Der Devanagari UTF-8-Textextraktionscode erzeugt keinen Lua-Fehler, wenn der Node-Renderer von Fontspec verwendet wird, liefert aber aufgrund eines möglichen Fehlers im Node-Renderer trotzdem kein korrektes Ergebnis. Ich habe das als separate Frage eingereicht:LuaTeX: Die Devanagari-Glyphenreihenfolge ist in der internen Knotenliste von Tex umgekehrt. Wie kann beim Durchlaufen der Glyphenknoten die richtige Reihenfolge wiederhergestellt werden?

Beim Experimentieren mit verschiedenen Techniken zur Extraktion von UTF-8-Text aus TeX-Boxen habe ich festgestellt, dass die beiden Techniken, die beim Extrahieren von Devanagari-Text mit dem Node-Renderer von Fontspec keine Lua-Fehler erzeugen, beide bei der Verwendung der HarfBuzz-Renderer von Fontspec (Renderer = Harfbuzz, Renderer = OpenType) Lua-Fehler erzeugen.

Die beiden Techniken werden hier ausführlich beschrieben:Technik-1(mithilfemicahl-h21's get_unicodeFunktion) und hier:Technik-2(nur unicode.utf8.charauf Bestandteile komplexer Glyphen anwenden). Ich habe mehrere Devanagari-Schriftarten ausprobiert, bei allen war das Verhalten dasselbe.

Der vollständige Testcode für beide Techniken und ihre jeweiligen Fehlersignaturen sind nacheinander in den folgenden Blöcken aufgeführt. Für mein Beispiel habe ich die frei verfügbare Noto Sans Devanagari (normales Gewicht) verwendet, die hier erhältlich ist:Link zu Google Fonts GitHub für Noto Sans Devanagari

Technik-1mit Devanagari und HarfBuzz (kein Lua-Fehler, wenn mit Node-Renderer kompiliert):

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
    % local fontstyles = require "l4fontstyles"
  local char = unicode.utf8.char
  local glyph_id = node.id("glyph")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local disc_id  = node.id("disc")
  local minglue  = tex.sp("0.2em")
  local usedcharacters = {}
  local identifiers = fonts.hashes.identifiers
  local function get_unicode(xchar,font_id)
    local current = {}
    local uchar = identifiers[font_id].characters[xchar].tounicode
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      print(xchar,uchar,cchar, font_id, i)
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end
  local function nodeText(n)
    local t =  {}
    for x in node.traverse(n) do
      % glyph node
      if x.id == glyph_id then
        % local currentchar = fonts.hashes.identifiers[x.font].characters[x.char].tounicode
        local chars = get_unicode(x.char,x.font)
        for _, current_char in ipairs(chars) do
          table.insert(t,current_char)
        end
      % glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      % discretionaries
      elseif x.id == disc_id then
        table.insert(t, nodeText(x.replace))
      % recursivelly process hlist and vlist nodes
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:close()
}

\box0
\end{document}

Fehlersignatur für Technik-1 (HarfBuzz-Renderer):

[\directlua]:1: bad argument #1 to 'len' (string expected, got nil)
stack traceback:
    [C]: in function 'string.len'
    [\directlua]:1: in upvalue 'get_unicode'
    [\directlua]:1: in local 'nodeText'
    [\directlua]:1: in main chunk.
l.62 }

Technik-2mit Devanagari und HarfBuzz (kein Lua-Fehler, wenn mit Node-Renderer kompiliert):

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
  local glyph_id = node.id("glyph")
  local disc_id = node.id("disc")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local minglue = tex.sp("0.2em")
  local function nodeText(n)
    local t =  {}
    for x in node.traverse(n) do
      % glyph node
      if x.id == glyph_id then
        if bit32.band(x.subtype,2) \csstring~=0 and unicode.utf8.char(x.char) \csstring~="“" and unicode.utf8.char(x.char) \csstring~="”" then %
          for g in node.traverse_id(glyph_id,x.components) do
            if bit32.band(g.subtype, 2) \csstring~=0 then
              for gc in node.traverse_id(glyph_id,g.components) do
                table.insert(t,unicode.utf8.char(gc.char))
              end
            else
              table.insert(t,unicode.utf8.char(g.char))
            end
          end
        else
          table.insert(t,unicode.utf8.char(x.char))
        end
      % disc node
      elseif x.id == disc_id then
        for g in node.traverse_id(glyph_id,x.replace) do
          if bit32.band(g.subtype, 2) \csstring~=0 then
            for gc in node.traverse_id(glyph_id,g.components) do
              table.insert(t,unicode.utf8.char(gc.char))
            end
          else
            table.insert(t,unicode.utf8.char(g.char))
          end
        end
        % glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:close()

}

\box0
\end{document}


Fehlersignatur für Technik-2 (HarfBuzz-Renderer):

[\directlua]:1: bad argument #1 to 'char' (invalid value)
stack traceback:
    [C]: in field 'char'
    [\directlua]:1: in local 'nodeText'
    [\directlua]:1: in main chunk.
l.64 }

Antwort1

Im Knotenmodus ist die Wiederherstellung des vollständigen Textes im Allgemeinen nicht möglich, da Sie eine geformte Ausgabe erhalten und geformte Glyphen nicht eindeutig wieder dem Eingabetext zugeordnet werden können. Sie können dies nur durch die Verwendung von Tounicode-Werten annähern. Diese werden den tatsächlichen ToUnicode-CMap-Einträgen der PDF-Datei zugeordnet und folgen daher ihrem eingeschränkten Modell der Zuordnung von Glyphen zu Unicode: Jede Glyphe entspricht einer festen Folge von Unicode-Codepunkten. Diese Zuordnungen werden in der Reihenfolge der Darstellung aneinandergereiht. Wie Sie gesehen haben, reicht dieses Modell nicht aus, um Devanagari-Glyphen dem Eingabetext zuzuordnen.

Sie können harfstattdessen mode verwenden, um das Problem zu vermeiden: harfmode wird von diesem eingeschränkten Modell nicht beeinflusst, da es Ihnen nicht nur eine geformte Liste von Glyphen liefert, sondern zusätzlich ActualText-Einträge mit PDF-markiertem Inhalt erstellt, die die ToUnicode-Zuordnungen in Sequenzen überschreiben, die nicht korrekt durch ToUnicode modelliert werden können. Die für diese Zuordnung erforderlichen Daten können mithilfe der glyph_dataEigenschaft aus dem Lua-Code abgefragt werden. (Dies ist ein nicht dokumentiertes Implementierungsdetail und könnte sich in Zukunft ändern.)

Wenn Sie so viel wie möglich aus einem Text extrahieren möchten, können Sie diesen eigenschaftsbasierten und den ToUnicode-basierten Ansatz in Ihrem Lua-Code kombinieren:

Erstellen Sie eine Datei extracttext.luamit

local type = type
local char = utf8.char
local unpack = table.unpack
local getproperty = node.getproperty
local getfont = font.getfont
local is_glyph = node.is_glyph

-- tounicode id UTF-16 in hex, so we need to handle surrogate pairs...
local utf16hex_to_utf8 do -- Untested, but should more or less work
  local l = lpeg
  local tonumber = tonumber
  local hex = l.R('09', 'af', 'AF')
  local byte = hex * hex
  local simple = byte * byte / function(s) return char(tonumber(s, 16)) end
  local surrogate = l.S'Dd' * l.C(l.R('89', 'AB', 'ab') * byte)
                  * l.S'Dd' * l.C(l.R('CF', 'cf') * byte) / function(high, low)
                      return char(0x10000 + ((tonumber(high, 16) & 0x3FF) << 10 | (tonumber(low, 16) & 0x3FF)))
                    end
  utf16hex_to_utf8 = l.Cs((surrogate + simple)^0)
end

-- First the non-harf case

-- Standard caching setup
local identity_table = setmetatable({}, {__index = function(_, id) return char(id) end})
local cached_text = setmetatable({}, {__index = function(t, fid)
  local fontdir = getfont(fid)
  local characters = fontdir and fontdir.tounicode == 1 and fontdir.characters
  local font_cache = characters and setmetatable({}, {__index = function(tt, slot)
    local character = characters[slot]
    local text = character and character.tounicode or slot
    -- At this point we have the tounicode value in text. This can have different forms.
    -- The order in the if ... elseif chain is based on how likely it is to encounter them.
    -- This is a small performance optimization.
    local t = type(text)
    if t == 'string' then
      text = utf16hex_to_utf8:match(text)
    elseif t == 'number' then
      text = char(text)
    elseif t == 'table' then
      text = char(unpack(text)) -- I haven't tested this case, but it should work
    end
    tt[slot] = text
    return text
  end}) or identity_table
  t[fid] = font_cache
  return font_cache
end})

-- Now the tounicode case just has to look up the value
local function from_tounicode(n)
  local slot, fid = is_glyph(n)
  return cached_text[fid][slot]
end

-- Now the traversing stuff. Nothing interesting to see here except for the
-- glyph case
local traverse = node.traverse
local glyph, glue, disc, hlist, vlist = node.id'glyph', node.id'glue', node.id'disc', node.id'hlist', node.id'vlist'
local extract_text_vlist
-- We could replace i by #t+1 but this should be slightly faster
local function real_extract_text(head, t, i)
  for n, id in traverse(head) do
    if id == glyph then
      -- First handle harf mode: Look for a glyph_info property. If that does not exists
      -- use from_tounicode. glyph_info will sometimes/often be an empty string. That's
      -- intentional and it should *not* trigger a fallback. The actual mapping will be
      -- contained in surrounding chars.
      local props = getproperty(n)
      t[i] = props and props.glyph_info or from_tounicode(n)
      i = i + 1
    elseif id == glue then
      if n.width > 1001 then -- 1001 is arbitrary but sufficiently high to be bigger than most weird glue uses
        t[i] = ' '
        i = i + 1
      end
    elseif id == disc then
      i = real_extract_text(n.replace, t, i)
    elseif id == hlist then
      i = real_extract_text(n.head, t, i)
    elseif id == vlist then
      i = extract_text_vlist(n.head, t, i)
    end
  end
  return i
end
function extract_text_vlist(head, t, i) -- glue should not become a space here
  for n, id in traverse(head) do
    if id == hlist then
      i = real_extract_text(n.head, t, i)
    elseif id == vlist then
      i = extract_text_vlist(n.head, t, i)
    end
  end
  return i
end
return function(list)
  local t = {}
  real_extract_text(list.head, t, 1)
  return table.concat(t)
end

Dies kann als normales Lua-Modul verwendet werden:

\documentclass{article}
\usepackage{fontspec}

\newfontfamily{\devharf}{Noto Sans Devanagari}[Script=Devanagari, Renderer=HarfBuzz]
\newfontfamily{\devnode}{Noto Sans Devanagari}[Script=Devanagari, Renderer=Node]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devharf एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}
\setbox1=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devnode एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
  local extracttext = require'extracttext'
  local f = io.open("hello.harf.txt","w") % Can reproduce the full input text
  f:write(extracttext(tex.getbox(0)))
  f:close()

  f = io.open("hello.node.txt","w") % In node mode, we only get an approximation
  f:write(extracttext(tex.getbox(1)))
  f:close()
}

\box0
\box1
\end{document}

Ein allgemeinerer Hinweis: Wie Sie sehen, ist es mit einigem Aufwand verbunden, Text aus einer geformten Liste zu erhalten, insbesondere im Fall von ToUnicode, wo wir Surrogatpaare und ähnliches zuordnen müssen. Das liegt hauptsächlich daran, dass geformter Textnichtfür eine solche Verwendung vorgesehen. Sobald die Glyphenknoten geschützt sind (auch bekannt als Subtyp(n) >= 256 oder not is_char(n)ist true), .charenthalten die Einträge keine Unicode-Werte mehr, sondern interne Bezeichner, der .fontEintrag hat möglicherweise nicht mehr den erwarteten Wert und einige Glyphen werden möglicherweise überhaupt nicht als Glyphen dargestellt. In den meisten Fällen, in denen Sie tatsächlich auf den Text hinter einem Feld zugreifen möchten und nicht nur auf die visuelle Anzeige des Textes, möchten Sie die Liste wirklich abfangenVores wird erst geformt.

Antwort2

tounicodeIch weiß nicht viel darüber, wie HarfBuzz-Schriftarten von Luaotfload verarbeitet werden, aber dank konnte ich herausfinden, wie ich die Felder bekomme table.serialize. Mein ursprünglicher, für Harfbuzz angepasster Code sieht also folgendermaßen aus:

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}
\usepackage{luacode}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]
\newfontfamily{\arabicfam}{Amiri}[Script=Arabic, Scale=1, Renderer=HarfBuzz]

\begin{document}

\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}
\setbox1=\hbox{\arabicfam \textdir TRT  هذه المقالة عن براغ. لتصفح عناوين مشابهة، انظر براغ (توضيح).}

\begin{luacode*}
  -- local fontstyles = require "l4fontstyles"
  local char = unicode.utf8.char
  local glyph_id = node.id("glyph")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local disc_id  = node.id("disc")
  local minglue  = tex.sp("0.2em")
  local usedcharacters = {}
  local identifiers = fonts.hashes.identifiers
  local fontcache = {}

  local function to_unicode_chars(uchar)
    local uchar = uchar or ""
    -- put characters into a table
    local current = {}
    -- each codepoint is 4 bytes long, we loop over tounicode entry and cut it into 4 bytes chunks
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      -- codepoint is hex string, we need to convert it to number ad then to UTF8 char
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end
  -- cache character lookup, to speed up things
  local function get_character_from_cache(xchar, font_id)
    local current_font = fontcache[font_id] or {characters = {}}
    fontcache[font_id] = current_font -- initialize font cache for the current font if it doesn't exist
    return current_font.characters[xchar]
  end

  -- save characters to cache for faster lookup
  local function save_character_to_cache(xchar, font_id, replace)
    fontcache[font_id][xchar] = replace
    -- return value
    return replace
  end

  local function initialize_harfbuzz_cache(font_id, hb)
    -- save some harfbuzz tables for faster lookup
    local current_font = fontcache[font_id]
    -- the unicode data can be in two places
    -- 1. hb.shared.glyphs[glyphid].backmap
    current_font.glyphs = current_font.glyphs or hb.shared.glyphs
    -- 2. hb.shared.unicodes
    -- it contains mapping between Unicode and glyph id
    -- we must create new table that contains reverse mapping
    if not current_font.backmap then
      current_font.backmap = {}
      for k,v in pairs(hb.shared.unicodes) do
        current_font.backmap[v] = k
      end
    end
    -- save it back to the font cache
    fontcache[font_id] = current_font
    return current_font.glyphs, current_font.backmap
  end

  local function get_unicode(xchar,font_id)
    -- try to load character from cache first
    local current_char = get_character_from_cache(xchar, font_id)
    if current_char then return current_char end
    -- get tounicode for non HarfBuzz fonts
    local characters = identifiers[font_id].characters
    local uchar = characters[xchar].tounicode
    -- stop processing if tounicode exists
    if uchar then return save_character_to_cache(xchar, font_id, to_unicode_chars(uchar)) end
    -- detect if font is processed by Harfbuzz
    local hb = identifiers[font_id].hb
    -- try HarfBuzz data
    if not uchar and hb then
      -- get glyph index of the character
      local index = characters[xchar].index
      -- load HarfBuzz tables from cache
      local glyphs, backmap = initialize_harfbuzz_cache(font_id, hb)
      -- get tounicode field from HarfBuzz glyph info
      local tounicode = glyphs[index].tounicode
      if tounicode then
        return save_character_to_cache(xchar, font_id, to_unicode_chars(tounicode))
      end
      -- if this fails, try backmap, which contains mapping between glyph index and Unicode
      local backuni = backmap[index]
      if backuni then
        return save_character_to_cache(xchar, font_id, {char(backuni)})
      end
      -- if this fails too, discard this character
      return save_character_to_cache(xchar, font_id, {})
    end
    -- return just the original char if everything else fails
    return save_character_to_cache(xchar, font_id, {char(xchar)})
  end

  local function nodeText(n)
    -- output buffer
    local t =  {}
    for x in node.traverse(n) do
      -- glyph node
      if x.id == glyph_id then
        -- get table with characters for current node.char
        local chars = get_unicode(x.char,x.font)
        for _, current_char in ipairs(chars) do
          -- save characters to the output buffer
          table.insert(t,current_char)
        end
      -- glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      -- discretionaries
      elseif x.id == disc_id then
        table.insert(t, nodeText(x.replace))
      -- recursivelly process hlist and vlist nodes
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  local n1 = tex.getbox(1)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:write(nodeText(n1.head))
  f:close()
\end{luacode*}

\box0

\box1
\end{document}

Ich habe auch eine arabische Probe hinzugefügt vonWikipedia. Hier ist der Inhalt von hello.txt:

Příliš žluťoučký kůň úpěl ďábelské ódy difference diffierence. एक गांव -- में मोहन नाम का लड़का रहता था। उसके पताजी एक मामूली मजदूर थे।هذه المقالة عن براغ. لتصفح عناوين مشابهة، انظر براغ (توضيح).

Zwei wichtige Funktionen sind diese

  local function to_unicode_chars(uchar)
    local uchar = uchar or ""
    local current = {}
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end

to_unicode_charsDie Funktion teilt to_unicode-Einträge in vier Byte große Blöcke auf, die dann in UTF-8-Zeichen umgewandelt werden. Sie kann auch Glyphen ohne Einträge verarbeiten tounicode, in diesem Fall gibt sie einfach eine leere Zeichenfolge zurück.

  local function get_unicode(xchar,font_id)
    -- try to load character from cache first
    local current_char = get_character_from_cache(xchar, font_id)
    if current_char then return current_char end
    -- get tounicode for non HarfBuzz fonts
    local characters = identifiers[font_id].characters
    local uchar = characters[xchar].tounicode
    -- stop processing if tounicode exists
    if uchar then return save_character_to_cache(xchar, font_id, to_unicode_chars(uchar)) end
    -- detect if font is processed by Harfbuzz
    local hb = identifiers[font_id].hb
    -- try HarfBuzz data
    if not uchar and hb then
      -- get glyph index of the character
      local index = characters[xchar].index
      -- load HarfBuzz tables from cache
      local glyphs, backmap = initialize_harfbuzz_cache(font_id, hb)
      -- get tounicode field from HarfBuzz glyph info
      local tounicode = glyphs[index].tounicode
      if tounicode then
        return save_character_to_cache(xchar, font_id, to_unicode_chars(tounicode))
      end
      -- if this fails, try backmap, which contains mapping between glyph index and Unicode
      local backuni = backmap[index]
      if backuni then
        return save_character_to_cache(xchar, font_id, {char(backuni)})
      end
      -- if this fails too, discard this character
      return save_character_to_cache(xchar, font_id, {})
    end
    -- return just the original char if everything else fails
    return save_character_to_cache(xchar, font_id, {char(xchar)})
  end

Diese Funktion versucht zunächst, Uniocode-Daten aus den aktuellen Schriftinformationen zu laden. Wenn dies fehlschlägt, versucht sie, in den Harfbuzz-Tabellen nachzuschlagen. Für die meisten Zeichen gibt es tounicodeeine Zuordnung in der glyphsTabelle. Wenn diese nicht verfügbar ist, versucht sie es mit der unicodesTabelle, die die Zuordnung zwischen Glyphenindizes und Unicode enthält. Wenn auch dies fehlschlägt, verwerfen wir dieses Zeichen.

verwandte Informationen
