我該如何創建這個乳膠中？我對 Latex 比較陌生，沒有創建任何圖表的經驗。
數字和文字本身是任意的，只要有空間即可。我還在尋找陰影“條形圖”以具有適當的縮放比例，例如綠色部分的起點（點313）應該是左側條形總寬度的313/1139。請注意，這些數字應該能夠被任何一組數字取代。同樣的想法適用於帶箭頭的行。總寬度為textwidth。
答案1
歡迎來到 TeX.SX！
你可以使用 TikZ繪製你的圖表。我強烈建議閱讀該包的文檔了解如何使用它。例如，您可以這樣開始：
\documentclass[border=1mm, tikz]{standalone}
\newcounter{rowstart}
\newcounter{rowend}
\newcounter{sequencestart}
\newcounter{sequenceend}
\newcounter{matchrevstart}
\newcounter{matchrevend}
\newcounter{matchfwdstart}
\newcounter{matchfwdend}
\newcommand{\drawsequence}{%
\begin{tikzpicture}[x=.25mm, y=5cm,
row/.append style={black},
sequence/.append style={row, fill=green},
]
\coordinate (rstart) at (\therowstart,0);
\coordinate (sstart) at (\thesequencestart,0);
\coordinate (send) at (\thesequenceend,0);
\coordinate (rend) at (\therowend,0);
\draw[row] ([yshift=5mm]rstart) rectangle coordinate[pos=.5] (xrleft) ([yshift=-5mm]sstart);
\draw[sequence] ([yshift=5mm]sstart) rectangle coordinate[pos=.5] (xsequence) ([yshift=-5mm]send);
\draw[row] ([yshift=5mm]send) rectangle coordinate[pos=.5] (xrright) ([yshift=-5mm]rend);
\node at ([yshift=7.5mm]rstart) {\therowstart};
\node at ([yshift=7.5mm]sstart) {\thesequencestart};
\node at ([yshift=7.5mm]send) {\thesequenceend};
\node at ([yshift=7.5mm]rend) {\therowend};
\node at (xrleft) {5' UTR};
\node at (xrright) {3' UTR};
\node at (xsequence) {Protein Coding Sequence};
\draw[dashed] ([yshift=-5mm]\thematchrevstart,0) -- ++(0,-.8);
\draw[dashed] ([yshift=-5mm]\thematchfwdend,0) -- ++(0,-.8);
\draw[->] (\thematchrevstart,-.25) node[above right] {\thematchrevstart} -- node[above, pos=.5] {\footnotesize Region of exact match, Reverse strand sequencing} (\thematchrevend,-.25) node[above left] {\thematchrevend};
\draw[<-] (\thematchfwdstart,-.5) node[above right] {\thematchfwdstart} -- node[above, pos=.5] {\footnotesize Region of exact match, Forward strand sequencing} (\thematchfwdend,-.5) node[above left] {\thematchfwdend};
\draw[<->] (\thematchrevstart,-.75) -- node[above, pos=.5] {\footnotesize Extent of cloned cDNA, excluding the polyA tail} (\thematchfwdend,-.75);
\end{tikzpicture}%
}
\begin{document}
\setcounter{rowstart}{1}
\setcounter{rowend}{1139}
\setcounter{sequencestart}{313}
\setcounter{sequenceend}{765}
\setcounter{matchrevstart}{213}
\setcounter{matchrevend}{1001}
\setcounter{matchfwdstart}{429}
\setcounter{matchfwdend}{1039}
\drawsequence
\end{document}
結果如下：
但是，您說過，結果應該與文本一樣寬。因此，我對上面的程式碼做了一些調整，以便結果始終縮放到文字寬度。我必須稍微增加箭頭的間距，因為文字不適合。
\documentclass{article}
\usepackage{tikz}
\newcounter{rowstart}
\newcounter{rowend}
\newcounter{sequencestart}
\newcounter{sequenceend}
\newcounter{matchrevstart}
\newcounter{matchrevend}
\newcounter{matchfwdstart}
\newcounter{matchfwdend}
\newcommand{\drawsequence}{%
\noindent\begin{tikzpicture}[
row/.append style={black},
sequence/.append style={row, fill=green},
]
\coordinate (rstart) at ({\therowstart/\therowend*\textwidth},0);
\coordinate (sstart) at ({\thesequencestart/\therowend*\textwidth},0);
\coordinate (send) at ({\thesequenceend/\therowend*\textwidth},0);
\coordinate (rend) at ({\therowend/\therowend*\textwidth},0);
\coordinate (mrstart) at ({\thematchrevstart/\therowend*\textwidth},0);
\coordinate (mfstart) at ({\thematchfwdstart/\therowend*\textwidth},0);
\coordinate (mrend) at ({\thematchrevend/\therowend*\textwidth},0);
\coordinate (mfend) at ({\thematchfwdend/\therowend*\textwidth},0);
\draw[row] ([yshift=2.5mm]rstart) rectangle coordinate[pos=.5] (xrleft) ([yshift=-2.5mm]sstart);
\draw[sequence] ([yshift=2.5mm]sstart) rectangle coordinate[pos=.5] (xsequence) ([yshift=-2.5mm]send);
\draw[row] ([yshift=2.5mm]send) rectangle coordinate[pos=.5] (xrright) ([yshift=-2.5mm]rend);
\node[anchor=west] at ([yshift=5mm]rstart) {\therowstart};
\node at ([yshift=5mm]sstart) {\thesequencestart};
\node at ([yshift=5mm]send) {\thesequenceend};
\node[anchor=east] at ([yshift=5mm]rend) {\therowend};
\node at (xrleft) {5' UTR};
\node at (xrright) {3' UTR};
\node at (xsequence) {Protein Coding Sequence};
\draw[dashed] ([yshift=-2.5mm]mrstart) -- ([yshift=-36mm]mrstart);
\draw[dashed] ([yshift=-2.5mm]mfend) -- ([yshift=-36mm]mfend);
\draw[->] ([yshift=-15mm]mrstart) node[above right] {\thematchrevstart} -- node[above, pos=.5, text width=50mm, align=center] {\footnotesize Region of exact match, Reverse strand sequencing} ([yshift=-15mm]mrend) node[above left] {\thematchrevend};
\draw[<-] ([yshift=-25mm]mfstart) node[above right] {\thematchfwdstart} -- node[above, pos=.5, text width=50mm, align=center] {\footnotesize Region of exact match, Forward strand sequencing} ([yshift=-25mm]mfend) node[above left] {\thematchfwdend};
\draw[<->] ([yshift=-35mm]mrstart) -- node[above, pos=.5, text width=50mm, align=center] {\footnotesize Extent of cloned cDNA, excluding the polyA tail} ([yshift=-35mm]mfend);
\end{tikzpicture}%
}
\begin{document}
\setcounter{rowstart}{1}
\setcounter{rowend}{1139}
\setcounter{sequencestart}{313}
\setcounter{sequenceend}{765}
\setcounter{matchrevstart}{213}
\setcounter{matchrevend}{1001}
\setcounter{matchfwdstart}{429}
\setcounter{matchfwdend}{1039}
\drawsequence
\end{document}
結果：
