Languages}
\cvitemwithcomment{Language 1}{Skill level}{Comment}
\cvitemwithcomment{\textbf{Language} 2}{\textbf{Skill} level}{Comment}
\cvitemwithcomment{Language 3}{Skill level}{Comment}
\section{Computer skills}
\cvdoubleitem{category 1}{XXX, YYY, ZZZ}{category 4}{XXX, YYY, ZZZ}
\cvdoubleitem{category 2}{XXX, YYY, ZZZ}{category 5}{XXX, YYY, ZZZ}
\cvdoubleitem{category 3}{XXX, YYY, ZZZ}{category 6}{XXX, YYY, ZZZ}
\section{Interests}
\cvitem{hobby 1}{Description}
\cvitem{hobby 2}{Description}
\cvitem{hobby 3}{Description}
\section{Extra 1}
\cvlistitem{Item 1}
\cvlistitem{Item 2}
\cvlistitem{Item 3. This item is particularly long and therefore
normally spans over several lines. Did you notice the indentation
when the line wraps?}
\section{Extra 2}
\cvlistdoubleitem{Item 1}{Item 4}
\cvlistdoubleitem{Item 2}{Item 5}
\cvlistdoubleitem{Item 3}{Item 6. Like item 3 in the single column list before, this item is particularly long to wrap over several lines.}
\section{References}
\begin{cvcolumns}
\cvcolumn{Category 1}{\begin{itemize}\item Person 1\item Person 2\item Person 3\end{itemize}}
\cvcolumn{Category 2}{Amongst others:\begin{itemize}\item Person 1, and\item Person 2\end{itemize}(more upon request)}
\cvcolumn[0.5]{All the rest \& some more}{\textit{That} person, and \textbf{those} also (all available upon request).}
\end{cvcolumns}
\end{document}
и его результат:
Это скомпилировано с текущим классом moderncv
2.0.0 (тот, что из ctan, а не из github!), текущим fontawesome fontawesome.sty 2016/05/15 v4.6.3.1 font awesome icons
и текущим MiKTeX pdfTeX, Version 3.14159265-2.6-1.40.20 (MiKTeX 2.9.6960 64-bit)
.
