在 Dell Latitude E6410 上設定 Trackpoint 的軟體包?

在 Dell Latitude E6410 上設定 Trackpoint 的軟體包?

我有一台運行最新 Ubuntu 15.04 的 Dell Latitude E6410(請參閱本問題末尾的詳細資訊)。我想我的 TrackPoint 也有同樣的問題,如下所述:

戴爾 vs 聯想指點桿/指點桿/指點桿滑鼠驅動程式?

對這個問題的評論是: 戴爾 vs 聯想指點桿/指點桿/指點桿滑鼠驅動程式?

這表明

Dell Latitude 上的 Glidepoint 觸控板/軌跡點設置

但是通讀該連結讓我對如何從 Ubuntu 存儲庫實際安裝該軟體包感到困惑(我的意思是安裝它而不需要付出很多努力,例如從源代碼包下載和構建)。

網路搜尋顯示http://www.ubuntu.com/certification/catalog/component/input/4932/input%3AAlpsPS/2ALPSGlidePoint/ 其中談論的是經過認證的筆記型電腦。 E6410 未列出。

搜尋 glidepoint 包顯示:

https://launchpad.net/ubuntu/+source/touchpad-glidepoint

其中說:

Ubuntu 中沒有此來源套件的目前版本。

這是要安裝的正確軟體包嗎?由於上述評論,我的結論是“不”。如果這不是正確的軟體包,我應該使用哪一個?如果它是正確的包,那麼為什麼會出現“沒有當前版本”訊息?

詳細資訊:

Ubuntu 版本來自cat /etc/issue

Ubuntu 15.04 \n \l

lspci顯示:

00:00.0 Host bridge: Intel Corporation Core Processor DRAM Controller (rev 02)
00:01.0 PCI bridge: Intel Corporation Core Processor PCI Express x16 Root Port (rev 02)
00:16.0 Communication controller: Intel Corporation 5 Series/3400 Series Chipset HECI Controller (rev 06)
00:16.3 Serial controller: Intel Corporation 5 Series/3400 Series Chipset KT Controller (rev 06)
00:19.0 Ethernet controller: Intel Corporation 82577LM Gigabit Network Connection (rev 05)
00:1a.0 USB controller: Intel Corporation 5 Series/3400 Series Chipset USB2 Enhanced Host Controller (rev 05)
00:1b.0 Audio device: Intel Corporation 5 Series/3400 Series Chipset High Definition Audio (rev 05)
00:1c.0 PCI bridge: Intel Corporation 5 Series/3400 Series Chipset PCI Express Root Port 1 (rev 05)
00:1c.1 PCI bridge: Intel Corporation 5 Series/3400 Series Chipset PCI Express Root Port 2 (rev 05)
00:1c.2 PCI bridge: Intel Corporation 5 Series/3400 Series Chipset PCI Express Root Port 3 (rev 05)
00:1c.3 PCI bridge: Intel Corporation 5 Series/3400 Series Chipset PCI Express Root Port 4 (rev 05)
00:1d.0 USB controller: Intel Corporation 5 Series/3400 Series Chipset USB2 Enhanced Host Controller (rev 05)
00:1e.0 PCI bridge: Intel Corporation 82801 Mobile PCI Bridge (rev a5)
00:1f.0 ISA bridge: Intel Corporation Mobile 5 Series Chipset LPC Interface Controller (rev 05)
00:1f.2 IDE interface: Intel Corporation 5 Series/3400 Series Chipset 4 port SATA IDE Controller (rev 05)
00:1f.3 SMBus: Intel Corporation 5 Series/3400 Series Chipset SMBus Controller (rev 05)
00:1f.5 IDE interface: Intel Corporation 5 Series/3400 Series Chipset 2 port SATA IDE Controller (rev 05)
00:1f.6 Signal processing controller: Intel Corporation 5 Series/3400 Series Chipset Thermal Subsystem (rev 05)
01:00.0 VGA compatible controller: NVIDIA Corporation GT218M [NVS 3100M] (rev a2)
01:00.1 Audio device: NVIDIA Corporation High Definition Audio Controller (rev a1)
03:00.0 Network controller: Intel Corporation Centrino Advanced-N 6200 (rev 35)
04:00.0 SD Host controller: Ricoh Co Ltd MMC/SD Host Controller (rev 03)
04:00.4 FireWire (IEEE 1394): Ricoh Co Ltd R5C832 PCIe IEEE 1394 Controller (rev 03)
3f:00.0 Host bridge: Intel Corporation Core Processor QuickPath Architecture Generic Non-core Registers (rev 02)
3f:00.1 Host bridge: Intel Corporation Core Processor QuickPath Architecture System Address Decoder (rev 02)
3f:02.0 Host bridge: Intel Corporation Core Processor QPI Link 0 (rev 02)
3f:02.1 Host bridge: Intel Corporation 1st Generation Core Processor QPI Physical 0 (rev 02)
3f:02.2 Host bridge: Intel Corporation 1st Generation Core Processor Reserved (rev 02)
3f:02.3 Host bridge: Intel Corporation 1st Generation Core Processor Reserved (rev 02)

xinput list顯示:

⎡ Virtual core pointer                        id=2    [master pointer  (3)]
⎜   ↳ Virtual core XTEST pointer                id=4    [slave  pointer  (2)]
⎜   ↳ AlpsPS/2 ALPS DualPoint TouchPad          id=12   [slave  pointer  (2)]
⎜   ↳ DualPoint Stick                           id=13   [slave  pointer  (2)]
⎣ Virtual core keyboard                       id=3    [master keyboard (2)]
    ↳ Virtual core XTEST keyboard                 id=5    [slave  keyboard (3)]
    ↳ Power Button                                id=6    [slave  keyboard (3)]
    ↳ Video Bus                                   id=7    [slave  keyboard (3)]
    ↳ Power Button                                id=8    [slave  keyboard (3)]
    ↳ Sleep Button                                id=9    [slave  keyboard (3)]
    ↳ Laptop_Integrated_Webcam_3M                 id=10   [slave  keyboard (3)]
    ↳ AT Translated Set 2 keyboard                id=11   [slave  keyboard (3)]
    ↳ Dell WMI hotkeys                            id=14   [slave  keyboard (3)]

xinput list-props 'DualPoint Stick'顯示:

Device 'DualPoint Stick':
    Device Enabled (142):   1
    Coordinate Transformation Matrix (144): 1.000000, 0.000000, 0.000000, 0.000000, 1.000000, 0.000000, 0.000000, 0.000000, 1.000000
    Device Accel Profile (265): 2
    Device Accel Constant Deceleration (266):   1.000000
    Device Accel Adaptive Deceleration (267):   1.000000
    Device Accel Velocity Scaling (268):    10.000000
    Device Product ID (260):    2, 8
    Device Node (261):  "/dev/input/event5"
    Evdev Axis Inversion (304): 0, 0
    Evdev Axes Swap (306):  0
    Axis Labels (307):  "Rel X" (152), "Rel Y" (153)
    Button Labels (308):    "Button Left" (145), "Button Middle" (146), "Button Right" (147), "Button Wheel Up" (148), "Button Wheel Down" (149), "Button Horiz Wheel Left" (150), "Button Horiz Wheel Right" (151)
    Evdev Scrolling Distance (309): 0, 0, 0
    Evdev Middle Button Emulation (310):    0
    Evdev Middle Button Timeout (311):  50
    Evdev Third Button Emulation (312): 0
    Evdev Third Button Emulation Timeout (313): 1000
    Evdev Third Button Emulation Button (314):  3
    Evdev Third Button Emulation Threshold (315):   20
    Evdev Wheel Emulation (316):    1
    Evdev Wheel Emulation Axes (317):   6, 7, 4, 5
    Evdev Wheel Emulation Inertia (318):    10
    Evdev Wheel Emulation Timeout (319):    200
    Evdev Wheel Emulation Button (320): 2
    Evdev Drag Lock Buttons (321):  0

設定僅顯示紅色標記的內容:

設定視圖

並且沒有顯示任何允許我控制 TrackPoint 行為的小部件,這讓我相信缺少了某些東西,因此,我需要尋找並安裝一些特殊的軟體包:

滑鼠和觸控板視圖

答案1

若要停用 Latitude 上的 DualPoint Stick,請開啟終端機並輸入:

xinput disable 'AlpsPS/2 ALPS DualPoint Stick'
