Tikz：有沒有辦法建立無頭箭頭寬度邊緣（有角度）？

tag-icon • tag-icon tikz-arrows
Tikz：有沒有辦法建立無頭箭頭寬度邊緣（有角度）？

我有這個箭頭，如果與節點一起使用，它可以正常工作：

\node[draw, single arrow,
        minimum height=9mm, minimum width=1mm,
        single arrow head extend=0mm,
        anchor=west]

\draw但是我怎樣才能在像這樣的“有角度”版本中獲得與 和 相同的箭頭(a) |- (b)？

答案1

如果我正確理解了OP，這就是我的嘗試：

\documentclass[border=3mm]{standalone}
\usepackage{tikz}
\newcommand{\angledArrowDown}[3]{
\coordinate (A) at #2;
\coordinate (B) at #3;
\node[anchor=south west,inner sep=#1/4] (StPoint-1)at (A){};
\node[anchor=north west,inner sep=#1/4] (StPoint-2) at (A){};
\node[anchor=south west,inner sep=#1/2] (EndPoint-1)at (B){};
\node[anchor=south east,inner sep=#1/2] (EndPoint-2) at (B){};
\draw (StPoint-1.north west) -| (EndPoint-1.north) -- (EndPoint-1.north east) -- (B)
-- (EndPoint-2.north west) -- (EndPoint-2.north) |- (StPoint-2.south west) -- cycle;}

\newcommand{\angledArrowUp}[3]{
\coordinate (A) at #2;
\coordinate (B) at #3;
\node[anchor=south west,inner sep=#1/4] (StPoint-1)at (A){};
\node[anchor=north west,inner sep=#1/4] (StPoint-2) at (A){};
\node[anchor=north east,inner sep=#1/2] (EndPoint-1)at (B){};
\node[anchor=north west,inner sep=#1/2] (EndPoint-2) at (B){};
\draw (StPoint-1.north west) -| (EndPoint-1.south) -- (EndPoint-1.south west) -- (B)
-- (EndPoint-2.south east) -- (EndPoint-2.south) |- (StPoint-2.south west) -- cycle;}
\begin{document}
\begin{tikzpicture}
%\angledArrowDown{thick}{star point}{end point below start point}
\angledArrowDown{5mm}{(0,1)}{(1,-1)}

%\angledArrowUp{thick}{star point}{end point above start point}
\angledArrowUp{5mm}{(0,-3)}{(1,-1)}
\end{tikzpicture}
\end{document}

在此輸入影像描述

答案2

只是為了好玩：某種箭頭樣式。優點是您可以使用簡單的命令來繪製箭頭，例如

\draw[outlined arrow] (-1,3) -| (0,0);

缺點是與vi pa 的好答案或者這個答案，它將內部塗成白色。外觀由各種 pgf 鍵控制（請參閱移位範圍中的範例）。

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{arrows.meta}
\begin{document}
\begin{tikzpicture}[outlined arrow/.code={\tikzset{oarrow/.cd,#1},
    \def\pv##1{\pgfkeysvalueof{/tikz/oarrow/##1}}%
    \edef\locallw{\the\pgflinewidth}%
    \tikzset{-{Triangle[open,fill=white,line width=\locallw,
        length=\pv{head length},width=\pv{head width}]},
    line width=\pv{line width},
    postaction={-,draw=white,line width=\pv{line width}-2*\locallw,
        shorten <=\locallw,shorten >=\pv{head length}-1.5*\locallw}%
    }},oarrow/.cd,line width/.initial=0.6cm,head width/.initial=1.2cm,
    head length/.initial=1cm]
 \draw[outlined arrow] (-1,3) -| (0,0);
 \draw[outlined arrow] (-1,-3) -| (0,0);
 \begin{scope}[xshift=5cm]
  \draw[blue,thick,outlined arrow={line width=0.7cm,head width=1.4cm}] (-1,3) -| (0,0);
  \draw[red,outlined arrow={line width=0.5cm,head length=0.8cm}] (-1,-3) -| (0,0);
 \end{scope}
\end{tikzpicture}
\end{document}

在此輸入影像描述

彎曲箭頭不適用於這種樣式，您可能需要看看例如這裡一種製作彎曲箭頭的可能方法。
