Flowframe 未移至下一頁

tag-icon • tag-icon flowfram
Flowframe 未移至下一頁

我試圖將此流程擴展到下一頁，但沒有發生。即使嘗試定義頁碼 [1-2]，編譯器仍然沒有對齊文字。我需要流程在下一頁繼續。它限制我只能使用單頁

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Document properties and packages
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\documentclass[a4paper,12pt,final]{memoir}

% misc
\renewcommand{\familydefault}{bch}  % font
\pagestyle{empty}                   % no pagenumbering
\setlength{\parindent}{0pt}         % no paragraph indentation


% required packages (add your own)
\usepackage{flowfram}                                       % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx}                                       % figures
\usepackage{url}                                            % URLs
\usepackage[usenames,dvipsnames]{xcolor}                    % color
\usepackage{multicol}                                       % columns env.
    \setlength{\multicolsep}{0pt}
\usepackage{paralist}                                       % compact lists
\usepackage{tikz}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}

% frame setup (flowfram package)
% left frame
\newflowframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
    \newlength{\LeftMainSep}
    \setlength{\LeftMainSep}{0.2\textwidth}
    \addtolength{\LeftMainSep}{2\columnsep}
% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]

% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
    \draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
    (0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule{flow}{1}{flow}{2}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}

\newenvironment{AboutMe}
    {\ignorespaces\textbf{\color{RoyalBlue} About me}}
    {\Sep\ignorespacesafterend}

\newcommand{\CVSection}[1]
    {\Large\textbf{#1}\par
    \SmallSep\normalsize\normalfont}

\newcommand{\CVItem}[1]
    {\textbf{\color{RoyalBlue} #1}}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}

% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{figure}
    \hfill
    \includegraphics[width=0.6\columnwidth]{cv-photo.png}
    \vspace{-7cm}
\end{figure}

\begin{flushright}\small
    Johnathan S. Doe \\
    \url{[email protected]}  \\
    \url{www.website.com} \\
    (555) 555-3333
\end{flushright}\normalsize
\framebreak


% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries  Graphics designer \\

\normalsize\normalfont

% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}

% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep

\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep

% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep

% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep

\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
    \item Dolor
    \item Sit
    \item Amet
    \item Consectetur
    \item Adipiscing
    \item Elit
    \item \ldots
\end{compactitem}
\end{multicols}
\Sep

% References
\CVSection{References}
References upon request.

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}

答案1

您的 MWE 實際上沒有兩頁文本，因此我使用以下命令添加了一些額外的虛擬文本lipsum包裹。問題是第一頁右框架中的文字流入第二頁上窄得多的左框架中，這導致 TeX 出現問題，因為它無法調整段落中間的線寬。但是，我懷疑您實際上希望第一頁右側框架中的文字流入第二頁右側框架中。在這種情況下，左框架更適合作為動態框架，並且可以使用dynamiccontents（或dynamiccontents*）環境或命令之一（例如 ）來設定內容\setdynamiccontents。這是對 MWE 的修改：

\documentclass[a4paper,12pt,final,oneside]{memoir}

% misc
\renewcommand{\familydefault}{bch}  % font
\pagestyle{empty}                   % no pagenumbering
\setlength{\parindent}{0pt}         % no paragraph indentation


% required packages (add your own)
\usepackage{flowfram}                                       % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx}                                       % figures
\usepackage{url}                                            % URLs
\usepackage[usenames,dvipsnames]{xcolor}                    % color
\usepackage{multicol}                                       % columns env.
    \setlength{\multicolsep}{0pt}
\usepackage{paralist}                                       % compact lists
\usepackage{tikz}
\usepackage{lipsum}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}

% frame setup (flowfram package)
% left frame
\newdynamicframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
    \newlength{\LeftMainSep}
    \setlength{\LeftMainSep}{0.2\textwidth}
    \addtolength{\LeftMainSep}{2\columnsep}

\setdynamicframe*{left}{clear}

% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]

% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
    \draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
    (0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule*{dynamic}{left}{flow}{main01}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}

\newenvironment{AboutMe}
    {\ignorespaces\textbf{\color{RoyalBlue} About me}}
    {\Sep\ignorespacesafterend}

\newcommand{\CVSection}[1]
    {\Large\textbf{#1}\par
    \SmallSep\normalsize\normalfont}

\newcommand{\CVItem}[1]
    {\textbf{\color{RoyalBlue} #1}}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}

% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{dynamiccontents*}{left}
{\centering
    \includegraphics[width=0.6\linewidth]{example-image}
\par
}

\begin{flushright}\small
    Johnathan S. Doe \\
    \url{[email protected]}  \\
    \url{www.website.com} \\
    (555) 555-3333
\end{flushright}\normalsize
\end{dynamiccontents*}


% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries  Graphics designer \\

\normalsize\normalfont

% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}

% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep

\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep

% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep

% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep

\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
    \item Dolor
    \item Sit
    \item Amet
    \item Consectetur
    \item Adipiscing
    \item Elit
    \item \ldots
\end{compactitem}
\end{multicols}
\Sep

% References
\CVSection{References}
References upon request.

\lipsum

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}

主要區別是：oneside類別選項，將左框架變更為動態框架，並使用環境設定其內容dynamiccontents*。我也用過

\setdynamicframe*{left}{clear}

每次分頁後清除左框架。如果您不希望發生這種情況，請刪除此行。
